  • Page 1 Server Quick Installation Guide IDS-T16000-RM Series 2.2.0.8 Information in this document is subject to change without notice. © Copyright 2024, DIGIEVER Corporation. All rights reserved.
  • Page 2: Table Of Contents

    Package Contents ..................4  Hardware Description ..................5  Hard Disk Installation ..................6  Connection to DIGIEVER iSCSI Server ............7  Quick Configuration ..................9 Appendix......................11 LED Indicators on Front Panel................11 LED Indicators at Rear Panel ................12...
  • Page 3: Safety Notice

    Quick Installation Guide Thank you for choosing DIGIEVER iSCSI Server (the Server). The following quick guide will lead you to complete the installation and configuration of the product. Please read the following description carefully.  Safety Notice The following safety precautions will increase the life of the product. Follow all precautions and instructions.
  • Page 4: Pre-Installation Notice

     1 slotted screwdriver and 1 Philips screwdriver  *For Hard disk compatibility, please check our website https://www.digiever.com/resource/Documents/CompatibleList/HDD/hdd_compatible_list.p  Remote PC System Requirements The following are minimum system requirements for a personal computer to operate the Server in better performance: Operating System ...
  • Page 5: Package Contents

     Package Contents  iSCSI Server  Power Cord  Ethernet Cable  Screw Bag  Product CD...
  • Page 6: Hardware Description

     Hardware Description Front View Rear View HDD LED indicator Network LED indicator: LAN 1, LAN 2 Power LED indicator One-touch backup button with LED indicator 2 x USB3.2 Gen 1x1 ports (Front) 6~21. HDD 1 to HDD 16 Reset button Digital Input/Digital Output (4-in, 4-out) Max24V, DI_GND, DI-4, DI-3, DI-2, DI-1, OCOM, DO4, DO3, DO2, DO1 2 x 2.5 Gigabit LAN ports...
  • Page 7: Hard Disk Installation

     Hard Disk Installation Please follow the steps as illustrated below to install the hardware:  Take out the disk tray from the  Connect the Ethernet cable to Server. the port of 2.5 Gigabit LAN.  Connect the power cord to ...
  • Page 8: Connection To Digiever Iscsi Server

     Connection to DIGIEVER iSCSI Server Please insert the product CD-ROM on a PC to install NVR Search. Finally, you can start Quick Configuration on a web page.  Install NVR Search for finding the Server in the network. ...
  • Page 9  Connect to the iSCSI Server 1. Connect to the Server After setting the NVR Search, the user can connect to the monitoring page by the following two options: NVR Search Once you click “Connect” or double click the selected Server list, the web browser will pop up automatically.
  • Page 10: Quick Configuration

    2. Enter a user name and password Log in the Server with the default administrator account (user name: admin, password: admin).  Quick Configuration After login, the system will direct you to set Quick Configuration in 5 steps. Follow the instructions of the Overview of wizard to complete the system setup. Once the five steps of Quick Configuration are completed, the window will show the completed status.
  • Page 11 You can click “Back” to return to the previous steps to modify the setup or click “Finish”. You have successfully installed the iSCSI Server. Congratulations!
  • Page 12: Appendix

    Appendix LED Indicators on Front Panel LED Color & Indicate Status LAN Link is not established Orange LAN Link is established Orange blinking LAN is being accessed Hard disk drive device is not established 1. Hard disk drive is ready to be accessed HDD1 2.
  • Page 13: Led Indicators At Rear Panel

    LED Indicators at Rear Panel LED Position LED/State Indicate LAN Link is not established LAN1 Link/Activity Yellow LAN Link is established LAN2 (Right LED) Yellow Blinking LAN activity is occurring 10Mbps connection or no connection LAN1 Speed 100Mbps connection LAN2 (Left LED) Green 1000Mbps connection...
