Vicon V100C-B-1 Instructions For Installation And Operation

INSTRUCTIONS FOR
INSTALLATION AND OPERATION
MODEL VIOOC-B-1 MOTORIZED ZOOM LENS CONTROL
The information in this instruction manual covers the instal-
lation, operation, andmaintenance of the VlOOC-B-1 Zoom
Lens Control. This unit should be installed in accordance
with national, state, and local electrical codes.
Model VlOOC-B-1 is designed to operate a variety of
Vicon motorized zoom lenses with its solid-state DC
power supply. The unit has convenient front panel
controls. Switch priority wiring prevents damage that
could occur as a result ofpushing two opposite functions
simultaneously. Speed control is provided by a knob
potentiometer mounted on the front panel. See Figure 1.
. . l E Ns g
IRIS ZOOM
OPEN CLOSE IN
Figure 1
Front and Rear Panels
