- Page 1 EN User Manual | Oven KOCAP31WT...
-
Page 2: Table Of Contents
Access your full user manual at electrolux.com/manuals Get usage advice, brochures, trouble shooter, service and repair information at electrolux.com/support For more recipes, hints, troubleshooting download My Electrolux Kitchen app. Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................4 2. - Page 3 My Electrolux Kitchen app ENGLISH...
-
Page 4: Safety Information
• Children should be supervised to ensure that they do not play with the appliance and mobile devices with My Electrolux Kitchen . • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. - Page 5 • This appliance may be used in, offices, hotel guest rooms, bed & breakfast guest rooms, farm guest houses and other similar accommodation where such use does not exceed (average) domestic usage levels. • Only a qualified person must install this appliance and replace the cable.
-
Page 6: Safety Instructions
2. SAFETY INSTRUCTIONS 2.1 Installation Ventilation opening mini‐ 560x20 mm mum size. Opening placed WARNING! on the bottom rear side Only a qualified person must install this Mains supply cable length. 1500 mm appliance. Cable is placed in the right corner of the back side •... - Page 7 • The electrical installation must have an – do not put water directly into the hot isolation device which lets you disconnect appliance. the appliance from the mains at all poles. – do not keep moist dishes and food in The isolation device must have a contact the appliance after you finish the opening width of minimum 3 mm.
-
Page 8: Pyrolytic Cleaning
2.5 Pyrolytic cleaning 2.6 Steam Cooking WARNING! WARNING! Risk of Injury / Fires / Chemical Risk of burns and damage to the Emissions (Fumes) in Pyrolytic Mode. appliance. • Before carrying out the pyrolytic cleaning • Released Steam can cause burns: and initial preheating remove from the –... -
Page 9: Product Description
• Remove the door catch to prevent children or pets from becoming trapped in the appliance. 3. PRODUCT DESCRIPTION 3.1 General overview Control panel Display Water drawer Socket for the food sensor Heating element Lamp Descaling pipe outlet Shelf support, removable Shelf positions 3.2 Accessories Wire shelf... -
Page 10: Control Panel
Food sensor To measure the temperature inside food. Telescopic runners For inserting and removing trays and wireshelf more easily. 4. CONTROL PANEL 4.1 Control panel overview ON / OFF Press and hold to turn the appliance on and off. Display Shows the current settings of the appliance. -
Page 11: Display Indicators
4.2 Display The display with the maximum number of functions set. B C D Menu / Back Wi-Fi (selected models only) Conventional cooking Time of day Information Timer Food sensor (selected models only) H G F E G. START/STOP Temperature Progress bar / Slider More Heating functions... -
Page 12: Before First Use
• Wireless network with the Internet connection. • Mobile device connected to the same wireless network. Step 1 Download the mobile app My Electrolux Kitchen and follow the instructions for the next steps. Step 2 Turn on the appliance. Step 3 Press: . - Page 13 To access the source code of these free and electrolux.opensoftwarerepository.com (folder open source software components whose GTM3). license conditions require publishing, and to 5.5 Initial preheating see their full copyright information and applicable license terms, visit: http:// Preheat the empty oven before the first use.
-
Page 14: Daily Use
6. DAILY USE WARNING! Refer to Safety chapters. 6.1 How to set: Heating functions Step 1 Turn on the oven. Step 2 Select a heating function. The display shows the default heating functions. To see more heating functions press: Step 3 Press: . - Page 15 Step 7 Fill the water drawer with cold water to the maximum level (around 950 ml) until the signal sounds or the display shows the message. Do not fill the water drawer over its maximum capacity. There is a risk of water leakage, overflow and furniture damage. WARNING! Use only cold tap water.
-
Page 16: Heating Functions
6.4 Heating functions STANDARD Heating function Application To grill thin pieces of food and to toast bread. Grill To roast large meat joints or poultry with bones on one shelf position. To make gratins and to brown. Turbo Grilling To bake on up to three shelf positions at the same time and to dry food. Set the tem‐ perature 20 - 40 °C lower than for Conventional Cooking. - Page 17 Heating function Application To defrost food (vegetables and fruit). The defrosting time depends on the amount and size of the frozen food. Defrost For dishes such as lasagna or potato gratin. To make gratins and to brown. Au Gratin To prepare tender, succulent roasts. Slow Cooking To keep food warm.
-
Page 18: Clock Functions
7. CLOCK FUNCTIONS 7.1 Clock functions description Clock function Application Cooking time To set the length of cooking. Maximum is 23 h 59 min. Start criteria To set when the timer starts counting. End action To set what happens when the timer ends counting. Delayed start To postpone the start and / or end of cooking. - Page 19 How to choose cooking start / end option Step 3 Press: Step 4 Press: Start criteria / End action. Step 5 Choose the preferred: Start criteria / End action. Step 6 Press: or . How to delay start and end of cooking Step 1 Press: Step 2...
-
Page 20: Using The Accessories
8. USING THE ACCESSORIES devices. The high rim around the shelf WARNING! prevents cookware from slipping of the shelf. Refer to Safety chapters. 8.1 Inserting accessories A small indentation at the top increases safety. The indentations are also anti-tip Wire shelf: Push the shelf between the guide bars of the shelf support. - Page 21 8.3 How to use: Food Sensor Step 1 Turn on the oven. Step 2 Set a heating function and, if necessary, the oven temperature. Step 3 Insert: Food Sensor. Meat, poultry and fish Casserole Insert the tip of Food Sensor into the centre of meat, Insert the tip of Food Sensor exactly in the centre of the fish, in the thickest part if possible.
-
Page 22: Additional Functions
9. ADDITIONAL FUNCTIONS 9.1 How to save: Favourites You can save your favourite settings, such as the heating function, the cooking time, the temperature or the cleaning function. You can save 3 favourite settings. Step 1 Turn on the appliance. Step 2 Select the preferred setting. -
Page 23: Moist Fan Baking - Recommended Accessories
(°C) (min) Sweet rolls, 16 baking tray or dripping pan 25 - 35 pieces Swiss Roll baking tray or dripping pan 15 - 25 Whole fish, 0.2 kg baking tray or dripping pan 15 - 25 Cookies, 16 pieces baking tray or dripping pan 20 - 30 Macaroons, 24 baking tray or dripping pan... - Page 24 °C Fatless sponge cake Conventional Cooking 45 - 60 Apple pie, 2 tins Ø20 cm True Fan Cooking 55 - 65 Apple pie, 2 tins Ø20 cm Conventional Cooking 55 - 65 Short bread True Fan Cooking 25 - 35 Short bread Conventional Cooking 25 - 35...
-
Page 25: Care And Cleaning
11. CARE AND CLEANING WARNING! Refer to Safety chapters. 11.1 Notes on cleaning Clean the front of the appliance only with a microfibre cloth with warm water and a mild de‐ tergent. Use a cleaning solution to clean metal surfaces. Clean stains with a mild detergent. -
Page 26: Cleaning Reminder
CAUTION! If there are other appliances installed in the same cabinet, do not use them at the same time as this function. It can cause damage to the oven. Before the Pyrolytic Cleaning: Turn off the oven and wait until Remove all accessories. -
Page 27: Descaling Reminder
11.5 How to use: Descaling Before you start: Turn off the oven and wait until it is Remove all accessories. Make sure that the water drawer is cold. empty. Duration of the first part: around 100 min Step 1 Place the deep pan on the first shelf position. Step 2 Pour 250 ml of the descaling agent in the water drawer. - Page 28 11.7 How to use: Rinsing Before you start: Turn off the oven and wait until it is cold. Remove all accessories. Step 1 Place the deep pan on the first shelf position. Step 2 Fill the water drawer with water to the maximum level until the signal sounds or the display shows the message.
- Page 29 11.11 How to remove and install: CAUTION! Door Carefully handle the glass, especially You can remove the door and the internal around the edges of the front panel. The glass panels to clean it. The number of glass glass can break. panels is different for different models.
-
Page 30: Troubleshooting
Before you replace the lamp: Step 1 Step 2 Step 3 Turn off the oven. Wait until the Disconnect the oven from the Put a cloth on the bottom of the cav‐ oven is cold. mains. ity. Top lamp Step 1 Turn the glass cover to remove it. - Page 31 12.1 What to do if... The appliance does not turn on or does not heat up Possible cause Remedy The appliance is not connected to an electrical supply Check if the appliance is correctly connected to the or it is connected incorrectly. electrical supply.
-
Page 32: Service Data
12.2 How to manage: Error codes When the software error occurs, the display shows error message. In this section, you will find the list of the problems that you can handle on your own. Code and description Remedy C2 - the Food sensor is in the appliance cavity during Take out the Food sensor. -
Page 33: Energy Efficiency
13. ENERGY EFFICIENCY 13.1 Product Information and Product Information Sheet according to EU Ecodesign and Energy Labelling Regulations Supplier's name Electrolux Model identification KOCAP31WT 944032014 Energy Efficiency Index 61.2 Energy efficiency class Energy consumption with a standard load, conventional mode 1.09 kWh/cycle Energy consumption with a standard load, fan-forced mode 0.52 kWh/cycle... -
Page 34: Menu Structure
Moist Fan Baking Standby mode Function designed to save energy during After 2 min the display switches to standby cooking. mode. When you use this function the lamp automatically turns off after 30 sec. You may turn on the lamp again but this action will reduce the expected energy savings. -
Page 35: Submenu For: Setup
Submenu Application Child Lock Prevents accidental activation of the appliance. When the option is on, the text Child Lock appears in the display when you turn on the appliance. To enable the appliance use, choose the code letters in the alphabetical order. When the option is on, and the appliance is turned off the appliance door is locked. -
Page 36: S Easy
Submenu Description Software version Information about software version. Reset all settings Restores factory settings. Reset all popups Restores all pop-ups to the original settings. 15. IT'S EASY! Before the first use you have to set: Language Display brightness Buzzer volume Water hardness Time of day Start using the appliance... -
Page 37: Environmental Concerns
Use quick functions to set the cooking time or change the cooking function 10% Finish assist - press the preferred time icon to +1 min +5 min +10 min Use 10% Finish assist to add extra time or change extend the cooking time. cooking function when 10% of the cooking time is left. - Page 40 867362161-B-112023...
