- Page 1 YARNMASTER ZENIT ® Operation of LZE-V Quick Guide V 5.9.x.x / 11.2018...
- Page 3 Instruction Manual to third parties – even in form of extracts – as well as the use and / or disclosure of the contents are not allowed without the written approval of Loepfe Brothers Ltd., except for internal purposes. YarnMaster is a registered trademark of Loepfe Brothers Ltd.
-
Page 5: Table Of Contents
Table of Contents Important Information Explanation of Symbols Start-up Central Unit LZE-V User Interface / Navigation Function Buttons Language Selection Login / Access Level Logout Change Password Set Date and Time Check and Complete Base Settings Firmware Update Create / Change Article Copy Article Define a Group Start Group... -
Page 6: Important Information
Useful hints and recommendations. Start-up Assembly and initial start-up are performed by an authorized service technician of the winding machine manufacturer or a service technician of Loepfe Brothers Ltd. For information concern- ing installation and connections, see Chapters 21 and 22. -
Page 7: Central Unit Lze-V
Quick Guide YM Zenit Central Unit LZE-V User interface USB interface Monitor Operation/entry is performed by applying light pressure on the touch-sensitive screen (touch-screen) of the monitor. ATTENTION! Risk of damage by incorrect handling of surface! » Operation by tapping with the finger or a blunt, non-metal object (e.g. -
Page 8: User Interface / Navigation
Language selection Online help Action buttons / function buttons Connection status (Ethernet / MillMaster TOP / Remote / Data Exist) Active user level / logged on user Date / time Software version Switch-over Loepfe / Savio GUI (only LZE-V Faceless) -
Page 9: Function Buttons
Quick Guide YM Zenit Function Buttons Language selection Copy article Login / access level Start lot / group Online help Stop lot / group List of messages Adjust requiring intervention (groups / spindles in production) Create screenshot / Reset monitoring data / save on USB stick quality data Create reports /... -
Page 10: Language Selection
Quick Guide YM Zenit Language Selection Tap Language button. Select desired operator language. Login / Access Level Tap Login button. Select user. Tap password input field. Enter password » Foreman password = 12911291 » Operater password = 47114711 Confirm entry with Confirm password / Login with The Foreman password is required for most of the actions described below! -
Page 11: Logout
Quick Guide YM Zenit Logout The access privileges are reset to “Guest”. 10 Change Password It is recommended to change these pass- words after startup and in regular intervals! 11 Set Date and Time SERVICE > Setup > Date and Time Activate the Edit mode with Enter date / day. -
Page 12: Check And Complete Base Settings
Quick Guide YM Zenit 12 Check and Complete Base Settings SETTINGS > Machine > Base Settings Activate the edit mode with Check and complete the base settings as follows: Machine Type Read only Machine Name Enter name (optional) MillMaster Link On / Off Total Spindles Enter total number of... - Page 13 Quick Guide YM Zenit > Default Data Acquisition Activate the edit mode with Accept / change default settings. Save settings with Confirm pop-up “Save machine settings” with Return to the overview with...
-
Page 14: Firmware Update
Quick Guide YM Zenit 13 Firmware Update SERVICE > System > Firmware Update Master Module, Bootloader and Firmware Versions The versions shown in the “Master Module” field and in the “Spindles” field must match the versions shown in the “Firmware Archive” field. ... - Page 15 Quick Guide YM Zenit Start the TK (Bootloader / Firmware) update with » The status of the update is displayed in the progress bar. » (Update Firmware) is displayed for all sensing heads which do not match. » is displayed after a successful update. After a successful firmware update, both progress bars show 100%.
-
Page 16: Create / Change Article
Quick Guide YM Zenit 14 Create / Change Article SETTINGS > Article (List) Double-clicking an article in the list opens the over- view of the respective clearer parameters. Activate the edit mode with Class Matrix Tapping the class fields (D class, F class, Splice class) activates or deactivates class clearing for these fields. -
Page 17: Copy Article
Quick Guide YM Zenit Select save mode: » Overwrite currently selected article. » or assign the changed settings to another article (assign new article name, if necessary). Confirm changes with The articles marked are articles predefined in the factory. They can not be changed, they can only be used as templates. On principle, clearer settings can also be changed for groups in production. -
Page 18: Define A Group
Quick Guide YM Zenit 16 Define a Group SETTINGS > Group (List) Double-clicking a group in the list opens the overview of the respective group settings. Activate the edit mode with > SETTINGS Group First Spindle / Last Spindle: Enter spindle range (first and last spindle of the group). -
Page 19: Start Group
Quick Guide YM Zenit 17 Start Group SETTINGS > Group (List) Select group. Start group with Group” with Confirm pop-up “Start Spindle adjustment is started. » “Production” is displayed in column “Status” and “Active” in column “Adjust”. » (Adjust) is displayed for all sensing heads. Start and monitor the respective number of pilot spindles individually. - Page 20 Quick Guide YM Zenit Start remaining spindles » If Reset Fine Adjust was selected in “Start Group”, an adjustment will also be performed for each non-pilot spindle. [x]” is displayed after adjustment, it was not possible to “Completed complete adjustment with all pilot spindles (in this case it is recommend- ed to repeat adjustment with other pilot spindles!) The other spindles may be started only when adjustment status “Com-...
-
Page 21: Test Mode
Quick Guide YM Zenit 18 Test Mode SERVICE > Diagnosis > Test Mode The Test mode is available for all cutting types. Several class fields (per D and F class) can be activated at the same time. Activate the Test Mode Activate the edit mode with Determine the time-out (Off, 30, 60, 90 or 120 min.) Select the cut types or respective class fields and confirm with... -
Page 22: Save Data
Quick Guide YM Zenit 19 Save Data Screenshots, reports and data can be copied to a USB stick via the USB port. The respective function buttons become active when the USB stick is inserted. Screenshots A screenshot of selected window is saved as XPS file on the USB stick. - Page 23 Quick Guide YM Zenit ATTENTION: Files with the same name on the USB stick are overwritten without any further confirmation prompt! Import The data selected in the list can be imported from the USB stick to the central unit. Select the required data and import with Wait for acknowledgment.
-
Page 24: Factory Reset
Quick Guide YM Zenit 20 Factory Reset SERVICE > Setup > Factory Reset The factory reset requires password: “MAKERESET” 21 Restart SERVICE > Setup > Restart The central unit is restarted. -
Page 25: Installation
External power supply 90–264 V AC Variant 3 External power supply 24 V DC Central unit (LZE-V Faceless) LAN connection (crossover cable) Loepfe 2-wire-bus (L2B) Spindle Loepfe 2-wire-bus (L2B) Spindle adapter computer (SA) Sensing head (TK) Sensing head cable... -
Page 26: Connections Lze-V
ATTENTION Threaded connection Protective ground This separate grounding point must be connected with the protective ground! DANGER LOEPFE 1 Sub-D Connection of Loepfe 2-wire bus (L2B) 9-pole connector LED green / red Power supply OK LED red Compact-flash drive active... - Page 27 Quick Guide YM Zenit Marking Type Description Microswitch LED green Switch to standby mode (Power ON/OFF) < 1 second controlled by operating system (LED becomes orange) LED green Press Only in emergencies! > 1 second Forced, uncontrolled switch to standby mode (LED becomes orange) Unsaved data are lost! Start...
- Page 28 Loepfe Brothers Ltd. 8623 Wetzikon / Switzerland Phone +41 43 488 11 11 Fax +41 43 488 11 00 info @ loepfe.com www.loepfe.com Subject to technical modifications...
