- Page 1 Owner’s Manual & Installation Guide One-Door Corner Wall Kitchen Cabinets Model # KWC2442 Note: Read all instructions before proceeding with installation. All specifications are subject to change without notice. Questions? Contact Us: 1-855-561-5222 • info@pelhamandwhite.com...
-
Page 2: Package Contents
ONE-DOOR CORNER WALL CABINET ASSEMBLY & INSTALLATION GUIDE Unpack and inspect your cabinet upon delivery to avoid costly contractor delays. Package Contents A. Back Panel x1 B. Front Side Panel x2 D. Top/Bottom Panels x2 C. Back Side Panel x1 E. - Page 3 Corner Wall Cabinet Assembly Guide Step 1: Align the card slots on the front frame (E) with the buckle on the front side panel (B), and slide them downward into place. Step 2: Align the slots on the rear back plane (A) with the clasps on the rear side panel (C) , and slide them downward into place.
- Page 4 Step 4: Attach the part assembled in step 2 to the part assembled in step 1 and flip the CAM lock to secure it in place. Corner Wall Cabinet Installation Guide For additional support on cabinets that will be loaded with heavy contents, we have included corner brackets to be used when installing.
- Page 5 STARTING IN A CORNER: Always start in a corner where two runs of cabinets will come together or at the end of the cabinet run (if there is no corner.) All doors and drawers will need to be removed prior to installation. Locate and mark wall studs for mounting hardware placement.
- Page 6 INSTALL REMAINING CABINETS: Drill a 3/16” pilot hole at the stud locations through the back panel and into the stud. Level and mount the cabinet to the wall with hardware appropriate for your wall type. If needed, shim the cabinet to level. DO NOT COMPLETELY TIGHTEN MOUNTING SCREWS UNTIL ALL CABINETS HAVE BEEN ATTACHED TOGETHER.
-
Page 7: Hinge Adjustment
HINGE ADJUSTMENT: Review the illustrations to locate the hinge on your specific cabinet. Up/Down In/Out Left/Right Silcone Pads: Attach silicone pads (BB) on the top and bottom corners of each door. Door panel can be assembled on the other side as required, please remove hinge to install on the other side which are predrilled. -
Page 8: Care And Maintenance
Care & Maintenance To keep the product clean & shining, follow the steps below. 1. For normal spills, a damp cloth is sufficient. Dry the surface immediately. 2. Cabinets can be cleaned with most general purpose household cleaners. 3. Do not use caustic agents and/or abrasive scrubbers, or oven cleaners.
