- Page 1 Owner’s Manual & Installation Guide Two-Door Wall Kitchen Cabinets Model # KW2730 KW3036 KW3030 KW3636 KW3630 Note: Read all instructions before proceeding with installation. All specifications are subject to change without notice. Questions? Contact Us: 1-855-561-5222 • info@pelhamandwhite.com...
-
Page 2: Package Contents
TWO-DOOR WALL CABINET ASSEMBLY & INSTALLATION GUIDE Unpack and inspect your cabinet upon delivery to avoid costly contractor delays. Package Contents A. Back Panel x1 B. Left Panel x1 D. Top/Bottom Panels x1 C. Right Panel x1 E. Front Face x1 E. - Page 3 Wall Cabinet Assembly Guide Step 1: Attach the left side panel (B) to the front panel (E) by inserting the tabs on the left side panel (B) into the slots on the front face (E) and pushing down until the left side panel (B) slides into place.
- Page 4 Step 4: Insert shelf support (DD) into the holes on the side panels, put on the shelf panel (H). Wall Cabinet Installation Guide For additional support on cabinets that will be loaded with heavy contents, we have included corner brackets to be used when installing.
- Page 5 STARTING IN A CORNER: Always start in a corner where two runs of cabinets will come together or at the end of the cabinet run (if there is no corner.) All doors and drawers will need to be removed prior to installation. Locate and mark wall studs for mounting hardware placement.
- Page 6 INSTALL REMAINING CABINETS: Drill a 3/16” pilot hole at the stud locations through the back panel and into the stud. Level and mount the cabinet to the wall with hardware appropriate for your wall type. If needed, shim the cabinet to level. DO NOT COMPLETELY TIGHTEN MOUNTING SCREWS UNTIL ALL CABINETS HAVE BEEN ATTACHED TOGETHER.
-
Page 7: Hinge Adjustment
HINGE ADJUSTMENT: Review the illustrations to locate the hinge on your specific cabinet. Up/Down In/Out Left/Right Silcone Pads: Attach silicone pads (BB) on the top and bottom corners of each door. Page 7/8... -
Page 8: Care And Maintenance
Care & Maintenance To keep the product clean & shining, follow the steps below. 1. For normal spills, a damp cloth is sufficient. Dry the surface immediately. 2. Cabinets can be cleaned with most general purpose household cleaners. 3. Do not use caustic agents and/or abrasive scrubbers, or oven cleaners.
