- Page 2 Please read the manual before using the product and keep the manual for future use. SAFETY INFORMATION ● Movable parts are dangerous, so it is forbidden to put ngers、hair、clothes and other things into the space between the tire and the car body, to avoid being clamped by the rotating parts. ●...
- Page 3 FUNCTION DESCRIPTION Headlight Seat compartment light Right front lamp grille lamp Left front lamp High and low beam High and low beam lamps lamps Right turn signal Left turn signal Forward/backward Turn right/turn left Forward/backward Tail lights/turn signals/reversing lights Tail lights/turn signals/reversing lights Recharging hole: connect Type-C line Recharging hole: connect Type-C line Pair hole...
- Page 4 PREPARE FOR RUN Transmitter battery installation This remote uses AA battery or Ni MH battery, when the voltage is lower than 4.5V ± 0.2V, the LED starts ashing. Note: instructions for safe use of the replaceable battery of the remote control: 1.
- Page 5 Charging When the car is in power o status, it can be charged in the following two ways; (Please charge the RC car for the rst time you use.) Use the hidden Type-C port on the remote to charge the car. (Picture 1-3) Remote control output voltage and current:...
- Page 6 2. Insert the attached charging cable into the charging port of the car and connect the power supply for charging. (as picture shows) Tip: When the car is power on, it will not be charged when charging power is inserted. lf need charge the car, the car's power switch must be turned "OFF". The remote control car should be charged by an adult;...
- Page 7 Car startup: in the shutdown state, turn on the power switch (push to the "on" position), The vehicle starts up after the LED lights up for 1 second. If the front light of the car stays on, it indicates that it’s connected with the remote control. If the front light of the car is ashing, please check whether the power of remote control has been turned on.
- Page 8 OPERATION NOTE Note: If you’re the rst time to use the 1:76 RC car, please take a few minutes to read this statement carefully to get familiar with di erent features of this operation system. Functions Transmitter 6CH 10CH 2CH-TRIM 3CH-TRIM 4CH-TRIM 1CH-TRIM...
- Page 9 1CH (direction): Control left and right turns. 1CH-REV: Use the reverse steering switch to reverse the left and right directions. 2CH (throttle): Control the throttle to move forward, 2CH REV: Using the throttle reverse switch,Reverse brake, and backward (Brake lights, backup lights) the front and rear directions.
- Page 10 Remote control battery case When installing a new battery case for the remote control, pay attention to the positive and negative poles of the JST plug, do not plug it in backwards! Battery box 4x 1.5v (AA) 1.5v (AA) 1.5v (AA) 1.5v (AA) 1.5v (AA) Binding...
- Page 11 Car running settings Forward/speed up Left Right Throttle trigger: Control forward / brake /backward. ● Brake /Backward Steering wheel: Control left / right steering. ● 1CH/TRIM: When the steering wheel in the middle ● position, if the front wheel is not in a straight line, please adjust it with 1CH/TRIM “+”...
- Page 12 SPECIFICATION C50-T Product name Model 1: 76 RC Tractor Driving distance Scale 1:76 Driving time Slope angle 30° 40min Size 80x41x49.3mm Four-wheel drive Drive mode Proportional Proportional steering 3.7V、150mAh lithium battery steering Battery Note: The lithium battery is built-in and detachable...
- Page 13 PRODUCT PERFORMANCE FAILURE TABLE Product Name Product performance failure 1. The product cannot be turned on. 2. Cannot charge. 1: 76 RC Semi-Truck 3. Unable to operate. 4. Dysfunction. MAINTENANCE 1. Before using the product, please ensure that all components have been tightened, check and clear foreign matter in the gap between the wheel and chassis.
- Page 14 TROUBLESHOOTING Fault symptom Cause of failure Solutions Make sure that the product is in car 1. Distance is too far receiving mode.(The headlights ash). The tranmitter connection failed 2. Multicars pairing at the same time Check the wheels for foreign objects Foreign object between Freeze the wheels...
- Page 15 PRECAUTION ● The car contains lithium batteries. Disassembling, striking, squeezing or throwing the car into the re is prohibited. If severe swelling occurs, do not continue to use it. Do not place it in high-temperature environment. ● Due to the special feature of lithium batteries, overly high or low temperature will a ect the battery charge and discharge performance and battery life, so please do not use or store this product under environments such as high temperature, low temperature, high humidity or direct sunlight.
- Page 16 INSTALLATION OF SEMI-TRUCK 2. Then proceed downwards. 1. Insert the trailer bottom hook along the locking position. CONTAINER ACCESSORIES DIAGRAM...
- Page 17 ASSEMBLY METHOD OF CONTAINER ACCESSORIES...
- Page 18 General assembly drawing Tractor explosion diagram Bodyshell Bumper screw Car platform Upper shell Transmission gear set Spring Gearbox Rear-wheel Steering Assembly Bottom shell...
- Page 19 Explosion diagram of car shell 760251 760248 760250 760261 760249 760247 760255 760258 760252 760254 760262 760253 760052 760256 760257...
- Page 20 Tractor transmission shaft 760226 760241 760216 760227 760243 760217 760241 760006 Tractor rear wheel 760228 760218 760242 760245...
- Page 21 Tractor steering 760244 760236 760237 760234 760213 760238 760240 760214 760235 760228...
