Argo DRY PURY 11 Operating Instructions Manual

Hide thumbs Also See for DRY PURY 11:

Advertisement

Table of Contents

EN
DEHUMIDIFIER
DRY PURY 11 – 13 – 17 – 21 – 25
OPERATING INSTRUCTIONS
Read the instructions carefully before operating or servicing the dehumidifier.
Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or damage.
Keep these instructions in a safe place for future reference.
V 02/22
20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DRY PURY 11 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Argo DRY PURY 11

Summary of Contents for Argo DRY PURY 11

  • Page 1 DEHUMIDIFIER DRY PURY 11 – 13 – 17 – 21 – 25 OPERATING INSTRUCTIONS Read the instructions carefully before operating or servicing the dehumidifier. Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or damage.
  • Page 2 Appliance is filled with flammable gas R290. Before installing and using the appliance, read the owner manual. Before installing the appliance, read the installation manual. Any repairs you need, contact the nearest authorized Service Centre and strictly follow manufacturer’s Service Manual. The Refrigerant R290 ...
  • Page 3 Exception Clauses Manufacturer will bear no responsibilities when personal injury or property loss is caused by the following reasons. Damage the product due to improper use or misuse of the product; Alter, change, maintain or use the product with other equipment without abiding by the instruction manual of manufacturer;...
  • Page 4 GENERAL OPERATING AND SAFETY INSTRUCTIONS  This appliance is a highly efficient dehumidifier, designed for domestic use only!  Use this dehumidifier only as outlined in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock or malfunctions. ...
  • Page 5  To disconnect the appliance, set the switch to OFF and remove the plug from the socket. Only pull on the plug. Do not pull the cord.  Do not bend, drag or twist the cord, or apply force to remove it. Do not operate the unit if its cable or plug are damaged;...

  • Page 6: Description Of Parts

     Do not use the appliance in the bathroom or laundry room.  Keep the appliance well away from sources of heat which could cause plastic parts to become warped.  Do not spray insecticides, oils or paints near the appliance; doing so may damage its plastic parts or start a fire.

  • Page 7: Appliance Start-Up

    PRE-OPERATING CHECKS AND OPERATIONS Before operating the appliance, check the correct positioning of the float inside the condensate collection tank. Remove the tank following the direction of the arrow. Remove from the tank the bubble plastic bag which contains the 4 wheels and the cable reel Reposition the tank, closing it perfectly, as shown below Check that the float inside the tank for collecting the condensate is correctly positioned.

  • Page 8: Operating Precautions

    Green filter - Catechin filter natural substance extracted from tea, eliminates odors and pollutants Gray filter - Silver ion filter, eliminates bacteria Blue filter - Additional filter with anti-bacterial action The dehumidifier is equipped with a signaling system for the need to clean the dust filter after 250 hours of operation (AIR CLEAN SYSTEM).
  • Page 9 Carefully remove the tank and following the direction of the arrow, paying attention to not spill out the water from the tank and then splash onto the floor. Empty the tank. Reposition the tank following the direction of the arrow. N.B.
  • Page 10 Rubber plug Adaptor The height of the drainage hose must not exceed that of the hole: do not block the drainage hose exit. When disconnecting the tube, prepare a container to collect the remaining water from the tube. Basin V 02/22...

  • Page 11: Control Panel

    CONTROL PANEL Water tank FULL light Filter cleaning indicator High fan speed Timer indicator Low fan speed 6. Auto Button 4. Timer Button 3. Fan Button 1. Power Button 5. Filter Button Display 2. Humidity Button Each time the button is pressed, the unit emits an auditory signal. BUTTONS &...

  • Page 12: Cleaning The Water Tank

    MEMORY FUNCTION: the dehumidifier starts up again after a power failure keeping last settings. AUTOSTOP FUNCTION: if the humidity it’s lower than 5% respect to the one set by the humidifier automatically it stop. CLEANING AND MAINTENANCE MAINTENANCE OF THE HUMIDIFIER’S EXTERIOR SURFACE Warning Always pull the dehumidifier's plug out of the power socket before cleaning it, to prevent electric shock and malfunction.

  • Page 13: Troubleshooting

    Do not dry the filter with a heat source or with a hairdryer, it could catch fire. Use a vacuum cleaner with the lowest possible power to avoid damaging the fibers. It is advisable to clean the filter every 3 months or more frequently, depending on the frequency of use, for a maximum of 4 cleaning cycles, then it must be replaced.
  • Page 14 Due to the temperature difference of the heat On departure, the air may smell exchanger, the air can have a strange smell on musty departure. The dehumidifier may emit noise if placed on a The appliance emits noise wooden floor If the noise seems like a hiss, it is normal, it is the refrigerant that circulates in the appliance There is water in the tank even...
  • Page 15 REGULATION (EU) N. 517/2014 - F-GAS The unit contains R290, a natural greenhouse gas with global warming potential (GWP) = 3 DRY PURY 11 : Kg. 0,045 = 0,000135 Tonn CO equiv DRY PURY 13 : Kg. 0,045 = 0,000135 Tonn CO equiv DRY PURY 17 : Kg.
  • Page 16 The area shall be checked with an appropriate refrigerant detector prior to and during work, to ensure the technician is aware of potentially toxic or flammable atmospheres. Ensure that the leak detection equipment being used is suitable for use with all applicable refrigerants, i.e. non-sparking, adequately sealed or intrinsically safe. ...
  • Page 17 Under no circumstances shall potential sources of ignition be used in the searching for or detection of refrigerant leaks. A halide torch (or any other detector using a naked flame) shall not be used. Leak detection methods The following leak detection methods are deemed acceptable for all refrigerant systems. Electronic leak detectors may be used to detect refrigerant leaks but, in the case of flammable refrigerants, the sensitivity may not be adequate, or may need re-calibration.
  • Page 18 When the cylinders have been filled correctly and the process completed, make sure that the cylinders and the equipment are removed from site promptly and all isolation valves on the equipment are closed off. k. Recovered refrigerant shall not be charged into another refrigeration system unless it has been cleaned and checked. Labelling Equipment shall be labelled stating that it has been de-commissioned and emptied of refrigerant.

This manual is also suitable for:

Dry pury 13Dry pury 17Dry pury 21Dry pury 25
