Operating instructions
Electromagnetic Air Pump
55705–55707
Illustration similar, may vary depending on model
Please read and follow the operating instructions and safety information prior to initial operation.
Technical changes reserved!
Illustrations, functional steps, and technical data may deviate insignificantly due to continuous further
developments.
Advertisement
Related Manuals for WilTec CAP-100
Summary of Contents for WilTec CAP-100
- Page 1 Operating instructions Electromagnetic Air Pump 55705–55707 Illustration similar, may vary depending on model Please read and follow the operating instructions and safety information prior to initial operation. Technical changes reserved! Illustrations, functional steps, and technical data may deviate insignificantly due to continuous further developments.
- Page 2 The information contained in this document may alter at any time without prior notice. No part of this document may be copied or otherwise duplicated without prior written consent. All rights reserved. WilTec Wildanger Technik GmbH cannot be held liable for any possible mistakes in this operating man- ual, nor in the diagrams and illustrations shown.
- Page 3 Handle the pump with care to avoid impact or damage. Store the pump in a dry place and away from corrosive substances. Avoid extreme temperatures (below 0 ℃ or above 40 ℃) during storage. © by WilTec Wildanger Technik GmbH Item 55705–55707 Page 3 http://www.wiltec.de...
- Page 4 7. Regularly clean the inlet filter. Clean and replace it in good time. You can check the filter by opening the inlet cover. 8. Do not touch the device with hands or other parts of the body when the air pump is running. © by WilTec Wildanger Technik GmbH Item 55705–55707 Page 4 http://www.wiltec.de...
- Page 5 55706 220–240 0,24 55707 0,35 1 → 16 Exploded view 55705, 55706 № Part Top housing Soundproof chamber O-ring Air delivery components Base plate Motor Outlet opening © by WilTec Wildanger Technik GmbH Item 55705–55707 Page 5 http://www.wiltec.de 04 2025-1...
- Page 6 Motor base plate Outer pressure plate Motor housing Gasket Silicon chip Screw of the air chamber Diaphragm base Pressure plate of the air chamber Outlet elbow tube © by WilTec Wildanger Technik GmbH Item 55705–55707 Page 6 http://www.wiltec.de 04 2025-1...
- Page 7 Air pump not working Open circuit Repair or replace the circuit com- ponents. Thermal protection triggered by Adjust operating mode, select a excessive temperature cooler and better ventilated loca- tion. © by WilTec Wildanger Technik GmbH Item 55705–55707 Page 7 http://www.wiltec.de 04 2025-1...
- Page 8 German law related to electrical and electronic equipment and appliances. All WilTec electric devices that fall under the WEEE directive are labelled with the symbol of a crossed- out wheeled rubbish bin. This symbol indicates that this electric device must not be disposed of with the domestic waste.
