- Page 1 Server Quick Installation Guide IDS-T16100-RM Series 2.2.0.10 Information in this document is subject to change without notice. © Copyright 2025, DIGIEVER Corporation. All rights reserved.
-
Page 2: Table Of Contents
Hardware Description................. 5 Hard Disk Installation ................... 6 Connection to DIGIEVER iSCSI Server ............7 Quick Configuration ................. 11 Appendix ......................12 LED Indicators on Front Panel ................ 12 LED Indicators at Rear Panel ................. 13... -
Page 3: Safety Notice
Quick Installation Guide Thank you for choosing DIGIEVER iSCSI Server (the Server). The following quick guide will lead you to complete the installation and configuration of the product. Please read the following description carefully. Safety Notice The following safety precautions will increase the life of the product. Follow all precautions and instructions. -
Page 4: Pre-Installation Notice
Compatibility of hard disk with the Server 1 slotted screwdriver and 1 Philips screwdriver *For hard disk compatibility, please check our website https://www.digiever.com/resource/Documents/CompatibleList/HDD/hdd_compatible_list.p System Requirements Remote PC The following are minimum system requirements for a personal computer to operate the Server in better performance: ... -
Page 5: Package Contents
Package Contents iSCSI Server Power Cord Ethernet Cable Screw Bag... -
Page 6: Hardware Description
Hardware Description Front View Rear View HDD LED indicator Network LED indicator: LAN 1, LAN 2 Power LED indicator One-touch backup button with LED indicator 2 x USB3.2 Gen 1x1 ports (Front) 6~21. HDD 1 to HDD 16 Reset button Digital Input/Digital Output (4-in, 4-out) Max24V, DI_GND, DI-4, DI-3, DI-2, DI-1, OCOM, DO4, DO3, DO2, DO1 2 x 2.5 Gigabit Lan ports... -
Page 7: Hard Disk Installation
Hard Disk Installation Please follow the steps as illustrated below to install the hardware: Take out the disk tray from the Connect the Ethernet cable to the Server. port of 2.5 Gigabit LAN. Connect the power cord to power ... -
Page 8: Connection To Digiever Iscsi Server
Connection to DIGIEVER iSCSI Server There are 3 methods to connect to the Server: Local display via HDMI connection Connect to the Server through computer in local network environment Web browser Install NVR Search to quickly find the Server in the local network... - Page 9 Connect to the Server through computer in local network environment Web Browser (Microsoft Edge, Chrome, Firefox, Opera, Safari) Step 1. Connect the Server to the local network (router or switch) Step 2. Enter the Server’s IP address in the web browser. Note: There are 2 methods to set network: Obtain an IP address automatically (System Default) ...
- Page 10 Install NVR Search to quickly find the Server in the local network Step 1. Please download NVR Search from official website (or request from our sales team) and install it to client’s computer. Step 2. Follow the instructions to install and the NVR Search will run automatically.
- Page 11 Connect the computer to the Server directly If you need to use a computer to set up the Server in a non-networked environment, you can use the docking method. Step 1. Please connect the Server and computer via LAN cable. Step 2.
-
Page 12: Quick Configuration
Quick Configuration After login, the system will direct you to set Quick Configuration in 5 steps. Follow the instructions of the Overview of wizard to complete the system setup. Please refer to iSCSI Server User Manual 2.4.6 iSCSI for setup iSCSI Target/LUN to iSCSI initiator. -
Page 13: Appendix
Appendix LED Indicators on Front Panel LED Color & Status Indicate LAN Link is not established Orange LAN Link is established Orange blinking LAN is being accessed Hard disk drive device is not established 1. Hard disk drive is ready to be accessed HDD1 2. -
Page 14: Led Indicators At Rear Panel
LED Indicators at Rear Panel LED Position LED/State Indicate LAN Link is not established LAN1 Link/Activity Yellow LAN Link is established LAN2 (Right LED) Yellow Blinking LAN activity is occurring 10Mbps connection or no connection LAN1 Speed 100Mbps connection LAN2 (Left LED) Green 1000Mbps connection...
