Loepfe YARNMASTER ZENIT+ Instruction Manual

Hide thumbs Also See for YARNMASTER ZENIT+:
Table of Contents

Advertisement

Quick Links

Download this manual
YARNMASTER
ZENIT
®
Instruction Manual
Version 5.9.x.x / 10.2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YARNMASTER ZENIT+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Loepfe YARNMASTER ZENIT+

Summary of Contents for Loepfe YARNMASTER ZENIT+

  • Page 1 YARNMASTER ZENIT ® Instruction Manual Version 5.9.x.x / 10.2018...
  • Page 3 Instruction Manual to third parties – even in form of extracts – as well as the use and / or disclosure of the contents are not allowed without the written approval of Loepfe Brothers Ltd., except for internal purposes. YarnMaster is a registered trademark of Loepfe Brothers Ltd.

  • Page 5: Table Of Contents

    Table of Contents Table of Contents General Information on this Instruction Manual 1.1.1 General 1.1.2 Duty to Read this Manual 1.1.3 Availability of Instruction Manual 1.1.4 Loss of Instruction Manual Explanation of Symbols 1.2.1 Symbols 1.2.2 Signal Words 1.2.3 Information Liability 1.3.1 Information in this Manual...
  • Page 6 Table of Contents Product Description General Equipment Configuration 3.2.1 Central Unit LZE-V 3.2.2 Spindle Adapter (SA) Sensing Head YM ZENIT + 3.2.3 3.2.4 Sensing Head Display (7-Segment Display) Installation Connections LZE-V 3.4.1 Front 3.4.2 Rear Identification of Components / Article Description 3.5.1 Type Plates Clearer Functions / Clearer Variants...
  • Page 7 Table of Contents User Interface / Navigation 7.4.1 Menu Overview 7.4.2 Navigation Path 7.4.3 Selection Bar for Group / Spindle or Article 7.4.4 Data Selection Filter 7.4.5 Function Buttons 7.4.6 Other Symbols Language Selection Online Help Login / Access Level 7.7.1 Password Level 7.7.2...
  • Page 8 Table of Contents 7.13 Group Administration 7.13.1 General 7.13.2 Prepare Group 7.13.3 Start Group 7.13.4 Adjust 7.13.5 Adjustment with Fine Adjust Reset 7.13.6 Adjust for Group In Production 7.13.7 Stop Group 7.14 Settings > Group 7.14.1 Settings Group 7.14.2 Settings Optional 7.14.3 Data Acquisition 7.14.4 Reset Data 7.15 Messages / Alarms...
  • Page 9 Table of Contents 7.19.6 LabPack SFI 7.19.7 Trend 7.19.8 Length 7.19.9 Last Cut 7.20 Service > Diagnosis 7.20.1 TK Information 7.20.2 TK Parameter 7.20.3 Last Cut 7.20.4 Event (History) 7.20.5 Test Mode 7.20.6 TK Commands 7.20.7 User Activity 7.21 Service > System 7.21.1 System Information 7.21.2 Log Profile 7.21.3 Firmware Update...
  • Page 10 Table of Contents 8.5.3 Replace the Knife 8.5.4 Replace Yarn Guides 8.5.5 Replace the Sensing Head 8.5.6 Replace the Spindle Adapter (Machine-specific) 8.5.7 Monitor Calibration Dismantling and Disposal Dismantling Disposal 10 Spare Parts / Accessories 10.1 Safety 10.2 Ordering Information 10.3 Spare Parts 10.4 Accessories...

  • Page 11: General

    General General 1.1 Information on this Instruction Manual General 1.1.1 This Instruction Manual allows safe and efficient operation of yarn clearer system YarnMaster Zenit + . The basic prerequisite for safe working is compliance with all specified safety information and instructions in this Instruction Manual. Operation as prescribed and thorough maintenance of the yarn clearer system ensure optimum clearer performance, trouble-free operation as well as a high service life of the yarn clearer system.

  • Page 12: Explanation Of Symbols

    General 1.2 Explanation of In this Instruction Manual, safety information is marked with symbols and Symbols signal words which express the extent of the hazard. The safety information must be strictly observed to prevent accidents, personal injuries and damage to property. Symbols 1.2.1 General danger...

  • Page 13: Liability

    In addition to the contractually agreed obligations, the manufacturer's General Terms and Delivery Conditions are applicable. Technical Modifications 1.3.3 Loepfe Brothers Ltd. will not be liable for damage and accidents resulting from the following: ƒ Unauthorized conversion and modification of the yarn clearer system ƒ...

  • Page 15: Safety

    User and foreman are persons qualified and trained for operation and main- tenance of the yarn clearer system. ƒ Service technician The service technician is a Loepfe employee qualified and trained for ser- vicing the yarn clearer system or a person expressly named by Loepfe for this task.

  • Page 16: Use

    Risk of injuries and damage by unauthorized modifica- tion of the yarn clearer system! WARNING Z Conversions or modifications of the yarn clearer system must be agreed with Loepfe. The manufacturer will not be liable for damaged caused by unauthorized modification of the yarn clearer system.

  • Page 17: Electrostatic Charging

    Safety Electrostatic Charging 2.4.3 Electronic components and assemblies (printed circuit boards) are endangered by electrostatic charges! Possible damage when touching the components! ATTENTION Z Hold assemblies only at the edge. X Do NOT touch soldered connectors, pin contacts, printed circuits or electronic components. 2.5 Safety Devices (Emergency-stop Button) Yarn clearer system YarnMaster Zenit + is integrated in a winding machine and has no additional safety devices.

  • Page 19: Product Description

    Product Description Product Description 3.1 General Yarn clearer system YarnMaster Zenit + serves to clear yarn faults and for- eign matter as well as quality monitoring in the winding shop. It is installed in winding machines from various manufacturers. The collection of the yarn faults is based on the optical measuring principle. 3.2 Equipment Configuration Yarn clearer system YarnMaster Zenit + consists of the following compo- nents:...

  • Page 20: Spindle Adapter (Sa)

    Product Description Spindle Adapter (SA) 3.2.2 The spindle adapter is the interface between central unit, sensing heads and spindle for provision of the power supply of the sensing head and adaption of the connecting devices. Sensing Head YM ZENIT + 3.2.3 The complete processing and evaluation of the yarn signal takes place in sensing head YM ZENIT + .

  • Page 21: Sensing Head Display (7-Segment Display)

    Sensing Head Display Product Description Sensing Head Display Sensing Head Display (7-Segment Display) 3.2.4 Flashing display indicates ALARM. Flashing display indicates ALARM. The set number of repetitions of the respective clearer channel was reached. The set number of repetitions of the respective clearer channel was reached. D Cuts (TK Display Mode: Channel) Nep / Short / Long / Thin n.
  • Page 22 Product Description Sensing Head Display Splice Cuts Splice: Nep / Short / Long / Thin Jn. JS. JL. Jt. with class cut / without channel cut • • Cluster Cuts nC SC LC tC Nep- / Short- / Long- / Thin Cluster OffCount Cuts / Short OffCount Cuts Off Count + / –...
  • Page 23 Product Description Sensing Head Display F Cuts (TK Display Mode: Channel) Foreign Matter with bright / without dark • • F Cluster with bright / without dark • • OffColor with bright / without dark • • F Class Cuts (SIRO) (TK Display Mode: Class) F Classes S1 –...
  • Page 24 Sensing Head Display Product Description Yarn Count Difference Diameter difference ≤ +/-10% > +10% > -10% Textile Alarms Class Alarm Off Limit Alarm IPI Alarm Technical Alarms AL 0 alternating Technical Alarm AL 1 alternating Cutter supply or coil failure AL 2 alternating Internal power supply failure TK...
  • Page 25 Product Description Sensing Head Display Spindle locked, group not started 8. 8 . Reset Zeroing (ECR) Update TK Firmware...

  • Page 26: Installation

    Variant 2 External power supply 90–264 V AC Variant 3 External power supply 24 V DC Central unit (LZE-V Faceless) LAN connection (crossover cable) Loepfe 2-wire-bus (L2B) Spindle Spindle Loepfe 2-wire-bus (L2B) computer adapter (SA) Tastkopf Sensing head (TK) Sensing head cable All cable connections are pluggable.

  • Page 27: Connections Lze-V

    ATTENTION Threaded connection Protective ground This separate grounding point must be connected with the protective ground! DANGER LOEPFE 1 Sub-D, 9-pole connector Connection of Loepfe 2-wire bus (L2B) LED green / red Power supply OK LED red Compact-flash drive active...

  • Page 28: Identification Of Components / Article Description

    Consecutive serial number TK YM ZENIT + XXX Calendar week / year xxxxxx xxxx xxxx OEM article number xxx-xxx.xxx 50xxxxxxX Revision Loepfe article number State the data on the product type plates when ordering spare parts or when you require technical support.

  • Page 29: Clearer Functions / Clearer Variants

    Product Description 3.6 Clearer Functions / Clearer Variants P Clearing ƒ Clearing of synthetic foreign matter PP PE etc. F Clearing ƒ Clearing and classification of foreign matter, dark and bright ƒ Foreign matter clusters dark and bright Feature Pack (Option) ƒ...

  • Page 31: Technical Data

    Technical Data Technical Data System Concept Modular, integrated in winding machine / Components individually replaceable / Power supply by winding machine Central unit One central unit per machine with serial connection to sensing heads Operation Setting of all parameters via touchscreen Operating temperature + 5°...
  • Page 32 Technical Data Channel Clearing Channel / Splice Channel Diameter limit for neps Diameter limit for short faults Limit for short fault length 1.0 cm 10 cm Diameter limit for long faults 1.04 Limit for long fault length 6.0 cm 200 cm –D Limit of diameter decrease - 6%...
  • Page 33 Technical Data Yarn Monitoring Yarn Count Channel Diameter deviation ±3% ±44% Reference length 10 m 50 m Short Count Channel Diameter deviation ±3% ±44% Reference length 32 m Cluster (Fault Accumulations) Diameter Nep cluster 7.00 Short cluster 1.10 4.00 Long cluster 1.04 2.00 Thin cluster...
  • Page 34 Technical Data LabPack (Option) Surface Index Channel (SFI/D) Moving or constant reference 25.0 Limits +/- (maximum deviation from reference value) ±5% ±40% Alarm Limit Check Length 10 / 80 m Automatic locking when reaching the alarm limit in the SFI / D channel Variable CV Channel (VCV) Limits +/- (maximum deviation from mean value) ±5%...

  • Page 35: Transport, Storage

    Transport, Storage Transport, Storage 5.1 Transport For transport to the “first destination”, the equipment parts are packaged according to the expected transport and storage conditions. For further transport or a possible return, the equipment parts must be packed so that they are protected from mechanical damage and humidity. The packaging of circuit boards must be such that they are protected from physical damage, electrostatic discharge and absorption of humidity (ESD packaging).

  • Page 37: Start-Up

    6.2 Assembly and Initial Start-up Loepfe Brothers Ltd. are responsible for the initial start-up of the yarn clearer system. The yarn clearer system is handed over to the customer ready for operation.

  • Page 39: Operation Of Lze-V

    Operation of LZE-V Operation of LZE-V 7.1 General The YM Zenit + yarn clearer system is controlled for all winding machine types via central unit LZE-V. Machine-specific differences in operation or in the settings are possible and have been stated accordingly in the instructions. All clearer functions are described in this Instruction Manual.

  • Page 40: Central Unit Lze-V

    The yarn clearer system Zenit + does not have a separate control unit. The clearer is operated via the touch panel of the winding machine. Switch between Loepfe clearer operation and Savio machine operation by tapping the Loepfe logo in the top left corner. Separate Loepfe USB interface on the winding machine.

  • Page 41: User Interface / Navigation

    Language selection Online help Action buttons / function buttons Connection status (Ethernet / MillMaster TOP / Remote / Data Exist) Active user level / logged on user Date / time Software version Switch-over Loepfe / Savio GUI (only LZE-V Faceless)

  • Page 42: Menu Overview

    Operation of LZE-V Menu Overview 7.4.1 DATA Dashboard Overview Detailed view > Alarms  Monitoring Overview Cuts  Monitoring Overview Trend  Quality > Trend Off Limits  Monitoring Overview Monitoring Overview > Detailed view Cuts NSLT OffCount Cluster Splice Foreign Matter Synth.
  • Page 43 Operation of LZE-V Group List (Group Administration) Overview (Group Parameters) >> Settings Group Settings Optional Data Acquisition Reset Data IPI Correction Factors Machine Overview > Detailed view Shift Calendar  Base Settings  Default Group Settings  Default Data Acquisition ...

  • Page 44: Navigation Path

    Operation of LZE-V Navigation Path 7.4.2 Main menu > Menu > Group (Article): Spindle Overview of monitoring data: Group 1 (Article “TITLIS”): Spindle 8 Main menu > Menu > Article Overview of article settings for article “TITLIS” Selection Bar for 7.4.3 Group / Spindle or Article Selected: Group 1 (Settings >...

  • Page 45: Function Buttons

    Operation of LZE-V Function Buttons 7.4.5 Language selection Copy article Login / access level Start lot / group Online help Stop lot / group Adjust List of messages requiring intervention (groups / spindles in production) Create screenshot / save on USB stick Reset monitoring data / quality data Create reports / save on USB stick Change password...

  • Page 46: Language Selection

    Operation of LZE-V 7.5 Language Selection The desired operator language can be selected. 7.6 Online Help Help Clicking the Help button displays the Help window with information on the current menu window. Click the Help button to return to the start of the page. E.g., menu: Data >...

  • Page 47: Login / Access Level

    ƒ Operator ƒ Foreman ƒ Service (only for Loepfe service personnel) A password is not required for user “Guest”. User 7.7.2 Users “Foreman”, “Operator” and “Service” have been defined by default. Other users (max. 88) can be determined in menu Setup >...

  • Page 48: Change Password

    Operation of LZE-V Change Password 7.7.5 During the startup, the operator password is “47114711”, the foreman password is “12911291”. It is recommended to change these passwords after startup and in regular intervals!

  • Page 49: Edit Settings

    Operation of LZE-V 7.8 Edit Settings To edit settings, the input mode / edit mode must be activated (password level Foreman). The input fields are now active. Tap the settings individually and edit them using the keypad or selection lists. Return to the overview with the Back button to change more settings or to save the changed settings.

  • Page 50: Save Data

    The respective function buttons become active when the USB stick is inserted. Make sure that the USB stick is free from viruses! LOEPFE assumes no liability for possible damage on the system (loss of data etc.,) which could be caused by viruses!
  • Page 51 Operation of LZE-V ATTENTION: Files with the same name on the USB stick are overwritten without any further confirmation prompt! Import The data selected in the list can be imported from the USB stick to the central unit. 1. Select the required data and import with 2.

  • Page 52: Settings > Machine

    Operation of LZE-V 7.10 Settings > Machine Machine Menu Level Overview Tapping a settings block (e.g., Base Settings) opens the detailed view. Detailed View / Edit Window The settings can be edited. Base Settings 7.10.1 The yarn clearer system is configured with these settings. Machine Type The machine type is displayed.

  • Page 53: Default Group Settings

    Operation of LZE-V Default Group Settings 7.10.2 Base settings for all groups in the “Defined” status. Drum Pulse Length The standard value is entered automatically based on the machine type (Base Settings). Reduction Fine Adjust Many cuts can be registered after an adjust with very sensitive settings in the yarn count channel or cluster channel.

  • Page 54: Default Data Acquisition

    Operation of LZE-V Suction after Adjust Suctioning off 25 m after adjustment can be switched on or off. TK Display Mode The TK Display Mode can be selected (class / cut type). Drift Limit Fine Adjust Continuous Input of allowed min. drift difference during the continuous fine adjust mode can be switched off or activated with the selected value.

  • Page 55: Shift Calendar

    Operation of LZE-V Shift Calendar 7.10.4 The begin of the individual shifts per weekday (max. 6 shifts per day) is defined in the Shift calendar. When a MillMaster System is connected, the shift calendar can be determined only there. Shift Cycles A maximum of 7 different shift cycles can be predefined: ƒ...

  • Page 56: Article Administration

    Operation of LZE-V 7.11 Article Administration Settings > Article General 7.11.1 An article with assigned clearer and quality parameters determines how the yarn is to be cleared and which quality is to be guaranteed. 99 articles with the assigned clearer settings can be managed. The articles marked are articles predefined in the fac- tory.

  • Page 57: Create / Change Article

    Operation of LZE-V Create / Change Article 7.11.2 1. Select the article. 2. Activate the Edit mode. 3. Change settings and confirm. 4. Return to the overview 5. Repeat this action until all setting blocks have been defined. – All changed setting blocks are highlighted yellow in the overview. 6.

  • Page 58: Copy Article

    Operation of LZE-V Copy Article 7.11.3 1. Select an article (e.g., CO NE40 TOP9). 2. Clicking the Copy button opens the Copy window. 3. Select the target article (existing settings are overwritten during copying). 4. Enter new article name (e.g. DOM) if required. 5.

  • Page 59: Settings > Article

    Operation of LZE-V 7.12 Settings > Article Properties 7.12.1 The article properties are defined with these settings. Article Name of article (max. 20 characters) Description Description of article (max. 20 characters) Yarn Count Yarn count of article Material Material of article (max.
  • Page 60 Operation of LZE-V Alarm Limit Bobbins with frequent, similar faults can be detected with this setting. The spindle is blocked as soon as the set alarm limits of the respective cut type per bobbin have been reached. outside Clearing Curve within The displayed clearing curve (red) is defined by the setting of the clearer channels.

  • Page 61: Splice Channel / Class

    Operation of LZE-V Splice Channel / Class Splice Channel 7.12.3 The limit values for D yarn clearing (clearing curve) are determined by setting the splice clearer channels for every spindle start according to the set splice control length. Clearing Clearing can be switched on or off. Diameter limit value for neps Diameter limit value for short faults Limit value for short fault length...

  • Page 62: Foreign Matter

    Operation of LZE-V Upper Yarn Monitoring Upper yarn detection can be switched on or off. Limit In order to reliably detect a double-yarn of the cone, the limit value must not be set higher than 1.6. This setting should be checked and perhaps modified when the yarn material is changed.
  • Page 63 Operation of LZE-V Alarm Limit Bobbins with frequent, similar faults can be detected with this setting. The spindle is blocked as soon as the set alarm limits of the respective cut type per bobbin have been reached. The respective fault length is automatically drawn off the cone after every F cluster cut.

  • Page 64: Yarn Count

    Operation of LZE-V Yarn Count 7.12.5 These settings allow the acquisition of false bobbins or yarn with a larger off- count difference. OffCount / Short OffCount Clearing Clearing after “OffCount / Short OffCount” can be separately switched on or off. + DiaDiff / –...

  • Page 65: Cluster

    Operation of LZE-V Cluster 7.12.6 With the cluster settings, fault clusters can be detected which, as single faults, are usually not considered disturbing. If, however, the faults are repeated multiple times within a short distance, they are disturbing. To acquire periodic faults, separate cluster curves are defined for the short, long and thin faults.

  • Page 66: P Settings

    Operation of LZE-V In Production The actual faults can be displayed for the groups in production with the same article. Curves The clearing curves D channel, nep cluster, short cluster, long / thin cluster can be separately shown / hidden. P Settings 7.12.7 The acquisition of synthetic foreign matter, e.g.
  • Page 67 Operation of LZE-V P Configuration Clearing P clearing can be switched on or off. Alarm Limit Bobbins with frequent, similar faults can be detected with this setting. The spindle is blocked as soon as the set alarm limits of the respective cut type per bobbin have been reached.

  • Page 68: Labpack

    Operation of LZE-V LabPack SFI/D 7.12.8 An upper and lower limit value is selected relative to the mean SFI/D value of the yarn (reference). If the current SFI/D value exceeds this limit, the clearer makes a cut and the defective yarn is drawn off the cone. Clearing Clearing can be switched on or off.
  • Page 69 Operation of LZE-V The clearer calculates continuously the VCV values from the yarn pieces with the set check length and compares these against their sliding average. Clearing Clearing can be switched on or off. + Limits / – Limit (%) + / –...

  • Page 70: Off Limit Alarm

    Operation of LZE-V Off Limit Alarm 7.12.9 Allows monitoring of textile / non-textile cutting types and provides different visualization and / or intervention options for selection, depending on the indi- vidually selected action. Action Block When the set limit value is exceeded, the spindle / group triggers an alarm. Message When the set limit value is exceeded, this is displayed in the message window.

  • Page 71: Ipi Alarm

    Operation of LZE-V IPI Alarm 7.12.11 Allows monitoring of IPI diameter / length and provides different visualization and / or intervention options for selection, depending on the individually selected action. IPI Groups Input of absolute IPI limit values relative to the group. To support adjustment, the events occurring for the current group are displayed.

  • Page 72: Off Standard Bobbins

    Operation of LZE-V In Production IPI events can be displayed for the groups which are in production with the same article. Off Standard Bobbins Limit 7.12.12 Average Yarn Breaks Allows to detect bobbins with an increased number of yarn breaks. Alarm Limit Text.

  • Page 73: Group Administration

    Operation of LZE-V 7.13 Group Administration Settings > Group General 7.13.1 The complete lot control is performed via the Group menu: ƒ Prepare the group ƒ Start / stop group (lot) ƒ Perform adjustment / fine adjustment Menu Level Group List The list provides an overview of the groups and their current status.

  • Page 74: Start Group

    Operation of LZE-V Start Group 7.13.3 A group cannot be started when the spindle range overlaps another group in production. An adjustment is performed (the current yarn count or yarn structure is read in and the basic value determined) at every group start. If necessary, the fine adjust values can be reset for all sensing heads of this group.

  • Page 75: Adjustment With Fine Adjust Reset

    Operation of LZE-V Adjustment with Fine Adjust Reset 7.13.5 If large deviations (> ± 10%) are determined for the diam- eter basis value between the individual spindles in the chart (“Diagnosis > TK Parameter” menu), it is advisable to reset the fine adjust values.

  • Page 76: Adjust For Group In Production

    Operation of LZE-V Adjust for Group In Production 7.13.6 All spindles of the group should be stopped before an adjustment can be performed for a group in production. The following can be required for a group in production: ƒ to perform an adjustment again. ƒ...

  • Page 77: Settings > Group

    Operation of LZE-V 7.14 Settings > Group Settings Group 7.14.1 First / Last Spindle Spindle range (first / last spindle of group). Pilot Spindles Number of pilot spindles (standard setting = 10% of spindles of this group). Sensing Head Type Installed Sensing head type (D, DF, DFP).

  • Page 78: Settings Optional

    Operation of LZE-V Settings Optional 7.14.2 These settings are equivalent to the standard settings (Machine menu) and can be individually adapted per group as required. Drum Pulse Length The standard value is entered automatically based on the machine type (base settings).

  • Page 79: Data Acquisition

    Operation of LZE-V Suction after Adjust Suctioning off 25 m after adjustment can be switched on or off. TK Display Mode The TK Display Mode can be selected (class / cut type). Drift Limit Fine Adjust Continuous Input of allowed min. drift difference during the continuous fine adjust mode can be switched off or activated with the selected value.

  • Page 80: Messages / Alarms

    Operation of LZE-V 7.15 Messages / Alarms Last Messages 7.15.1 The last message is displayed. Tapping displays a list with the 20 last messages. Alarm Levels Warning Message not requiring intervention Error Message requiring intervention Alarm Messages requiring intervention Message which prevents further use of the Fatal LZE and cannot be acknowledged Messages Requiring Intervention...

  • Page 81: Data > Data Selection Filter

    Operation of LZE-V 7.16 Data > Data Selection Filter Production 7.16.1 The cut / quality data are displayed according to the selected option (e.g., the last 100 km). ƒ First: With the “First” setting, the acquisition of monitoring and classifica- tion data of the current production is stopped at e.g.

  • Page 82: Data > Dashboard

    Operation of LZE-V 7.17 Data > Dashboard The dashboard allows a quick overview of important system variables. In this context, preconfigured alarm and cut evaluations, on the one hand, and user- configurable trend and offline evaluations, on the other hand, are shown. Alarms Display of all current alarms of the selected group / spindle.

  • Page 83: Data > Monitoring

    Operation of LZE-V 7.18 Data > Monitoring Shows the sum of all events with respect to the wound length (km), relative to the selected data selection filter. This data can be optionally viewed per spindle or group. Cuts 7.18.1 Total Cuts Total of textile cuts (D / F / P cuts) D Cuts, F Cuts, P Cuts Yarn fault cuts, Foreign matter cuts, Synthetic foreign matter cuts...

  • Page 84: Cluster

    Operation of LZE-V Cluster 7.18.4 Nep Cluster Cuts Nep cluster cuts Short Cluster Cuts Short cluster cuts Long Cluster Cuts Long cluster cuts Thin Cluster Cuts Thin cluster cuts Splice Splice 7.18.5 Sum of all wound splices Splice Cuts Splice cuts Splice Repetitions Splice repetitions caused by splices that did not occur (e.g., no upper/lower yarn, yarn breaks, splicer malfunction).

  • Page 85: Off Standard Bobbins

    Operation of LZE-V Off Standard Bobbins 7.18.8 Total All off standard bobbins relative to the total number of bobbin changes Total Textile Cut Alarms Off standard bobbins caused by textile cut alarms relative to the total number of bobbin changes Total Yarn Breaks Off standard bobbins caused by an increased number of yarn breaks relative to the total number of bobbin changes...
  • Page 86 Operation of LZE-V Detailed View of Monitoring Data Overview Tapping a data block (e.g., Cuts) opens the detailed view. Detailed View Data Window The total as well as the average value of the selected data are displayed and shown graphically in the chart. Total value Average value Chart...

  • Page 87: Last Cut

    Operation of LZE-V Last Cut 7.18.15 Display of last cut event (cut type, fault classification and possible alarms). Tapping displays the last 5 cut events (Diagnosis). Display Cause N / S / L / T Channel Channel cut (Nep, Short, Long, Thin) N / S / L / T Class Class cut (Nep, Short, Long, Thin) N / S / L / T Splice Channel...

  • Page 88: Data > Quality

    Operation of LZE-V 7.19 Data > Quality An optimum setting of the clearer parameters can be performed very quickly and efficiently using the detailed information concerning the number as well as the length and thickness of the yarn faults. YarnMaster Zenit + classifies all yarn faults of every group and spindle. D Class 7.19.1 Yarn faults in the yarn to be cleared are entered in the respective fault classes...
  • Page 89 Operation of LZE-V Detailed View Classification Data Overview Class) Tapping a data block (e.g., opens the detailed view. Detailed View Classification Data The numbers in the individual class fields indicate the cut and fault sums which remained in the yarn for the corresponding classes relative to the wound length which is displayed on the screen.

  • Page 90: Labpack Ipi

    Operation of LZE-V LabPack IPI Imperfections IPI 7.19.5 The classical yarn clearing in the winding process is designed for the record- ing of thick/thin places in the yarn which are defined according to the respec- tive fault classes. In yarn fault classification, “rare” and “frequent” yarn faults are distinguished. The general rule is that the shorter the fault length or the smaller the diameter variation, the more frequent the events.
  • Page 91 Operation of LZE-V SFI / D (LabPack) The SFI / D is the sum signal of the fibres protruding from the core diameter of the yarn. The core diameter of the yarn is fixed at 100%.The SFI/D numbers therefore refer to 100. Surface index SFI / D allows to detect off-standard bobbins (e.g., sporadic thin or thick places which normally do not disturb, but have a negative effect on the fabric appearance when too many occur) and, if necessary, remove the...

  • Page 92: Trend

    Operation of LZE-V Trend Trend Settings 7.19.7 A total of 5 trend settings can be defined. The desired criterion can be determined using a selection list. Each shift group can be assigned a color. The trend settings can be defined for a group and also for an individual spindle.

  • Page 93: Service > Diagnosis

    Operation of LZE-V 7.20 Service > Diagnosis TK Information 7.20.1 TK Information Information concerning the installed sensing heads. TK Information Clicking opens the Diagram view. The status of the individual spindles can be checked in the diagram. TK Alarms Overview of registered events.

  • Page 94: Tk Parameter

    Operation of LZE-V TK Parameter 7.20.2 Detailed information for authorized personnel (exception: Fine Adjust Parameter). Fine Adjust Parameter Clicking Fine Adjust Parameter opens the Diagram view. The values of the indi- vidual spindles can be checked in the diagram. Value of selected spindle Average value of all spindles If large deviations (>...

  • Page 95: Last Cut

    Operation of LZE-V Spindle Adjustment A single spindle adjustment should be performed when a sensing head of a current group is replaced or a large diameter deviation (> ± 10%) was deter- mined for a spindle. 1. Select the affected spindle. 2.

  • Page 96: Test Mode

    Operation of LZE-V Test Mode 7.20.5 The Test mode is available for all cutting types. Several class fields (per D and F class) can be activated at the same time. Activate the Test mode 1. Activate the Edit mode with 2.

  • Page 97: Tk Commands

    Operation of LZE-V TK Commands 7.20.6 Only for authorized personnel (Service password). User Activity 7.20.7 The list of user activities can be filtered according to date / time, user and activity.

  • Page 98: Service > System

    Operation of LZE-V 7.21 Service > System System Information 7.21.1 Log Profile 7.21.2 Only for authorized personnel (Service password). Firmware Update 7.21.3 Master Module, Bootloader and Firmware Versions The versions shown in the “Master Module” field and in the “Spindles” field must match the versions shown in the “Firmware Archive”...
  • Page 99 Operation of LZE-V Perform the firmware update If the versions do not match (e.g., after a master module or a sensing head exchange), the corresponding firmware update must be performed: 1. Activate the edit mode with 2. Start the Master Module update with –...

  • Page 100: Software Update Lze

    Operation of LZE-V Software Update LZE 7.21.4 Only for authorized personnel (Service password). System Backup 7.21.5 Assistant for creation of a backup copy of the current system configuration (e.g., before a reset to factory settings). System Restore 7.21.6 Only for authorized personnel (Service password). Maintenance / Service 7.21.7 Only for authorized personnel (Service password).

  • Page 101: Service > Setup

    7.22.2 The associated option code is required to activate the software options; this code must be requested from Loepfe. For this purpose, Loepfe requires the request key shown in the Software Options menu. It is recommended to keep a print-out of the option code!

  • Page 102: Reports

    Operation of LZE-V Reports 7.22.3 Configuration of Shift reports: ƒ Completed Shift report (completed shifts) ƒ Intermediate report (current shift) – The setting, monitoring or quality data can be printed individually or combined per Shift report. – In addition, 5 spindle parameters each can be selected. –...

  • Page 103: Factory Reset

    Operation of LZE-V Factory Reset 7.22.5 The factory reset requires password: “MAKERESET” or the Service pass- word. Restart 7.22.6 The central unit is restarted. Date and Time 7.22.7 Setting: 1. Enter date / day / hour / minutes. 2. Save date and time with “Save date and time settings”...

  • Page 105: Inspection And Maintenance

    The information included in this chapter serves for analysis and possible clear- ance of occurred malfunctions. If the described actions do not contribute to fault clearance, we recommend to contact the Loepfe Service Station. 8.2 Safety Only authorized and trained persons are allowed to perform the work described in this chapter.

  • Page 106: Fault Display

    Inspection and Maintenance 8.3 Fault Display Messages and alarms are displayed as follows: Message Window The respective last message is displayed in the Message window.Tapping the Message window displays the last 20 messages. Messages Requiring Messages requiring intervention are displayed in a popup window. These Intervention messages must be acknowledged.

  • Page 107: Messages

    Inspection and Maintenance 8.4 Messages Procedure for messages requiring intervention: 1. Perform suggested measures for fault clearance. 2. Acknowledge the respective alarm message in the popup window with 3. If the fault cannot be corrected, contact the Service Station. Send defective systems parts in suitable packaging and with the relevant fault information for repair to the local Ser- vice Station (see “5 Transport, Storage”).

  • Page 108: Textile Alarms

    Inspection and Maintenance Textile Alarms 8.4.2 ƒ The respective cause of the alarm is shown on the sensing head. ƒ The respective spindle is blocked. ƒ The yarn with faults is automatically removed from the cone (max. 80 m). ƒ The respective bobbin is ejected (machine-specific setting).
  • Page 109 Inspection and Maintenance Thin Cluster The last thin cluster Excessive fault accumulations in Alarm on all spindles of this group: Alarm cut (tC) is displayed the tC channel (cluster alarm). – Check thin cluster setting blinking. Tolerated number of repetitions of Alarm always on one spindle of this group the yarn fault cuts in the thin clus- only:...

  • Page 110: Maintenance Work

    X Aromatic hydrocarbons, e.g. benzene, benzole, toluene ATTENTION X All kinds of alcohol, e.g. methanol, ethanol X Spirit, acetone X Automobile and aviation gasoline Loepfe will not be liable for damage claims resulting from the use of unsuitable substances!

  • Page 111: Clean The Knife Guide

    Inspection and Maintenance Suitable Cleaning Substances ƒ Light contamination: – Cleaning agent TK-Clean from LOEPFE ƒ Heavy contamination: – “Zippo Premium Lighter Fluid” – “Ronsonol Lighter Fluid” – Medical grade benzine – n-Heptane (C – Cypar 7, Cycloaliphat (C ) (a SHELL product)

  • Page 112: Replace Yarn Guides

    Inspection and Maintenance Replace Yarn Guides 8.5.4 Fissures and notches in the yarn guide affect the running of the yarn and could be the cause of higher cutting numbers and classification faults. TK YM ZENIT + D / DF 1. Pull out the sensing head cable. 2.

  • Page 113: Replace The Spindle Adapter (Machine-Specific)

    Inspection and Maintenance Replace the Spindle Adapter (Machine-specific) 8.5.6 Electronic components and assemblies (printed circuit boards) are endangered by electrostatic charges! Possible damage when touching the components! ATTENTION Z Hold assemblies only at the edge. X Do NOT touch soldered connectors, pin contacts, printed circuits or electronic components.

  • Page 115: Dismantling And Disposal

    Dismantling and Disposal Dismantling and Disposal 9.1 Dismantling Danger to life due to voltage! Immediate danger to life when touching live parts. DANGER Z Work on electrical equipment must be performed only by persons with the appropriate qualification. Z Only perform maintenance work on electric components when these are switched off, disconnected from the mains and potential-free.

  • Page 117: Spare Parts / Accessories

    Z Only use original spare parts or accessories approved by Loepfe. The manufacturer assumes no liability for damage caused by the use of spare parts / non-OEM parts / conversion parts not supplied by us.

  • Page 118: Spare Parts

    Spare Parts / Accessories 10.3 Spare Parts Central Unit LZE-V YM ZENIT + Central unit complete LZE-V YM Zenit + 21C / QPRO 50304000 LZE-V YM Zenit + 21C / QPRO Labpack 50322000 LZE-V YM Zenit + SOP 50303000 LZE-V YM Zenit + SOP Labpack 50321000 LZE-V YM Zenit + AC 50305000...
  • Page 119 Spare Parts / Accessories Spindle Adapter Spindle adapter YM Zenit + QPRO 50328000 Spindle adapter YM Zenit + 21C 50330000 Spindle adapter YM Zenit + SOP 50155100 Spindle adapter YM Zenit + AC 50274000 Spindle adapter YM Zenit + AC338 50276000 Spindle adapter YM Zenit + SMARO / ISPERO 50233000...
  • Page 120 Spare Parts / Accessories Sensing Head TK YM ZENIT + Murata TK YM Zenit + D QPRO 50314020 TK YM Zenit + DF QPRO 50315020 TK YM Zenit + DFP QPRO 50316020 TK YM Zenit + D N QPRO 50317000 TK YM Zenit + DF N QPRO 50318000 TK YM Zenit + DFP N QPRO...
  • Page 121 Spare Parts / Accessories Schlafhorst TK YM Zenit + D AC338 50471000 TK YM Zenit + DF AC338 50472000 TK YM Zenit + DFP AC338 50473000 TK YM Zenit + D N AC338 50474000 TK YM Zenit + DF N AC338 50475000 TK YM Zenit + DFP N AC338 50476000...
  • Page 122 Spare Parts / Accessories Side limiter TK YM Zenit + AC 50254000 1 x SR LZYL TORX8 M 2.5 x 6 16666900 1 x Schnorr lock washer Z/M 2.6 10667900 Retaining mechanism TK YM Zenit + 50299000 1 x SR LZYL TORX8 M 2.5 x 6 16666900 1 x U SB 2.5 x 5.0 x 0.5 Polyamid 16516900...

  • Page 123: Accessories

    Spare Parts / Accessories 10.4 Accessories Screwdriver Torx T 8 16748900 LOEPFE TK Clean 14359900 Cotton buds 14655900 Fault chart 42874000 Loepfe Brothers Ltd. P.O. Box 582 Phone + 41 43 488 11 11 www.loepfe.com 8623 Wetzikon / Switzerland Kastellstrasse 10 + 41 43 488 11 00 info@loepfe.com...
  • Page 124 Spare Parts / Accessories Quick Guide YM Zenit + deutsch 50418001 français 50418002 YARNMASTER ® ZENIT english 50418003 Kurzanleitung español 50418004 V 5.5.x.x / 12.2015 italiano 50418005 português 50418006 türkçe 50418007 50418010 中文 Startup manual YM Zenit + deutsch 50338001 français 50338002 YARNMASTER...
  • Page 125 Loepfe Brothers Ltd. 8623 Wetzikon / Switzerland Phone +41 43 488 11 11 Fax +41 43 488 11 00 info@loepfe.com www.loepfe.com Subject to technical modifications...
