V1400X-IDL Intelligent Distribution Line
Control
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the
operation will be entirely error free or perform precisely as described in the documentation. This system has not been
designed to be used in life-critical situations and must not be used for this purpose.
Copyright © 2000 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
Vicon Part No. 8009-8017-00-00 Section 11 Rev 200
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TELEPHONE: 631-952-CCTV (2288) FACSIMILE: 631-951-CCTV (2288)
24-Hour Technical Support: 800-34-VICON (800-348-4266)
TOLL FREE: 800-645-9116 UK: 44/(0) 1489-566300 INFOFAX: 800-287-1207
Advertisement
Table of Contents
Related Manuals for Vicon V1400X-IDL
Summary of Contents for Vicon V1400X-IDL
- Page 1 Control Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose.
-
Page 5: Table Of Contents
Addressing ..............................11 Basics................................. 11 Operation Verification Procedure....................... 13 Input Devices.............................. 13 Output Devices............................13 CPU Control System Operation........................13 MAINTENANCE ......................... 15 Fuse Replacement ............................15 Contents • • • • i XX017 Rev 200 V1400X-IDL Intelligent Distribution Line Control... - Page 6 Manual References for Associated Equipment ..................19 CPUs................................19 Input Devices ..............................19 Output Devices ............................19 TECHNICAL INFORMATION ..................... 21 ELECTRICAL ............................21 CONTROLS & CONNECTORS ......................21 OPERATIONAL............................22 MECHANICAL............................22 ENVIRONMENTAL ..........................22 ii • • • • Contents XX017 Rev 200 V1400X-IDL Intelligent Distribution Line Control...
-
Page 7: Important Safeguards
Use only with a mounting accessory recommended by Vicon, or sold with the video product. Any mounting of the video product should follow Vicon’s instructions, and a mounting accessory recommended by Vicon should be used. - Page 8 Vicon or that have the contact with them might be fatal. same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other 16.
-
Page 9: Introduction
This manual covers the installation and operation of the Vicon V1400X-IDL Intelligent Distribution Line Control (IDL). The V1400X-IDL will be referred to as the IDL throughout this manual. The installation procedures should only be performed by a qualified technician using approved materials in accordance with national, state and local wiring codes. -
Page 10: How To Use This Manual
Operation section to apply power and verify operation. In addition, these sections detail information on the use of peripheral equipment used, such as input and output (I/O) devices. 2 • • • • Introduction XX017 Rev 200 V1400X-IDL Intelligent Distribution Line Control... -
Page 11: Installation
Installation of the IDL is simple. This Section will detail Quick installation and complete installation, which is comprised of Physical Installation and Cabling sub-sections. Quick Installation Figure 2 Quick Installation Installation • • • • 3 XX017 Rev 200 V1400X-IDL Intelligent Distribution Line Control... -
Page 12: Unpacking And Inspection
Open the cartons and inspect the equipment for damage. Save the cartons and packing material. If damage is present, contact the carrier and file a damage claim immediately. If the equipment must be returned to Vicon for repair, follow the instructions in the Shipping Information Section of this manual. -
Page 13: Cpu Connection
Keypad. Use the pin designations in Figure 6 for connection. NOTE: STAT 1/J1 is used to represent any of the 6- position Panel Connectors. Figure 5 J1-J10 Pin Definition for I/O Device Cable Installation • • • • 5 XX017 Rev 200 V1400X-IDL Intelligent Distribution Line Control... - Page 14 Response In - signal (Pin 5) and Ground (Pin 4) when using the port. Figure 6 STAT 1 (J1) - STAT 10 (J10) Pin Definition for V1300X-DVC/RVC Cable 6 • • • • Installation XX017 Rev 200 V1400X-IDL Intelligent Distribution Line Control...
-
Page 15: V1400X-Dvc System Console
System Console units to the V1400X-DVC Master System Console. Figure 7 STAT 1 (J1) - STAT 10 (J10) Pin Definition for V1400X-DVC Cable Installation • • • • 7 XX017 Rev 200 V1400X-IDL Intelligent Distribution Line Control... -
Page 16: Receivers And Domes
Response In - signal (Pin 5) and Ground (Pin 4) when using the port. Figure 9 STAT 1 (J1) - STAT 10 (J10) Pin Definition for V1319R Cable 8 • • • • Installation XX017 Rev 200 V1400X-IDL Intelligent Distribution Line Control... -
Page 17: Rj-45 Connector Applications
STAT 1 (J1) - STAT 10 (J10) Pin Definition for Figure 12 V1311RB Cable STAT 1 (J1) - STAT 10 (J10) Pin Definition for V7UVS Cable Installation • • • • 9 XX017 Rev 200 V1400X-IDL Intelligent Distribution Line Control... - Page 18 STAT 1 (J1) - STAT 10 (J10) Pin Definition for Surveyor2000 Cable NOTE: The RJ-45 connector can be used instead of the Terminal Block on the Surveyor2000. 10 • • • • Installation XX017 Rev 200 V1400X-IDL Intelligent Distribution Line Control...
-
Page 19: Operation
Operation The V1400X-IDL allows up to 10 I/O Devices to be connected to CPU-based Matrix systems. Since the V1400X- IDL has panel indicators and no controls, individual I/O Devices are used for operation. Refer to the Reference Section of this manual for I/O Device and CPU Instruction Manual numbers. - Page 20 NOTE: Do not connect Input Devices (Keypads/System Consoles) and Output Devices (Receivers/Domes) to the same IDL unit, as they will not operate correctly. Figure 17 Typical System Setup With Daisy-Chained IDLs 12 • • • • Operation XX017 Rev 200 V1400X-IDL Intelligent Distribution Line Control...
-
Page 21: Operation Verification Procedure
To properly control Cameras and Monitors on various CPU systems, it is necessary to setup monitor partitioning and camera seize control on the CPU. Refer to the appropriate CPU Instruction Manual for information on establishing monitor partitioning and camera seize control. Operation • • • • 13 XX017 Rev 200 V1400X-IDL Intelligent Distribution Line Control... - Page 22 NOTES 14 • • • • Operation XX017 Rev 200 V1400X-IDL Intelligent Distribution Line Control...
-
Page 23: Maintenance
Maintenance This unit does not require any scheduled maintenance. If a unit does not operate and replacement of the fuse, as described below, does not correct the problem, contact Vicon’s Service Department. Fuse Replacement If a unit is plugged into a known good outlet, switched on, and does not illuminate the Power LED, replace the Fuse. - Page 24 NOTES 16 • • • • Maintenance XX017 Rev 200 V1400X-IDL Intelligent Distribution Line Control...
-
Page 25: Shipping Instructions
Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A. - Page 26 NOTES 18 • • • • Shipping Instructions XX017 Rev 200 V1400X-IDL Intelligent Distribution Line Control...
-
Page 27: Reference
Universal Receiver X871 V1319R Dual Station Receiver X825 V15UVS Omniscan Dome X806 V7UVS Surveyor Mini Dome X971 V5UVS Surveyor 99 Dome X978 SUR2000 Surveyor2000 Mini-Dome XX031 Reference • • • • 19 XX017 Rev 200 V1400X-IDL Intelligent Distribution Line Control... - Page 28 NOTES 20 • • • • Reference XX017 Rev 200 V1400X-IDL Intelligent Distribution Line Control...
-
Page 29: Technical Information
6-pin removable Screw Terminal Block connector. Station (LEDs): Green front panel LEDs indicate Station conditions. Station (STAT J1 - J10): 6-pin removable Screw Terminal Block for each connector. Technical Information • • • • 21 XX017 Rev 200 V1400X-IDL Intelligent Distribution Line Control... -
Page 30: Operational
Storage Temperature Range: -40° to 150° F (-40° to 65° C). Storage Humidity Range: Up to 90% relative, noncondensing. Figure 19 Front and Rear Panel Views 22 • • • • Technical Information XX017 Rev 200 V1400X-IDL Intelligent Distribution Line Control... - Page 31 Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-CCTV (2288) 800-645-9116 Fax: 631-951-CCTV (2288) Infofax: 800-287-1207 Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom 44/(0) 1489/566300 Fax: 44/(0) 1489/566322 Brussels Office Planet II - Unit E...
