User Self Repair Guide
CMP0484-00 EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC-F9500H Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Epson SC-F9500H Series

Summary of Contents for Epson SC-F9500H Series

  • Page 1 User Self Repair Guide CMP0484-00 EN...

  • Page 2: Copyrights And Trademarks

    Epson printer. Epson is not responsible for any use of this information as applied to other printers. Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by the purchaser or third parties as a result of accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation’s operating and maintenance instructions.

  • Page 3: Table Of Contents

    SC-F9500H Series/SC-F9500 Series User Self Repair Guide Contents Contents Copyrights and Trademarks Introduction Meaning of Symbols......4 Illustrations and Photos Used in this Guide.

  • Page 4: Introduction

    SC-F9500H Series/SC-F9500 Series User Self Repair Guide Introduction Introduction Meaning of Symbols Warning: Warnings must be followed to avoid serious bodily injury. Caution: Cautions must be followed to avoid bodily injury. Important: Important must be followed to avoid damage to this product.

  • Page 5: Notes On User Self Repair Work

    SC-F9500H Series/SC-F9500 Series User Self Repair Guide Notes on User Self Repair Work Notes on User Self Repair Work What is User Self Repair Work In this manual, starting this unit in Self Repair mode to perform diagnostics and then replace User Self Repair parts is known as "User Self Repair Work".

  • Page 6: Notes When Working

    ❏ The replacement Print Head is a precision instrument. Handle with the utmost care. Be careful not to lose it. ❏ Work within the following temperature and humidity ranges. 15 to 30˚C (59 to 86˚F) 20 to 80% ❏ When performing this operation, connect the printer to the network and Epson Cloud Solution PORT.

  • Page 7: Notes On Safety

    SC-F9500H Series/SC-F9500 Series User Self Repair Guide Notes on Safety Notes on Safety This section lists precautions that must be taken to use the product safely and prevent damage to property or injury to operators or others. Regions other than North America and Latin America : In addition, be sure to read the "Safety Instructions" in the Setup Guide (booklet) or the Safety Instructions (booklet), which is a separate manual.

  • Page 8: Work Flow

    SC-F9500H Series/SC-F9500 Series User Self Repair Guide Work Flow Work Flow 1. Start the printer in User Self Repair Mode “How to Start in User Self Repair Mode” on page 9 2. Run Diagnosis from the Repair Menu Take measures according to the diagnostic results. In some cases, you may not need to replace the Self Repair parts, you may only need to perform Cleaning (Heavy) or clean the capping station.

  • Page 9: How To Start In User Self Repair Mode

    SC-F9500H Series/SC-F9500 Series User Self Repair Guide How to Start in User Self Repair Mode How to Start in User Self Repair Mode You can check the procedure in a video on YouTube. Epson Video Manuals Check that the printer's power is off.

  • Page 10: How To Do Diagnosis

    SC-F9500H Series/SC-F9500 Series User Self Repair Guide How to Do Diagnosis Select the rows that you noted needed cleaning How to Do Diagnosis when you executed Diagnosis. Selecting All Nozzles cleans all the rows. Diagnosis Procedure Check the message, and then press Start.

  • Page 11: Replacing And Adjusting The Print Head

    ❏ Use the outer carton, plastic bag, and protective case to pack the used Print Head to send it to your Prevent ink from coming into contact with your skin dealer or Epson Support. Open them carefully or from entering your eyes or mouth. without tearing anything.

  • Page 12: Correctly Holding The Print Head

    SC-F9500H Series/SC-F9500 Series User Self Repair Guide Replacing and Adjusting the Print Head Nozzle surfaces (bottom side of Print Head) Correctly Holding the Print Head When replacing the Print Head or removing it from its protective case, use both hands and hold it at the positions shown in the photos.
  • Page 13 SC-F9500H Series/SC-F9500 Series User Self Repair Guide Replacing and Adjusting the Print Head Check the on-screen messages, and then press Unplug the power cable connected to the right of the printer from the electrical outlet. Start. If you need to cancel the operation, press...
  • Page 14 SC-F9500H Series/SC-F9500 Series User Self Repair Guide Replacing and Adjusting the Print Head Turn over the Ink Damper Unit and hang it Open the carriage cover towards you and temporarily on the hook. remove it. Turn all the fixing levers (4 locations) sideways to release the locks of the Ink Damper Unit.
  • Page 15 SC-F9500H Series/SC-F9500 Series User Self Repair Guide Replacing and Adjusting the Print Head Important: Important: ❏ Do not pull the ink tubes connected to Hold down the Print Head as you remove the the Ink Damper Unit too hard. If they...

  • Page 16: How To Install

    SC-F9500H Series/SC-F9500 Series User Self Repair Guide Replacing and Adjusting the Print Head Remove the left side connector in the same way, Use both hands to lift the Print Head straight and place it on the holder. up and remove it.
  • Page 17 SC-F9500H Series/SC-F9500 Series User Self Repair Guide Replacing and Adjusting the Print Head Connect the left and right connectors. Important: Lightly press on the top of the connectors to Do not touch the areas you should not touch while assure they are inserted.
  • Page 18 SC-F9500H Series/SC-F9500 Series User Self Repair Guide Replacing and Adjusting the Print Head Hold the Ink Damper Unit in both hands, and Important: install it on the Print Head. ❏ Do not touch the bottom of the Ink Damper Unit. There is a risk of deforming the ink supply ports.

  • Page 19: Process After Replacement

    SC-F9500H Series/SC-F9500 Series User Self Repair Guide Replacing and Adjusting the Print Head Process after Turn all the fixing levers (4 locations) back lengthwise to lock them. Replacement When Print Head replacement is complete, perform operations in the following order. Follow the on-screen instructions.

  • Page 20: About Used Print Head

    About Used Print Head Pack the used Print Head according to the following procedure, and then contact your dealer or Epson Support. How to Pack When the screen switches to Print Head...

  • Page 21: Confirm The Adjustment Results

    If there are problems with the print quality, perform Media Settings - Print Adjustments. For details on Print Adjustments, see the User's Guide (Online Manual). If the problem is not eliminated by doing Print Adjustments, contact your dealer or Epson Support.

  • Page 22: Problem Solver

    SC-F9500H Series/SC-F9500 Series User Self Repair Guide Problem Solver Problem Solver What to Do When a Message Is Displayed If the printer displays one of the messages shown below, refer to the solution listed and take the necessary steps. If messages that are not shown in the following table appear and you are uncertain about how to solve the problem, see the User's Guide (Online Manual).

  • Page 23: When A Printer Error Occurs

    “Replacing and Adjusting the Print Head” on page 11 “How to Start in User Self Repair Mode” on page 9 002202, 002204, 002206, 002208, Contact your dealer or Epson Support for assistance. Tell them the printer error code is 002209, 00220A "XXXXXX".
