Page 5 1. Important safety warning Please strictly adhere to all warnings and operating instructions in this manual. Keep this manual properly and read the following instructions carefully before installing the unit. Do not operate this unit before carefully reading all safety information and operating instructions. 1-1.
Page 6 • Caution - risk of electric shock. Even after disconnecting the unit from the mains power (building wiring outlet), components within the UPS system are still connected to the battery and are electrically live and dangerous. • Before performing any type of service and/or maintenance, disconnect the batteries and verify that there is no current and no dangerous voltage on the high capacity capacitor terminals, such as BUS capacitors.
Page 7 2. INSTALLATION AND CONFIGURATION NOTE: Before installation, inspect the unit. Make sure nothing inside the package is damaged. Store the original package in a safe place for future use. 2.1 Rear Panel View Tower models 1K/1.5K (AX) 2K (AX) 3K (A) MODEL RT Rack 1K/ 1.5K (AX) 2K (AX)
Page 8 1. Programmable outputs: do not connect to critical loads. 2. Output receptacles: connecting mission-critical loads. 3. AC input 4. Network/Fax/Modem surge protection 5. USB communication port 6. RS - 232 communication port 7. SNMP smart slot 8. Emergency Power Off (EPO) function connector 9.
Page 9 2 - 3. Install the UPS (for RT models only) For safety, the UPS is shipped from the factory without connecting battery cables. Before installing the UPS, please follow the steps below to reconnect battery cables first. Step 1 Step 2 Step 3 Remove the front panel Put the front panel...
Page 10 Installation of the towers Step 1 Step 3 Step 2 2 - 4. UPS Settings Before installing the UPS, please read below to select the suitable location to install UPS. 1. UPS should be placed on the flat and clean surface. Place it in an area away from vibration, dust, moisture, high temperature, flammable liquids, corrosive gases and conductive pollutants.
Page 11 4. UPS: It is equipped with cooling fan. Therefore, place the UPS in a well-ventilated area. It is necessary to keep the minimum clearance distance of 100mm in the front of the UPS and 300mm in the back and two sides of the UPS for heat dissipation and easy maintenance. 5.
Page 12 Step 1:external battery connection Follow the chart on the right to connect the external battery. Step 2:UPS input connection Plug the UPS into two-pole, three-wire, grounded receptacles only. Avoid using extension cords. For 200/208/220/230/240VAC models: The power cord is supplied in the UPS package. For 100/110/115/120/127VAC models: The power cord is attached to the UPS.
Page 13 Communication port: USB port RS-232 port smart space To enable automatic shutdown/startup and UPS status monitoring, connect a communication cable from one end to the USB/RS-232 port and the other end to the communication port of your PC. With the monitoring software installed, you can schedule UPS shutdown/startup and monitor UPS status via PC.
Page 14 Step 7:Turn on the UPS Press the ON/Mute button on the front panel for two seconds to turn on the UPS. Note: The battery is fully charged during the first five hours of normal operation. Do not expect the battery to operate during the initial charging period.
Page 15 STEP 4 STEP 5 STEP 6 After replacing the Reconnect the battery cables Remove the top cover of the batteries, place the battery battery box and replace the box back into its internal batteries. original location and screw firmly. STEP 7 Place the front panel under the unit 2-6.
Page 16 Step 3:Place the assembled battery Step 4:Cover the other side of the plastic cover packs on one side of the plastic covers. as shown in the table below. Then the drum kit is fine. assembly. 3- drum kit Step 2:Connect all battery terminals Step 1:Remove the adhesive caps following the table below.
Page 17 4- battery kit Step 2:Connect all terminals of the Step 1:remove the adhesive covers battery following the table below. Cover Adhesive Cover adhesive Step 3:Place the assembled battery Step 4:Cover the other side of the plastic cover packs on one side of the plastic covers. as shown in the table below.
Page 18 Step 3:Place the assembled battery Step 4:Cover the other side of the plastic cover packs on one side of the plastic covers. as shown in the table below. Then the drum kit is fine. assembly. 3. Operation 3-1. Operation button Function Button •...
Page 19 • Switch to bypass mode: When the main power is normal, press ON/Mute and Select buttons simultaneously for 3 seconds. Then UPS will enter bypass mode. This action will be ineffective when the input voltage is out of the acceptable range. ON / OFF button •...
Page 20 Departure information Voltage output and frequency output indicators. VCA: AC voltage, Vdc: DC voltage, Hz: frequency Loading information Charge level indicators 0-24%, 25-49%, 50-74% and 75-100%. Overload indicators UPS load or output indicators are short circuit Programmable outputs information Indicates that the programmable management outputs are operating. Information in operational mode UPS main connection indicators Battery indicators are working...
Page 21 3-4. LCD expression index Screen content Meaning Abbreviation Enabled Disabled Exhaust High loss Low loss Open activity Activity closed Estimated autonomy time. Running autonomy time. turn off Low battery Overload High output current I HEARD Battery not connected Overload Wiring fault site Temperature Charger Battery failure...
Page 22 • 01: Voltage output settings Settings Interface Parameter 2: Voltage output For 200/208/220/230/240 VAC models, you can choose the following output voltage: 200:It has an output voltage of 200Vac. 208:It has an output voltage of 208 Vac. 220:It has 220 Vac output voltage. 230:It has 230 Vac output voltage (default) 240:It has 240 Vac output voltage.
Page 23 • 04: ECO Enabled/Disabled Settings Interface Parameter 2:enable/disable the ECO function. You can choose the following two options ENA:ECO mode enabled DIS:ECO mode disabled (Default) • 05: ECO voltage range settings Settings Interface Parameter 2:Set the acceptable high voltage point and low voltage point for ECO mode by pressing the Down key or the Up key.
Page 24 • 07: Bypass voltage range adjustment Settings Interface Parameter 2:Set the acceptable high voltage point and the acceptable low voltage point for the Bypass mode by pressing the Down key or the Up key. HLS:High voltage point bypass For 200/208/220/230/240 Vac models: 230-264:Setting the high voltage point in parameter 3 from 230Vac to 264Vac.
Page 25 • 09: Enable/Disable Programmable Outputs Settings Interface Parameter 2:enable/disable Programmable Outputs. ENA:enable Programmable Outputs. DIS:Disable Programmable Outputs. (Default) • 10: Programmable output settings Settings Interface Parameter 2:Set backup time limits for programmable outputs. 0-999:Setting backup time limits in minutes from 0-999 for programmable outputs that connect to non-critical devices in battery mode.
Page 26 • 13: Maximum charging current setting Settings Interface Parameter 2:Set the maximum charger current. For low voltage model with 24/36/48VDC. 1/2/4/6/8:Maximum charger current setting 1/2/4/6/8 amps. (Default: 2A) High voltage models with 24/36/48VDC 1/2/4/6/8/10/12:Setting the maximum charger current 1/2/4/6/8/10/12/12 in ampere. (Default: 2A) For low voltage and high voltage models with 72/96VDC.
Page 27 • 15: Adjusting the charger float voltage Settings Interface Parameter 2:Set the charger float voltage. 2.20-2.33:charger float voltage setting 2.20 V/cell to 2.33V/cell. (Default: 2.28V/cell) • 16: EPO Logical Configuration Settings Interface Parameter 2:Configure the control logic for the EPO function.
Page 28 • 19: Acceptable input voltage range adjustment Settings Interface Parameter 2:Set the acceptable high voltage point and the acceptable low voltage point for the input voltage range by pressing the Down key or the Up key. HLS:High input voltage point Models: 200/208/220/230/240 VAC 280/290/300:High input voltage point (Default: 300VAC) For 100/110/115/120/127 VAC models:...
Page 29 3-6. Operating mode description Operating mode Description LCD display When the input voltage is within the acceptable Online Mode range, the UPS will provide pure and stable AC power for output. The UPS will also charge the battery in online mode. Power saving mode: ECO mode When the input voltage is within the voltage...
Page 30 When the input voltage is within the acceptable Bypass mode range but the UPS is overloaded, the UPS will enter bypass mode or the front panel can set the bypass mode. The alarm sounds every 10 seconds. The UPS is off and there is no output power, but Standard mode the batteries can still be charged.
Page 31 3-8. Warning indicators Icon Alarm Code Warning (blinks) Low battery It will sound every 2 seconds overload It will ring every second About the input current Sounding 2 beeps every 10 seconds Battery is not connected It will sound every 2 seconds Overload It will sound every 2 seconds Wiring fault site...
Page 32 are inverted. LCD display and the alarm is connect it to the UPS system. ringing every 2 seconds Check if all batteries are ok The external or internal The icons of flashes in battery is connected The LCD screen and the alarm incorrectly.
Page 33 Battery backup time is shorter The battery is not fully Charge the battery for at than normal charged least 5 hours and check the capacity. If the problem persists, contact your dealer. Contact your dealer to Defective battery replace the battery. The short circuit occurs at Check if the battery wiring The fault code is displayed as 2A on...
Page 34 6. Specifications Tower Models MODEL 1.5K AX 1K 2B AX 1K 3B AX 2K 4B AX 2K 6B AX 3K AX ABILITY* 1000VA/1000W 1500VA/1500W 2000VA/2000W 3000VA / 3000W ENTRANCE Transfer of 160VAC/140VAC/120VAC/110VAC ± 5% or 80VAC/70VAC/60VAC/55VAC ± 5% low line (based on low percentage) 100% - 80% / 80% - 70% / 70 - 60% / 60% - 0) Line return Range of...
Page 35 RT Model: MODEL K RT-2BAX 1K RT-3B AX 2K RT-4B AX 1.5K RT AX 2K RT-6B AX 3K RT AX ABILITY* 1000VA/1000W 1500VA/1500W 2000VA/2000W 3000VA / 3000W ENTRANCE Line transfer 160VAC/140VAC/120VAC/110VAC ±5% or 80VAC/70VAC/60VAC/55VAC ±5% (based on load percentage 100% - 80% / 80% - 70% / 70 - 60% / 60% - 0) Low line return Range of 175VAC/155VAC/135VAC/125VAC ±...
Page 36 User manual Output Power Rating Table (for 100/110/115/120/127 VAC systems only) Model name Entry classification Exit rating 1K 2B, 1K 3B, 1K RT-2B, 1K RT-3B 110-127Vac, 50/60Hz, 12A, 100/110/115/120/125/127Vac, 50/60Hz, 1Ø 1000VA/1000W,1Ø, 10A 1.5K, 1.5K RT 110-127Vac, 50/60Hz, 12A, 100/110/115/120/125/127Vac, 50/60Hz, 1Ø 1Ø...
