Tecno POP 6 Manual

Explosion diagram specification

  1. TP/LCM module
  2. Front housing module
  3. Indicator light guide
  4. Front CAM sealed rubber
  5. P/L sensor light guide
  6. Front CAM pressured foam
  7. Main CAM pressured foam
  8. Front flash light guide
  9. T-card sealed foam
  10. P/L sensor mylar
  11. Receiver dust gauze
  12. BB shielding copper foil
  13. Receiver sealed foam
  14. Main CAM conductive copper foil
  15. Front CAM module
  16. Side key FPC module
  17. T-card pinhole sealed rubber
  18. Main CAM
  19. Vice CAM
  20. Pinhole sealed rubber adhesive
  21. Receiver
  22. Main PCBA board
  23. G-sensor shielding can
  24. RF shielding can
  25. PDN shielding can
  26. BB shielding can
  27. WCN shielding can
  28. Fingerprint module
  29. Screw to lock main PCBA board
  30. Flash light guide sealed foam
  31. RF shielding copper foil
  32. Main PCBA connector sealed foam
  1. Front CAM conductive sponge
  2. Vice CAM sealed foam
  3. Flash light guide adhesive
  4. Main CAM sealed foam
  5. Fingerprint thermolytic copper foil
  6. Main PCBA connector pressured foam
  7. Fingerprint pressured foam
  8. Vice CAM pressured foam
  9. Fingerprint conductive foam
  10. Battery connector pressured foam
  11. Fingerprint adhesive
  12. Upper rear housing
  13. Rear CAM lens adhesive
  14. Rear flash housing
  15. Rear CAM lens
  16. Screws to lock upper rear housing
  17. Battery housing sealed foam
  18. Fingerprint sealed foam
  19. Battery DECO adhesive
  20. Battery DECO sealed foam
  21. LTE antenna and GPRS antenna
  22. Battery graphite
  23. SIM card
  24. SIde key
  25. Battery housing
  26. Battery DECO
  27. Main antenna
  28. Screws to lock lower rear housing
  29. Speaker box dust gauze foam
  30. Speaker anti-magnetic steel
  31. Speaker anti-magnetic steel adhesive
  32. Lower rear housing
  33. Sub-PCBA connector pressured foam
  34. Speaker sealed foam
  35. Sub-PCBA connector sealed foam
  36. Screw to lock sub-PCBA board
  37. Speaker
  38. Coaxial cable
  39. Sub-PCBA board
  40. Battery
  41. Vibration motor
  42. Speaker connector FPC
  43. Speaker box sealed foam
  44. Mic sealed foam
  45. Mic sealed rubber adhesive
  46. Battery adhesive
  47. Mic sealed rubber
  48. Sub-PCBA conductive adhesive
  49. Micro-USB rubber
  50. Phone jack rubber

Know your phone

Know your phone

  1. Front camera
  2. Volume + key
  3. Volume - key
  4. Power key

SIM/SD card installation

SIM/SD card installation

  1. Power off mobile.
  2. Refer to the following picture for SIM / SD card installation.

Charging the phone

You can charge your device using a charger or by connecting it to the computer using a USB cable (comes with the phone).
Charging the phone

  1. Please remind the front and back of the plug.
  2. Use only TECNO charger and cables. Other chargers or cables may damage the device. This will invalidate your phone warranty.
