EN
DEHUMIDIFIER
LILIUM ART 11 - 13
OPERATING INSTRUCTIONS
Read the instructions carefully before operating or servicing the dehumidifier.
Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or damage.
Keep these instructions in a safe place for future reference.
V 02/22
16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LILIUM ART 11 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Argo LILIUM ART 11

Summary of Contents for Argo LILIUM ART 11

  • Page 1 DEHUMIDIFIER LILIUM ART 11 - 13 OPERATING INSTRUCTIONS Read the instructions carefully before operating or servicing the dehumidifier. Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or damage. Keep these instructions in a safe place for future reference.
  • Page 2 Appliance is filled with flammable gas R290. Before installing and using the appliance, read the owner manual. Before installing the appliance, read the installation manual. Any repairs you need, contact the nearest authorized Service Centre and strictly follow manufacturer’s Service Manual. The Refrigerant R290 ...
  • Page 3 GENERAL OPERATING AND SAFETY INSTRUCTIONS  This appliance is a highly efficient dehumidifier, designed for domestic use only!  Use this dehumidifier only as outlined in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock or malfunctions. ...
  • Page 4  To disconnect the appliance, set the switch to OFF and remove the plug from the socket. Only pull on the plug. Do not pull the cord.  Do not bend, drag or twist the cord, or apply force to remove it. Do not operate the unit if its cable or plug are damaged;...
  • Page 5  Do not spray insecticides, oils or paints near the appliance; doing so may damage its plastic parts or start a fire.  Keep flammable gases and oils away from the appliance!  Do not move the appliance while it is operating; doing so can cause leaks and malfunction.

  • Page 6: Appliance Start-Up

    The following space must be maintained to ensure the operating efficiency of the dehumidifier. 50 cm 50 cm OPERATING INSTRUCTIONS APPLIANCE START-UP Place the product on a flat and stable heat-resistant surface, at least 1 metre away from flammable or heat-sensitive materials and 50 cm away from walls or other obstructions.
  • Page 7 TURNING THE DEHUMIDIFIER OFF To turn the dehumidifier off press the POWER button. This shuts off power to the unit. Unplug the appliance if you do not intend to use it for some time. HOW TO ELIMINATE CONDENSATE The water extracted from the air can be collected in the provided front tank. When the tank is full, not inserted or not correctly inserted, the FULL TANK led turns on and the unit beeps for about 10 seconds, at the end of which the unit turns off.

  • Page 8: Display On Control Panel

    CONTROL PANEL Display DISPLAY ON CONTROL PANEL Continuous Sleep Mode Mode Auto Mode POWER Timer Low fan speed Child lock High fan speed Led Tank full BUTTONS and LEDs 1. POWER BUTTON: Press this button to turn the dehumidifier on and off. To turn on the dehumidifier, press this button, the unit emits a beep and is in standby.
  • Page 9 Auto mode: When the humidity in the room is 3% higher than the set one, the ventilation and the compressor start to work after 3 minutes. On the other hand, when the humidity in the room is 3% lower than the set one, the compressor stops while the ventilation continues for a short period of time.

  • Page 10: Cleaning The Water Tank

    CLEANING THE WATER TANK We advise removing the tank once every two weeks to prevent mould and bacteria forming on it. Fill the tank with clean water a small amount of detergent; swill the water around in it, then it out and rinse it thoroughly. CLEANING THE AIR FILTER The filter is designed to remove dust or dirt from the air.

  • Page 11: Troubleshooting

    High temperature protection in the environment above 38 ° C REGULATION (EU) N. 517/2014 - F-GAS LILIUM ART 11 The unit contains R290, a natural greenhouse gas with global warming potential (GWP) = 3 - Kg. 0,045 = 0,000135 Tons CO equiv.
  • Page 12 Specialist’s Manual Aptitude requirement for maintenance man (repairs. should be done only be specialists). a) Any person who is involved with working on or breaking into a refrigerant circuit should hold a current valid certificate from an industry-accredited assessment authority, which authorises their competence to handle refrigerants safely in accordance with an industry recognised assessment specifìcation.
  • Page 13 ---That no live electrical components and wiring are exposed while charging, recovering or purging the system; ---That there is continuity of earth bonding.  Repairs to sealed components During repairs to sealed components, all electrical supplies shall be disconnected from the equipment being worked upon prior to any removal of sealed covers, etc.
  • Page 14 Ensure that contamination of different refrigerants does not occur when using charging equipment. Hoses or lines shall be as short as possible to minimise the amount of refrigerant contained in them. Cylinders shall be kept upright. Ensure that the refrigeration system is earthed prior to charging the system with refrigerant. Label the system when charging is complete (if not already).

This manual is also suitable for:

Lilium art 13
