GOALRILLA TR2000W Owner's Manual

Multi sports trainer
Hide thumbs

Advertisement

Table of Contents

THE TOUGHEST TRAINING SYSTEM ON THE PLANET.
O W N E R ' S
1. Read this manual carefully before starting assembly. Read each step completely before beginning
each step.
2. Some smaller parts may be shipped inside larger parts. Check inside all parts and cartons before
assembling or ordering parts.
3. If hardware is tightened too soon, mounting holes may not align and parts may not easily fit together.
Leave bolts or locknuts slightly loose until you are instructed to tighten them.
4. Tools required for assembly:
Allen Wrench T1 & T2 (inlcuded)
Rubber Hammer
5. To make assembly as easy as possible, place all parts of the trainer in a cleared area and remove the
packaging material. Organize all parts as per parts identifier in the assembly manual. Do not dispose
of the packing material until assembly is completed.
6. Avoid scratching metal tube parts during the assembly process.
7. During assembly - Pivot points are to be "snug" tight only and must pivot freely.
"Fixed" connections should be tightened tight.
8. Take time to correctly orientate parts exactly as per each assembly diagram.
9. Save this instruction in the event that the manufacturer has to be contacted for replacement parts.
Please Do Not Return This Product To The Store!
Contact Escalade Sports customer service department at:
Phone:
1-888-USA-GOAL
Fax:
1-866-873-3536
E-mail:
training@escaladesports.com
Mailing Address:
Escalade Sports
PO Box 889
Evansville, IN 47706
Please visit our World Wide Web site at: www.Goalrilla.com
ON-LINE TROUBLE SHOOTING
ON-LINE PARTS REQUESTS
ADDITIONAL ESCALADE SPORTS PRODUCT INFORMANTION
Escalade Sport products may be manufactured and/or licensed under the following patents.
R
6419596, 6179733, 5919102, 5071120, 4798381, 4424968, D326128
Additional patents may be pending. One or more of the listed patents and/or pending patents may cover specific product.
13mm or 1/2" Open End Wrench
16mm or 5/8" Open End Wrench
R
R
M A N U A L
Toll-Free!
Toll-Free!
TECHNICAL ASSISTANCE
FREQUENTLY ASKED QUESTIONS
MODEL NO.
TR2000W
TR2000F
MULTI SPORTS TRAINER
5/16" Open End Wrench
2L-7222-00
2011 Escalade Sports
C
R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TR2000W and is the answer not in the manual?

Questions and answers

Related Manuals for GOALRILLA TR2000W

Summary of Contents for GOALRILLA TR2000W

  • Page 1 Toll-Free! E-mail: training@escaladesports.com Mailing Address: Escalade Sports PO Box 889 Evansville, IN 47706 Please visit our World Wide Web site at: www.Goalrilla.com ON-LINE TROUBLE SHOOTING TECHNICAL ASSISTANCE ON-LINE PARTS REQUESTS FREQUENTLY ASKED QUESTIONS ADDITIONAL ESCALADE SPORTS PRODUCT INFORMANTION 2L-7222-00 Escalade Sport products may be manufactured and/or licensed under the following patents.
  • Page 2 WARNING FAILURE TO FOLLOW THESE SAFETY INSTRUCTIONS MAY RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE Owner must ensure that all users know and follow these rules for safe operation of the product. • Product is recommended for children 9 years of age and older. •...
  • Page 3 HARDWARE IDENTIFIER (To Scale) H1 - M8 x 20mm H2 - M8 x 60mm Allen Head Bolt (22 pcs) Allen Head Bolt (4 pcs) H3 - M8 x 71mm H4 - M10 x 55mm Allen Head Bolt (4 pcs) Allen Head Bolt (4 pcs) H5 - M8 x 16mm H6 - M10 x 20mm H7 - M8 Locknut...

  • Page 4: Parts Identifier

    PARTS IDENTIFIER P1L - Front Top P2R - Front Top P3 - Front Top Left Corner (1 pc) Right Corner (1 pc) Cross Beam (1 pc) P4 - Front Side P5 - Top Side Support P6 - Side Goal Support Post (2 pcs) Beam (2 pcs) Beam (2 pcs) and...
  • Page 5 PARTS IDENTIFIER P15A Product ID & Date Code Label P15B P13L - Back Left P14R - Back Right P15A - Back Top Rebounder Bottom Corner (1 pc) Bottom Corner (1 pc) Beam (1pc) P15B - Back Bottom Rebounder Beam (1pc) P16L - Left Side Angle P17R - Left Side Angle P18 - Ball Dampening Net...
  • Page 6 PARTS IDENTIFIER P25 - 6” Wheel P26 - Safety Cable P27 - Locking Pin (2 pcs) (2 pcs) (2 pcs) P28 - Fiberglass Rod P29 - 11pcs Aluminum P30 - Rebound Net (1 set) Spring Clip / Bag (4 Bags) (1 pc) P31 - 208-1/2”...
  • Page 7 IMPORTANT! Please study each assembly diagram and carefully read all “Notes” before working on each assembly step. STEP 1: Install P1L into P3 using Allen Head Bolt H1 and Flat Washer H5 as shown in FIGURE 1. Use Allen Wrench T1 to tighten H1 Bolt. PARTS REQUIRED: 1 pc - H1 Allen Head Bolt 1 pc - H5 Flat Washer...
  • Page 8 STEP 3: Rubber Install P2R into P3 using Allen Head Bolt H1 and Flat Washer H5 as shown in FIGURE 3. Hammer Use Allen Wrench T1 to tighten H1 Bolt. PARTS REQUIRED: 1 pc - H1 Allen Head Bolt 1 pc - H5 Flat Washer 1 pc - P2R Front Top Right Corner 1 pc - T1 Allen Wrench 1 pc - Rubber Hammer...
  • Page 9 STEP 5: Install two pieces P4 using Allen Head Bolts H1 and Flat Washers H5 as shown in FIGURE 5. Slide P21L Left Side Net and P22R Right Side Net onto each P5 as shown in FIGURE 5. Connect each P5 to P1L and P2R using Allen Head Bolts H1 and Flat Washers H5 as shown in FIGURE 5. Use Allen Wrench T1 to tighten H1 Bolts.
  • Page 10 8 pcs - H5 Flat Washer 2 pcs - P24 5” Wheel Note: 2 pcs - H7 Locknut Make sure “Goalrilla” logo 1 pc - T1 Allen Wrench is turned up as per diagram. 1 pc - 13mm or 1/2” Open End Wrench...
  • Page 11 STEP 8: Install P20 Cable (both sides of unit), starting in the middle of each P4 and sliding cable both directions through P21L & P22R Side Net loops and P4 Side Post steel eyelets. Install Locknuts H7 on each end of P20 Cables as shown in DETAIL C & DETAIL D. Tighten Locknuts H7 until Cable is tight / Do not overtighten. Secure velcro on Side Nets P21L &...
  • Page 12 STEP 9: Install P9L & P10R onto P15A using Allen Head Bolts H1 and Flat Washers H5 as shown in FIGURE 9. Install P11L & P12R onto P9L & P10R using Allen Head Bolts H1 and Flat Washers H5 as shown in FIGURE 9. Use Allen Wrench T1 to tighten all H1 Bolts.
  • Page 13 STEP 11: Connect the previous STEP 9 and STEP 10 assemblies using Allen Head Bolts H1 and Flat Washers H5 as shown in FIGURE 11. Use Allen Wrench T1 to tighten H1 Bolts. FIGURE 11 PARTS REQUIRED: 2 pcs - H1 Allen Head Bolt 2 pcs - H5 Flat Washer 1 pc - T1 Allen Wrench 1 pc - Rubber Hammer...
  • Page 14 STEP 13: Install two pieces H9 Plastic Step Washers into the top hole of both P16L & P17R as shown in FIGURE 13. With the help of another adult, attach P16L & P17R to P11L & P12R using Allen Head Bolts H2, Flat Washers H5 and Locknuts H7 as shown in FIGURE 13.
  • Page 15 STEP 14: With the help of another adult, install two pieces P27 Locking Pin into bottom (lowest) position hole of each angle changing bracket as shown in FIGURE 14. Install two pieces P26 Safety Cable using Allen Head Bolts H4, Flat Washers H6 and Locknuts H8 as shown in FIGURE 14.
  • Page 16 STEP 15: Install H9 Plastic Step Washers into the end holes of each P5. With the help of another adult, very carefully attach the previous STEP 14 assembly to each P5 using Allen Head Bolts H2, Flat Washers H5 and Locknuts H7 as shown in FIGURE 15. Use Allen Wrench T1 to snug tighten H2 Bolts.
  • Page 17 STEP 16: Picture - Tie off one end of P31 Bungee Cord using a double knot at the bottom right half moon welded eyelet. Picture - With help of another adult, thread P31 Bungee Cord through all right side, top side, left side and bottom eyelets.
  • Page 18 STEP 17: Attach fourty four (44) pieces P29 Aluminum Spring Clips to P31 Bungee Cord as shown in FIGURE 17. Be careful not to damage P31 Bungee Cord while installing these P29 Aluminum Spring Clips. PARTS REQUIRED: 44 pcs - P29 Aluminum Spring Clip FIGURE 17 - 18 -...

  • Page 19: Important Note

    STEP 18: Install P30 Rebound Net using fourty four (44) pieces P29 Aluminum Spring Clips as shown. Note: Rebound Net will be tight. PARTS REQUIRED: 1 pc - P30 Rebound Net NOTE: Attach four corners first for ease of installation. FIGURE 18 IMPORTANT NOTE: P30 Rebound Net sensitivity can be adjusted by tightening or loosing the P31 Bungee Cord.
  • Page 20 • Baseball – Long Toss, Fly Balls • Soccer – Headers • Basketball – Ball Return Under Hoop - Free Throw Practice • Volleyball – Bump/Set/Spike Drills • Lacrosse – Pitch Back POSITION 5 For additional information, visit goalrilla.com - 20 -...

  • Page 21: Care And Maintenance

    INSTRUCTIONS To move the product, flip the dampening net up and over the back of the goal net to avoid tripping. Grab the top middle of the product (orange cross bar) and carefully tip toward your body until the wheels engage the ground. Move to desired location and tip product back into position.

  • Page 22: Product Parts List

    PRODUCT PARTS LIST TR2000W / F PARTS# KEY# DESCRIPTION QTY. TR2000-H1 M8 x 20mm Allen Head Bolt TR2000-H2 M8 x 60mm Allen Head Bolt TR2000-H3 M8 x 71mm Allen Head Bolt TR2000-H4 M10 x 55mm Allen Head Bolt TR2000-H5 M8 x 16mm Flat Washer...

  • Page 23: Five Year Limited Warranty

    FIVE YEAR LIMITED WARRANTY This consumer warranty extends to the original consumer purchase of any Escalade® Sports Product (hereinafter referred to as the “Product”). WARRANTY COVERAGE: Escalade® Sports warrants to the original Consumer Purchaser that any Product of its manufacture is free from defects in material and workmanship. THIS WARRANTY IS VOID IF THE PRODUCT HAS BEEN DAMAGED BY ACCIDENT, UNREASONABLE USE, NEGLIGENCE, IMPROPER SERVICE, FAILURE TO FOLLOW INSTRUCTIONS PROVIDED WITH THE PRODUCT OR OTHER CAUSES NOT ARISING OUT OF DEFECTS IN MATERIAL OR WORKMANSHIP.
