Jofran 1801-42 Assembly Instructions

j
OFRAN
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may have come
loose inside the carton during shipment.
No
Code
1A 1801-42P13NL
1B 1801-42P13NR
2
1801-42P02L
3
1801-42P02R
4 1801-42P11
5 1801-42P11S
6 1801P01F
x 08
2
MADE IN VIET NAM
INC.
Parts key
Qty
Description
2 pcs
Left Side Facing Extension Mechanism
2 pcs
Right Side Facing Extension Mechanism
Left Side Facing Leg
2 pcs
Right Side Facing Leg
2 pcs
Center Connecting Stretcher
1 pc
Side Stretcher
2 pcs
Floor Glide
4 pcs
6
H
E
D
B
5
3
1
3
5
ASSEMBLY INSTRUCTIONS &
PARTS IDENTIFICATION
MODEL # 1801 - 42
COUNTER HEIGHT TRESTLE TABLE
TELLURIDE GOLD
No
Bolt
A
Hex Nut
B
Semi lunar washer
C
D Lock washer
E Big Flat washer
F
Small Flat washer
G
Allen Key
H
Wrench
C A D G
x 04
4
2
3
4
Hardware kit
#1801-42P01
Description
Ø7.8 x 50
Ø8
Ø8 x 30
Ø8
Ø10 x 22
Ø8 x 16
K4
12
G
A x 02
D
F
5
2
2
5
Qty
6 pcs
8 pcs
4 pcs
14 pcs
8 pcs
2 pcs
1 pc
1 pc
3
