A.R.C. Laser FOX IV 810 Quick Manual

1
FOX IV 810 − QUICK-GUIDE
1) Sockets
Rear side of the Fox IV 810
Foot switch AUX 1 Door Interlock
CIRCLE CIRCLE CIRCLE
AUX 3
CIRCLE
Power supply
CIRCLE
(3)DoorInterlock - c onnector
1) Insert the door Interlock (3) and check the
power supply if needed.
3) Enter password
3)  E nterPassword:Pleaseusethe
password you received from
our local distributor.
Enter the correct 4-digits code
to switch to the laser screen.
Factory setting: '0000'
WARNING!
Keep in mind that the used laser might cause
serious harm! WEAR SAFETY GOGGLES,
when using the laser!
CAUTION LASER DIODE: Never open the housing! Keep the device from untrained persons. There are no serviceable parts
inside the device. Maintenance and service operations can only be performed by authorized persons or A.R.C.-trained partners.
2) Switch on
Please check before starting
AUX 2
CIRCLE
CIRCLE Fiber-Port Warning label
CIRCLE
2) C heckthefiberconnectionbeforestarting,it
mustnotbeconnectedtoafiber.Aninserted
fiberwillinterruptthestartupandawarning
message will be displayed.
4) Select application
4)  S elect the desired application by
touching the coloured applica-
tion icon.
Emergency-Off
Push and hold (2 s) the switch to turn on the
CIRCLE
FOX IV. The green Start-LED begins to
ing the system check
some seconds cause the laser check several
security circuits. Please do not touch the display
during starting process as it is being calibrated.
5) Select user
5)  I fdifferentusershavebeen
createdduringtheinitialsetup,a
user selection may be necessary
as shown above.
Preselect from the list of sur-
geon names. The selected user
will be displayed in green. Press
the arrow in the lower right
corner to get to the next screen
or double-click. The next screen
will appear - the main screen.
CIRCLE On-Off-Button
flash dur-
. The start-up routine will take
6) Insert probes
300µm
6)  I nserttheprobesasdisplayed.
Ifperfectlyinserted,youshould
hear a "click".
The READY mode can be ac-
tivated now. The aiming beam
will be visible. Without a probe
it will not be possible to switch
on the ready mode.
