Item #497-475
Model #FP4A0052BNV
USE AND CARE GUIDE
Pull-out KItcheN FAucet
Questions, problems, missing parts? Before returning to the store,
call Glacier Bay Customer Service
8 a.m.-6 p.m., EST, Monday-Friday
1-855-HD-GLACIER
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in Glacier Bay through the purchase of this faucet. We strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products
available for your home improvement needs. Thank you for choosing Glacier Bay!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FP4A0052BNV and is the answer not in the manual?

Questions and answers

Summary of Contents for Glacier bay FP4A0052BNV

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in Glacier Bay through the purchase of this faucet. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products...
  • Page 2: Table Of Contents

    Glacier Bay products are manufactured with superior quality standards and workmanship and are backed by our limited lifetime warranty. Glacier Bay products are warranted to the original consumer purchaser to be free of defects in materials or workmanship. We will replace FREE OF CHARGE any product or parts that proves defective.
  • Page 3: Pre-Installation

    Pre-Installation PLANNING INSTALLATION Before you begin to install this product: Ensure that all parts are present. Compare parts with the package contents list. If any part is missing or damaged, do not attempt to install the product. Contact customer service for replacement parts. Turn off the cold and hot water lines and turn on the old faucet to release built-up pressure.
  • Page 4: Package Contents

    Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Faucet body Spray head Rubber weight Discharge tube Putty plate Water supply line Quick connector Top mounting fixture Deck plate Sprayer hose...
  • Page 5: Installation

    Installation Checking for thickness Removing the existing faucet if required Check for the proper thickness of the sink. Shut off both of water supplies. Remove the old faucet and clean off the installation surface. Without deck plate Cold 1-1/2 in. (38 mm) max. Ø...
  • Page 6 Installation (continued) Installing the faucet without Tightening the top mounting the deck plate fixture The word “FR£NT” on the top mounting fixture Rotate the two half-moon locking nuts (2) inward (H) must face the front of the sink. before inserting the top mounting fixture (H) into Turn the screws with the provided hex wrench the sink.
  • Page 7 Installation (continued) Inserting water supply lines and Securing the faucet body discharge tube Remove the set screw at the bottom of the faucet. Insert water supply lines (F) one by one through the Align the set screw hole at the bottom of the large hole of the top mounting fixture (H).
  • Page 8: Checking For Leaks

    Installation (continued) Connecting water supply lines Attaching the weight Connect and tighten the water supply line nuts Locate the lowest point on the sprayer hose (J) (1) by using an adjustable wrench. and attach the rubber weight (C) to cover the weight locating sticker on the sprayer hose (J).
  • Page 9: Operation

    operation Removing the Quick Connecting Hose cAutIoN: Use caution when removing the quick connecting hose connections in order to prevent cutting your hands. Push the quick connector (G) housing up. Hold the clip and housing together and pull down. Cleaning the Filter Screen cAutIoN: When irregular flow or low flow occurs, please follow these steps to clean the filter located inside the spray head (B).
  • Page 10: Troubleshooting

    troubleshooting Problem Possible Cause Solution There are leaks The retainer nut has come loose Tighten the retainer nut. underneath the and the O-ring on the cartridge is Clean or replace the O-ring. handle. dirty or damaged. The aerator leaks or The aerator is dirty or mis-fitted.
  • Page 11: Service Parts

    Service Parts MODEL TYPE Part Description Part No. Metal Handle A069911 Handle Cap A66D558 Trim Cap A103250 Locking Nut A104034 Ceramic Disc Cartridge A507348N Hand Spray A528011W-54 Screw A075208 Sprayer Hose A515103N Weight A504718 Hose Adaptor Assembly A66G465N Wrench A031217 (H2.5 * 11 mm L * 53mm L) Hex Wrench A031000NI...
  • Page 12 Questions, problems, missing parts? Before returning to the store, call Glacier Bay Customer Service 8 a.m.-6 p.m., EST, Monday-Friday 1-855-HD-GLACIER HomEDEpot.Com Retain this manual for future use.
  • Page 13: Guía De Uso Y Cuidado

    HOMEDEPOT.COM GRACIAS Apreciamos la confianza que ha depositado en Glacier Bay por la compra de este grifo. Nos esforzamos por crear continuamente productos de calidad diseñados para mejorar su hogar. Visítenos en internet para ver nuestra línea completa de productos disponibles para sus necesidades de mejorar su hogar. ¡Gracias por elegir a Glacier Bay!
  • Page 14: Información De Seguridad

    Garantía de por vida limitada Los productos de Glacier Bay están fabricados con normas y mano de obra de calidad superior y están respaldados por nuestra garantía de por vida limitada. Los productos de Glacier Bay están garantizados al comprador consumidor original de estar libres de defectos en materiales o mano de obra.
  • Page 15: Pre-Instalación

    Pre-instalación PLANIFICACIÓN DE LA INSTALACIÓN Antes de comenzar a instalar este producto: Asegúrese de que todas las partes estén presentes. Compare las partes con la lista de contenido del paquete. Si hace falta alguna parte o se encuentra dañada, no intente instalar el producto. Póngase en contacto con servicio al cliente para las partes de reemplazo.
  • Page 16: Contenido Del Paquete

    Pre-instalación (continuación) CONTENIDO DEL PAQUETE Pieza Descripción Cantidad Cuerpo del grifo Cabezal de rociador Peso de goma Tubo de descarga Placa para masilla Línea de suministro de agua Conector rápido Soporte de montaje superior Placa de cubierta Manguera de rociador...
  • Page 17: Instalación

    Instalación retire el grifo existente si es Verificación de grosor necesario Verifica el grosor adecuado del fregadero. Cierre el suministro de agua. Retire el grifo viejo y limpie la superficie de instalación. Sin placa de cubierta Caliente Fría 1-1/2 pulg. (38 mm) máx. Ø...
  • Page 18 Instalación (continuación) Fijación del soporte de montaje instalación del grifo sin superior la placa de cubierta La palabra “FR£NT” en el soporte de montaje Rota las dos contratuercas de media luna (2) vhacia superior (H) debe hacer frente a la parte delantera del adentro antes de colocar el soporte de montaje superior fregadero.
  • Page 19 Instalación (continuación) inserción de las líneas de Fijación del cuerpo del grifo suministro y el tubo de conexión rápida Retire el tornillo de fijación en la parte inferior del grifo. Alinea el orificio para tornillo de fijación en la parte Inserta las líneas de suministro (F) de a una a la vez a inferior del grifo en el hueco sobre el soporte de montaje través del orificio grande del soporte de montaje superior...
  • Page 20: Comprobación De Fugas

    Instalación (continuación) Conexión de las líneas de sujeción del peso suministro de agua Localice el punto más bajo de la manguera de rociador Conecta y aprieta las tuercas de suministro de agua (J) y coloque el peso de caucho (C) para cubrir la (1) mediante el uso de una llave ajustable.
  • Page 21: Operación

    operación Para retirar el conector rápido de la manguera PRecAucIÓN: Tenga cuidado al retirar el extremo del conector rápido de la manguera para no sufrir cortes en las manos. Empuje hacia arriba el receptáculo del conector rápido (G). Sujete el clip y el receptáculo juntos y jale hacia abajo. Limpieza de la pantalla de filtro PRecAucIÓN: Cuando se produce el flujo irregular o bajo, siga estos pasos para limpiar el flitro situado en el...
  • Page 22: Resolución De Fallas

    Resolución de fallas Problema Posible causa Solución Hay fugas debajo de la La tuerca retenedora se ha aflojado y Apriete la tuerca retenedora. manija. el anillo O en el cartucho está sucio o Limpie o reemplace el anillo O. dañado. El aireador tiene fugas El aireador está...
  • Page 23: Piezas De Servicio

    Piezas de servicio TIPO DE MODELO Pieza Descripción Pieza No. Manija metálicas A069911 Tapón de la manija A66D558 Tapa ornamental A103250 Contratuerca A104034 Cartucho de disco cerámico A507348N Rociador A528011W-54 Tornillo A075208 Manguera del rociador A515103N Pesas A504718 Ensamblaje del adaptador de A66G465N manguera Llave hexagonal...
  • Page 24 ¿Tiene preguntas, problemas, o faltan piezas? Antes de regresar a la tienda, llame a Servicio al Cliente de Glacier Bay de lunes a viernes de 8 a.m. a 6 p.m., hora local del Este 1-855-HD-GLACIER HOMEDEPOT.COM Conserve este manual para uso futuro.
