PELHAM & WHITE KBLSB36 Owner's Manual & Installation Manual

Lazy susan corner base kitchen cabinets
Hide thumbs

Advertisement

Table of Contents

Owner's Manual & Installation Guide
Lazy Susan Corner Base Kitchen Cabinets
Model #
KBLSB36
Note: Read all instructions before proceeding with installation. All specifications are
subject to change without notice.
Questions? Contact Us:
1-855-561-5222 • info@pelhamandwhite.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KBLSB36 and is the answer not in the manual?

Questions and answers

Related Manuals for PELHAM & WHITE KBLSB36

Summary of Contents for PELHAM & WHITE KBLSB36

  • Page 1 Owner’s Manual & Installation Guide Lazy Susan Corner Base Kitchen Cabinets Model # KBLSB36 Note: Read all instructions before proceeding with installation. All specifications are subject to change without notice. Questions? Contact Us: 1-855-561-5222 • info@pelhamandwhite.com...

  • Page 2: Package Contents

    LAZY SUSAN CORNER CABINET ASSEMBLY & INSTALLATION GUIDE Unpack and inspect your cabinet upon delivery to avoid costly contractor delays. Package Contents A. Back Panel x1 B. Front Side Panel C. Back Side Panel E. Front Face H. Toe Kicks x2 D.
  • Page 3 Lazy Susan Cabinet Assembly Guide Step 1: Slide Back Panel (A) in Side Panels (C1, C2) Step 2: Insert Bottom Shelf (D) into assembled unit. Step 3: Put the Front Side Panels (B) together with the Back Side Panels (C). Assemble the two Side Panels (B1, B2) and connect to the Back Panel using cam-locks.
  • Page 4 Step 4: Attach Toe Kicks (H1, H2) using cam-locks. H1 H2 Step 5: Attach the Left Front Frame (E1). Step 6: Attach the Right Front Frame (E2) and secure with cam-locks. Secure E1 to E2 using Screw (EE). Page 4/9...
  • Page 5 Step 7: Attach Revolving Basket (J) to Bottom Shelf (D) with 5 Screws (FF). Holes are pre-drilled. Step 8: Attach Top Brace (G), Attach Revolving Basket (J) by using Screws to the Top Brace. Slide Top Brace (G) into the grooves in Front Frames (E1, E2) and secure to Back Panel (A) with cam-locks.
  • Page 6 Step 10: Attach Door Hinges (DD) to Door Assembly (F) using two screws each. Select the swing of the door and secure the hinges to the Front Frame using screws. Step 11: Attach Magnetic Catch (HH) to appropriate side of the Front Frame (E). Lazy Susan Cabinet Installation Guide For additional support on cabinets that will be loaded with heavy contents, we have...
  • Page 7 STUDS: Secure to wall with #10 x 3” screws at stud location. Important: Use “pan head” or “round head” screws with seat washers. Seat screws tightly against back rail or panel without driving into back rail or panel material. STARTING IN A CORNER: Always start in a corner where two runs of cabinets will come together or at the end of the cabinet run (if there is no corner.) All doors and drawers will need to be removed prior to installation.
  • Page 8 INSTALL REMAINING CABINETS: Drill a 3/16” pilot hole at the stud locations through the back panel and into the stud. Level and mount the cabinet to the wall with hardware appropriate for your wall type. If needed, shim the cabinet to level. DO NOT COMPLETELY TIGHTEN MOUNTING SCREWS UNTIL ALL CABINETS HAVE BEEN ATTACHED TOGETHER.

  • Page 9: Hinge Adjustment

    HINGE ADJUSTMENT: Review the illustrations to locate the hinge on your specific cabinet. Up/Down In/Out Left/Right Silcone Pads: Attach silicone pads (BB) on the top and bottom corners of each door. Page 9/9...

  • Page 10: Care And Maintenance

    Care & Maintenance To keep the product clean & shining, follow the steps below. 1. For normal spills, a damp cloth is sufficient. Dry the surface immediately. 2. Cabinets can be cleaned with most general purpose household cleaners. 3. Do not use caustic agents and/or abrasive scrubbers, or oven cleaners.
