DISASSEMBLY INSTRUCTIONS

<Detaching method of the terminal with locking mechanism>
The terminal which has the locking mechanism can be detached as shown below.
There are 2 types of the terminal with locking mechanism.
The terminal without locking mechanism can be detached by pulling it out.
Check the shape of the terminal before detaching.
(1) Slide the sleeve and check if there is a locking lever or not.
Sleeve
Locking lever
11-1. MSZ-EX09NLW
MSZ-EX09NLB
MSZ-EX09NLS
NOTE: Turn OFF power supply before disassembly.
OPERATING PROCEDURE
1. Removing the panel
(1) Remove the horizontal vanes.
(2) Remove the screw caps of the panel. Remove the
screws of the panel.
(3) Unhook the lower part ( ) of the panel.
(4) First, hold the lower part of the right end of the panel,
and hold the lower part of the left end of the panel.
(5) Pull the panel slightly toward you, and then remove
the panel by pushing it upward.
OBD956
Slide the sleeve.
Pull the terminal while
pushing the locking lever.
MSZ-EX12NLW
MSZ-EX12NLB
MSZ-EX12NLS
(2) The terminal with this connector shown below
has the locking mechanism.
Hold the sleeve, and
pull out the terminal slowly.
Connector
MSZ-EX15NLW
MSZ-EX15NLB
MSZ-EX15NLS
: Indicates the visible parts in the photos/figures.
: Indicates the invisible parts in the photos/figures.
PHOTOS/FIGURES
Photo 1
A
Front panel
Screws of
the panel
33
MSZ-EX18NLW
MSZ-EX18NLB
MSZ-EX18NLS
Photo: MSZ-EX•NLB
Horizontal vanes
