HPE 5920&5900 Switch Series
Installation Guide
Part number: 5998-2852s
Document version: 6W106-20160516

Advertisement

loading
Need help?

Need help?

Do you have a question about the HPE 5920 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HP HPE 5920 Series

Summary of Contents for HP HPE 5920 Series

  • Page 1 HPE 5920&5900 Switch Series Installation Guide Part number: 5998-2852s Document version: 6W106-20160516...
  • Page 2 © Copyright 2016 Hewlett Packard Enterprise Development LP The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.

  • Page 3: Table Of Contents

    Contents Preparing for installation ················································································· 1     Safety recommendations ··································································································································· 3   Examining the installation site ···························································································································· 3   Temperature/humidity ································································································································ 3   Cleanliness ················································································································································· 4   EMI ····························································································································································· 4   Laser safety ················································································································································ 4   Installation tools ················································································································································· 5  ...
  • Page 4 Appendix A Chassis views and technical specifications ······························· 35     Chassis views ·················································································································································· 35   HPE 5920AF-24XG/HPE 5920AF-24XG TAA ························································································· 35 HPE 5900AF-48XG-4QSFP+/HPE 5900AF-48XG-4QSFP+ TAA/HPE 5900CP-48XG-4QSFP+/HPE   5900CP-48XG-4QSFP+ TAA/HPE 5900CP-48XG-4QSFP+8Gb FC B-F ··············································· 36   HPE 5900AF-48XGT-4QSFP+/HPE 5900AF-48XGT-4QSFP+ TAA ······················································· 37  ...

  • Page 5: Preparing For Installation

    Preparing for installation Table 1 describes HPE 5920 and 5900 Switch Series models, power supplies, and fan trays. Table 1 HPE 5920 and 5900 Switch Series models, power supplies, and fan trays Product code HPE description Alias HPE 5920 switches JG296A HPE 5920AF 24XG Switch HPE 5920AF-24XG...
  • Page 6 • For regulatory identification purposes, the HPE 5920AF-24XG and HPE 5920AF-24XG TAA products are assigned Regulatory Model Numbers (RMNs). The RMNs for these products are listed below. These regulatory numbers should not be confused with the marketing name HPE 5920AF, or product codes JG296A and JG555A. Product code HPE description JG296A...

  • Page 7: Safety Recommendations

    Safety recommendations To avoid any equipment damage or bodily injury, read the following safety recommendations before installation. Note that the recommendations do not cover every possible hazardous condition. • Before cleaning the switch, remove all power cords from the switch. Do not clean the switch with wet cloth or liquid.

  • Page 8: Cleanliness

    Cleanliness Dust buildup on the chassis might result in electrostatic adsorption, which causes poor contact of metal components and contact points, especially when indoor relative humidity is low. In the worst case, electrostatic adsorption can cause communication failure. Table 2 Dust concentration limit in the equipment room Substance Concentration limit (particles/m³) ≤...

  • Page 9: Installation Tools

    Installation tools The installation tools are not provided with the switch. Prepare them yourself. • Phillips screwdriver • ESD wrist strap Installation accessories Table 4 Installation accessories Product code Description Quantity Applicable models 1 U mounting bracket kit (including one pair of mounting brackets and eight M4 countersunk screws) 5066-0850...
  • Page 10 Product code Description Quantity Applicable models DC power cord 650 W DC power supply 5185-8688 5400-0249 The power cord color code scheme is for illustration only. The cable delivered for your country or region might use a different color scheme. Removable cable tie  ...

  • Page 11: Installing The Switch

    Installing the switch CAUTION: Keep the tamper-proof seal on a mounting screw on the chassis cover intact, and if you want to open the chassis, contact Hewlett Packard Enterprise for permission. Otherwise, Hewlett Packard Enterprise shall not be liable for any consequence caused thereby. Figure 1 Hardware installation flow Start Install the...

  • Page 12: Mounting Brackets And Rack Mounting Rail Kit

    Table 5 Requirements for the rack Switch model Installation method Requirements for the rack • Depth—A minimum of 1000 mm (39.37 in). • HPE 5920AF-24XG Using mounting brackets and • Distance between the front • short slide rails (provided) HPE 5920AF-24XG TAA and rear rack posts—401 mm (15.79 in) to 895 mm (35.24 in).

  • Page 13: Rack-Mounting Procedures At A Glance

    Figure 3 Rack mounting rail kit (1) Chassis rail (2) Short slide rail (1) Chassis rail (2) Long slide rail Rack-mounting procedures at a glance Figure 4 Rack-mounting procedure IMPORTANT: To make sure the switch is securely installed in the rack, you must install both the mounting brackets and rack mounting rail kit.
  • Page 14 Table 6 Grounding points for the switch Switch model Grounding point Remarks One primary grounding point • HPE 5920AF-24XG. (with a grounding sign) and one • HPE 5920AF-24XG TAA. auxiliary grounding point • HPE 5900AF-48XG-4QSFP+. • HPE 5900AF-48XG-4QSFP+ TAA. • •...
  • Page 15 Figure 6 Mounting and grounding positions of the HPE 5900AF-48XG-4QSFP+/ 5900AF-48XG-4QSFP+ TAA/5900CP-48XG-4QSFP+/5900CP-48XG-4QSFP+ TAA/ 5900CP-48XG-4QSFP+8Gb FC B-F/5900AF-48XGT-4QSFP+/5900AF-48XGT-4QSFP+ TAA switch (1) Auxiliary grounding point 2 (2) Rear mounting position (3) Primary grounding point (4) Auxiliary grounding point 1 (5) Front mounting position Figure 7 Mounting and grounding positions of the HPE 5900AF-48G-4XG-2QSFP+/5900AF-48G-4XG-2QSFP+ TAA switch (1) Auxiliary grounding point 2...
  • Page 16 NOTE: Secure the mounting brackets and chassis rails to both sides of the chassis in the same way. Connecting the grounding cable CAUTION: The primary grounding point and auxiliary grounding point 1 are located on the left side panel. If you use one of these grounding points, you must connect the grounding cable to the grounding point before you mount the switch in the rack.

  • Page 17: Attaching The Slide Rails To The Rack

    Figure 9 Attaching the front mounting brackets/chassis rails to the chassis Attaching the slide rails to the rack Identify the rack attachment position for the slide rails. Install cage nuts (user-supplied) in the mounting holes in the rack posts. Align the screw holes in one slide rail with the cage nuts in the rack post on one side, and use screws (user supplied) to attach the slide rail to the rack, as shown in Figure Repeat the preceding step to attach the other slide rail to the rack post on the other side.
  • Page 18 Verify that the mounting brackets and chassis rails have been securely attached to the switch chassis. Verify that the slide rails have been correctly attached to the rear rack posts. Install cage nuts (user-supplied) to the front rack posts and make sure they are at the same level as the slide rails.

  • Page 19: Grounding The Switch

    Figure 12 Mounting the switch in the rack (2) Grounding the switch WARNING! Correctly connecting the switch grounding cable is crucial to lightning protection and EMI protection. The power input end of the switch has a noise filter, whose central ground is directly connected to the chassis to form the chassis ground (commonly known as PGND).

  • Page 20: Grounding The Switch By Using The Ac Power Cord

    Attach the two-hole grounding lug at one end of the grounding cable to a grounding point on the switch chassis. See "Connecting the grounding cable." Remove the hex nut of a grounding post on the grounding strip. Attach the ring terminal at the other end of the grounding cable to a grounding post on the grounding strip, and fasten the ring terminal with the removed hex nut.

  • Page 21: Installing/Removing A Fan Tray

    Figure 14 Grounding through the PE wire of the AC power cord (1) Three-wire AC power cable (2) Chassis rear panel NOTE: To guarantee the grounding effect, use the grounding cable provided with the switch to connect to the grounding strip in the equipment room as long as possible. Installing/removing a fan tray CAUTION: To ensure good ventilation for the switch:...

  • Page 22: Removing A Fan Tray

    Figure 15 Installing an LSWM1FANSC/LSWM1FANSCB/LSWM1HFANSC/LSWM1HFANSCB fan tray (HPE 5900AF-48XG-4QSFP+) Figure 16 Installing an LSVM1FANSC/LSVM1FANSCB fan tray (HPE 5920AF-24XG) Removing a fan tray WARNING! • Do not take out the fan tray until the fans completely stop rotating. • Never touch the fans and rotation axis. To remove a fan tray: Wear an ESD wrist strap and make sure it makes good skin contact and is reliably grounded.

  • Page 23: Installing/Removing A Power Supply

    Installing/removing a power supply WARNING! • Do not install AC and DC power supplies on the same switch. • Provide a circuit breaker for each power supply and make sure the circuit breaker is off before installation. • In power redundancy mode, you can replace a power supply without powering off the switch but must strictly follow the installation and procedures in Figure 17 Figure 18...

  • Page 24: Removing A Power Supply

    Figure 19 Installing a power supply Figure 20 Installing a filler module Removing a power supply CAUTION: • If the switch has two power supplies, removing one power supply does not affect the operation of the switch. If the switch has only one power supply, removing the power supply powers off the switch.
  • Page 25 Figure 21 Removing the DC power cord (1) Press the tabs on the power cord connector (2) Pull the power cord connector out with your thumb and forefinger Figure 22 Removing the power supply (1) Pivot the latch to the right with your thumb (2) Pull the power supply out...

  • Page 26: Connecting The Power Cord

    Connecting the power cord CAUTION: • Provide a circuit breaker for each power supply. • Before you connect the power cord for a power supply, make sure the circuit breaker for the power supply is turned off. Connecting the 650W AC power supply Insert the female connector of the AC power cord supplied with the power supply into the power receptacle on the power supply.

  • Page 27: Verifying The Installation

    Connect the other ends of the wires to the DC power source wiring terminals, with the negative wire (– or L–) to the negative terminal (–) and the positive wire (+ or M/N) to the positive terminal (+). Figure 24 Connecting the 650W DC power supply Verifying the installation After you complete the installation, verify the following information: •...

  • Page 28: Accessing The Switch For The First Time

    Accessing the switch for the first time Setting up the configuration environment The first time you access the switch you must use a console cable to connect a configuration terminal, for example, a PC, to the console port on the switch. Figure 25 Connecting the console port to a terminal Connecting the console cable A console cable is an 8-core shielded cable, with a crimped RJ-45 connector at one end for...

  • Page 29: Setting Terminal Parameters

    RJ-45 Signal DB-9 Signal To connect a terminal (for example, a PC) to the switch: Plug the DB-9 female connector of the console cable to the serial port of the PC. Connect the RJ-45 connector to the console port of the switch. NOTE: •...

  • Page 30: Setting Up An Irf Fabric

    Setting up an IRF fabric You can use HPE IRF technology to connect and virtualize the switches into a large virtual switch called an "IRF fabric" for flattened network topology, and high availability, scalability, and manageability. To set up IRF links between the switches, use SFP+ ports, 1/10-GE Ethernet ports, or QSFP+ ports. IRF fabric setup flowchart Figure 27 IRF fabric setup flowchart To set up an IRF fabric:...

  • Page 31: Planning Irf Fabric Setup

    Step Description Install IRF member "Installing the switch in a 19-inch rack." switches. Connect ground wires "Grounding the switch" and "Connecting the power cord." and power cords. Power on the switches. Configure basic IRF See HPE 5920 & 5900 Switch Series IRF Configuration Guide. settings.

  • Page 32: Planning Irf Topology And Connections

    Planning IRF topology and connections You can create an IRF fabric in daisy chain topology, or more reliably, ring topology. In ring topology, the failure of one IRF link does not cause the IRF fabric to split as in daisy chain topology. Rather, the IRF fabric changes to a daisy chain topology without interrupting network services.

  • Page 33: Planning The Cabling Scheme

    Table 8 Physical ports available for IRF connections Switch model Physical port available for IRF connections • HPE 5900AF-48XG-4QSFP+ • HPE 5900AF-48XG-4QSFP+ TAA • HPE 5900CP-48XG-4QSFP+ • SFP+ port • HPE 5900CP-48XG-4QSFP+ TAA • QSFP+ port • HPE 5900CP-48XG-4QSFP+8Gb FC B-F •...
  • Page 34 Table 9 Cabling schemes Switch model Cabling scheme Remarks • HPE 5920AF-24XG • HPE 5920AF-24XG TAA • HPE 5900AF-48XG-4QSFP+ If the IRF member switches • are far away from one HPE 5900AF-48XG-4QSFP+ another, choose the • SFP+/QSFP+ transceiver • SFP+/QSFP+ network cables HPE 5900CP-48XG-4QSFP+ modules with optical fibers.

  • Page 35: Configuring Basic Irf Settings

    Figure 31 IRF fabric topology Connecting the IRF member switches in a ToR solution You can install IRF member switches in different racks side by side to deploy a top of rack (ToR) solution. shows an example for connecting four top of rack IRF member switches by using Figure 32 SFP+/QSFP+ network cables, and SFP+/QSFP+ transceiver modules, and optical fibers.

  • Page 36: Accessing The Irf Fabric To Verify The Configuration

    NOTE: Wear an ESD wrist strap when you connect SFP+ network cables or SFP+ transceiver modules and fibers. For how to connect them, see SFP/SFP+/XFP Transceiver Modules Installation Guide and QSFP+ Transceiver Modules/Cables Installation Guide. Accessing the IRF fabric to verify the configuration To verify the basic functionality of the IRF fabric after you finish configuring basic IRF settings and connecting IRF ports: Log in to the IRF fabric through the console port of any member switch.

  • Page 37: Maintenance And Troubleshooting

    Maintenance and troubleshooting Power supply failure You can use the LEDs on the power supply to identify a power supply failure. For more information about the LEDs on a power supply, see HPE A58x0AF 650W AC (JC680A) & 650W DC (JC681A) Power Supplies User Guide or HPE FlexFabric Switch 650W 48V Hot Plug NEBS Compliant DC Power Supply (JH336A) User Guide.

  • Page 38: Garbled Display On The Configuration Terminal

    Baud rate—9600. Data bits—8. Parity—None. Stop bits—1. Flow control—None. Verify that the console cable is not faulty. If the problem persists, contact Hewlett Packard Enterprise Support. Garbled display on the configuration terminal The configuration terminal displays garbled text. To resolve the problem: Verify that the following settings are configured for the terminal: Baud rate—9600.

  • Page 39: Appendix A Chassis Views And Technical Specifications

    Appendix A Chassis views and technical specifications Chassis views HPE 5920AF-24XG/HPE 5920AF-24XG TAA Figure 33 Front panel (1) SFP+ port (2) SFP+ port LED (3) Management Ethernet port (4) Console port (5) System status LED (SYS) (6) ACT LED for the management Ethernet port (7) LINK LED for the management Ethernet port Figure 34 Rear panel (1) Power supply slot 1...

  • Page 40: Hpe 5900Af-48Xg-4Qsfp+/Hpe 5900Af-48Xg-4Qsfp+ Taa/Hpe 5900Cp-48Xg-4Qsfp+/Hpe 5900Cp-48Xg-4Qsfp+ Taa/Hpe 5900Cp-48Xg-4Qsfp+8Gb Fc B-F

    Figure 35 Left side panel (1) Primary grounding point (2) Auxiliary grounding point 1 HPE 5900AF-48XG-4QSFP+/HPE 5900AF-48XG-4QSFP+ TAA/HPE 5900CP-48XG-4QSFP+/HPE 5900CP-48XG-4QSFP+ TAA/HPE 5900CP-48XG-4QSFP+8Gb FC B-F Figure 36 Front panel (1) SFP+ port (2) SFP+ port LED (3) QSFP+ port (4) QSFP+ port LED (5) System status LED (SYS) Figure 37 Rear panel (1) Grounding screw (auxiliary grounding point 2)

  • Page 41: Hpe 5900Af-48Xgt-4Qsfp+/Hpe 5900Af-48Xgt-4Qsfp+ Taa

    The HPE 5900AF-48XG-4QSFP+, 5900AF-48XG-4QSFP+ TAA, FlexFabric 5900CP 48XG 4QSFP+, 5900CP-48XG-4QSFP+ TAA, and 5900CP-48XG-4QSFP+8Gb FC B-F switches also come with the fan tray slots empty. You must install two fan trays for the HPE 5900AF-48XG-4QSFP+, 5900AF-48XG-4QSFP+ TAA, 5900CP-48XG-4QSFP+, 5900CP-48XG-4QSFP+ TAA, and 5900CP-48XG-4QSFP+8Gb FC B-F for adequate heat dissipation, and their models must be the same.

  • Page 42: Hpe 5900Af-48G-4Xg-2Qsfp+/Hpe 5900Af-48G-4Xg-2Qsfp+ Taa

    The HPE 5900AF-48XGT-4QSFP+ and 5900AF-48XGT-4QSFP+ TAA switches come with the power supply slots empty and the filler modules for the slots as accessories. You can install one or two power supplies for the switch as needed. In Figure 43, two 650W AC power supplies are installed.
  • Page 43 Figure 43 Rear panel (1) Grounding screw (auxiliary grounding point 2) (2) Management Ethernet port (3) Console port (4) Fan tray slot 1 (5) Fan tray slot 2 (6) Power supply slot 1 (7) Power supply slot 2 (8) LINK LED for the management Ethernet port (9) ACT LED for the management Ethernet port (10) USB port The HPE 5900AF-48G-4XG-2QSFP+ and 5900AF-48G-4XG-2QSFP+ TAA switches come with the...

  • Page 44: Technical Specifications

    Technical specifications 5900AF-48XG-4 QSFP+/HPE 5900AF-48XG-4 QSFP+ TAA/HPE 5900AF-48G-4X 5900AF-48XGT-4 5920AF-24XG/H 5900CP-48XG-4 Item G-2QSFP+/HPE QSFP+/HPE PE 5920AF-24XG QSFP+/HPE 5900AF-48G-4X 5900AF-48XGT-4 5900CP-48XG-4 G-2QSFP+ TAA QSFP+ TAA QSFP+ TAA/HPE 5900CP-48XG-4 QSFP+8Gb FC 43.6 × 440 × 700 43.6 × 440 × 660 43.6 × 440 × 460 43.6 ×...
  • Page 45 5900AF-48XG-4 QSFP+/HPE 5900AF-48XG-4 QSFP+ TAA/HPE 5900AF-48G-4X 5900AF-48XGT-4 5920AF-24XG/H 5900CP-48XG-4 Item G-2QSFP+/HPE QSFP+/HPE PE 5920AF-24XG QSFP+/HPE 5900AF-48G-4X 5900AF-48XGT-4 5900CP-48XG-4 G-2QSFP+ TAA QSFP+ TAA QSFP+ TAA/HPE 5900CP-48XG-4 QSFP+8Gb FC • • • • Single AC Single AC Single AC Single AC input: 334 W input: 183 W input: 98 W input: 124 W...

  • Page 46: Appendix B Frus And Compatibility Matrixes

    Appendix B FRUs and compatibility matrixes This appendix describes the field replaceable units (FRUs) available for the HPE 5920 and 5900 Switch Series and their compatibility. All the FRUs in this appendix are hot swappable. Power supplies Power Specifications Switch model Reference supply •...
  • Page 47 Item Specifications Back to front Airflow direction (Fans blow air from the power supply side to the network port side.) Input voltage 12 V Maximum power consumption 19.5 W Documentation reference HPE LSWM1FANSC & LSWM1FANSCB Fan Assemblies Installation LSWM1FANSCB (for the HPE 5900AF-48XG-4QSFP+, 5900AF-48XG-4QSFP+ TAA, 5900CP-48XG-4QSFP+, 5900CP-48XG-4QSFP+ TAA, 5900CP-48XG-4QSFP+8Gb FC B-F, 5900AF-48G-4XG-2QSFP+, and 5900AF-48G-4XG-2QSFP+ TAA switches) Fans...
  • Page 48 Item Specifications LSVM1FANSC ( for the HPE 5920AF-24XG and 5920AF-24XG TAA switches) Fans Three 40 × 40 × 28 mm (1.57 × 1.57 × 1.1 in) fans Fan speed 18500 R.P.M Max airflow 57 CFM Back to front Airflow direction (Fans blow air from the power supply side to the network port side.) Input voltage 12 V...

  • Page 49: Appendix C Ports And Leds

    Appendix C Ports and LEDs Ports Console port The switch has one console port. Table 11 Console port specifications Item Specification Connector type RJ-45 Compliant standard EIA/TIA-232 Transmission baud rate 9600 bps (default) to 115200 bps • Provides connection to an ASCII terminal. •...

  • Page 50: Sfp+ Port

    SFP+ port The following switches provide SFP+ ports: • HPE 5920AF-24XG. • HPE 5920AF-24XG TAA. • HPE 5900AF-48XG-4QSFP+. • HPE 5900AF-48XG-4QSFP+ TAA. • HPE 5900CP-48XG-4QSFP+. • HPE 5900CP-48XG-4QSFP+ TAA. • HPE 5900CP-48XG-4QSFP+8Gb FC B-F. • HPE 5900AF-48G-4XG-2QSFP+. • HPE 5900AF-48G-4XG-2QSFP+ TAA. You can install the 1000 Mbps SFP transceiver modules in Table 13, the SFP+ transceiver modules...
  • Page 51 Table 14 10 G SFP+ transceiver modules available for the SFP+ ports Modal Central Fiber Product bandwidth wavelength Connector diameter transmission Code description (MHz × (nm) (µm) distance 300 m (984.25 2000 Multi-mod HPE X130 e, 50/125 82 m (269.03 ft) 10G SFP+ JD092B 66 m (216.54 ft)

  • Page 52: Qsfp+ Port

    NOTE: • As a best practice, use HPE 1000 Mbps SFP transceiver modules, SFP+ transceiver modules, or SFP+ network cables for the SFP+ ports on the switch. The HPE SFP and SFP+ transceiver modules and SFP+ network cables are subject to change over time. For the most up-to-date list of SFP and SFP+ transceiver modules and SFP+ network cables, contact your Hewlett Packard Enterprise sales representative or technical support engineer.

  • Page 53: 10/100/1000Base-T Autosensing Ethernet Port

    Figure 46 40G QSFP+ network cable (1) Connector (2) Pull latch Figure 47 40G QSFP+ to 4 x 10G SFP+ network cable (1) QSFP+ module (2) QSFP+ side pull latch (3) SFP+ side pull latch (4) SFP+ module For more information about the QSFP+ transceiver module and QSFP+ network cables, see HPE Comware-Based Devices Transceiver Modules User Guide.

  • Page 54: 1/10Gbase-T Autosensing Ethernet Port

    Table 18 10/100/1000Base-T autosensing Ethernet port specifications Item Specification Connector type RJ-45 Port transmission rate 10/100/1000 Mbps, half/full duplex, MDI/MDI-X autosensing Transmission medium and max 100 m (328.08 ft) over category-5 twisted pair cable transmission distance • IEEE 802.3i • IEEE 802.3u Compatible standards •...

  • Page 55: Sfp+ Port Led

    Table 20 System status LED description LED mark Status Description Steady green The switch is operating correctly. Flashing green The switch is performing power-on self test (POST). The system has failed to pass POST or has problems such Steady red as fan failure.

  • Page 56: Management Ethernet Port Leds

    Management Ethernet port LEDs A management Ethernet port has one LINK LED and one ACT LED to show its link and data transmission status. Table 23 Management Ethernet port LEDs description LED mark Status Description The management Ethernet port is not connected. LINK Steady green The management Ethernet port is operating at 10/100/1000 Mbps.

  • Page 57: Appendix D Cooling System

    Appendix D Cooling system The cooling system of the switch includes the ventilation holes in the chassis, fan trays, and built-in fans of power supplies. To guarantee that this cooling system can effectively work, you must consider the site ventilation design when you plan the installation site for the switches. HPE 5920 cooling system The fan trays in the HPE 5920AF-24XG and 5920AF-24XG TAA switches must be the same type: LSVM1FANSC or LSVM1FANSCB.

  • Page 58: Hpe 5900 Cooling System

    Figure 49 Airflow through the chassis (with LSVM1FANSCB fan trays) (1) Fan tray air vents (2) Power supply air vents (3) Network port-side air vents IMPORTANT: The chassis and the power supplies use separate air aisles. Make sure both aisles are not blocked. HPE 5900 cooling system Table 26 describes fan trays available for the HPE 5900 switches.
  • Page 59 Figure 50 Airflow through the HPE 5900AF-48XG-4QSFP+ chassis (with LSWM1FANSC fan trays) (1) Power supply air vents (2) Fan tray air vents (3) Network port-side air vents Figure 51 Airflow through the HPE 5900AF-48XG-4QSFP+ chassis (with LSWM1FANSCB fan trays) (1) Power supply air vents (2) Fan tray air vents (3) Network port-side air vents IMPORTANT:...

  • Page 60: Document Conventions And Icons

    Document conventions and icons Conventions This section describes the conventions used in the documentation. Port numbering in examples The port numbers in this document are for illustration only and might be unavailable on your device. Command conventions Convention Description Boldface Bold text represents commands and keywords that you enter literally as shown.

  • Page 61: Network Topology Icons

    Convention Description An alert that provides helpful information. TIP: Network topology icons Convention Description Represents a generic network device, such as a router, switch, or firewall. Represents a routing-capable device, such as a router or Layer 3 switch. Represents a generic switch, such as a Layer 2 or Layer 3 switch, or a router that supports Layer 2 forwarding and other Layer 2 features.

  • Page 62: Support And Other Resources

    Hewlett Packard Enterprise Support Center More Information on Access to Support Materials page: www.hpe.com/support/AccessToSupportMaterials IMPORTANT: Access to some updates might require product entitlement when accessed through the Hewlett Packard Enterprise Support Center. You must have an HP Passport set up with relevant entitlements.

  • Page 63: Websites

    Websites Website Link Networking websites Hewlett Packard Enterprise Information Library for www.hpe.com/networking/resourcefinder Networking Hewlett Packard Enterprise Networking website www.hpe.com/info/networking Hewlett Packard Enterprise My Networking website www.hpe.com/networking/support Hewlett Packard Enterprise My Networking Portal www.hpe.com/networking/mynetworking Hewlett Packard Enterprise Networking Warranty www.hpe.com/networking/warranty General websites Hewlett Packard Enterprise Information Library www.hpe.com/info/enterprise/docs Hewlett Packard Enterprise Support Center...

  • Page 64: Documentation Feedback

    Documentation feedback Hewlett Packard Enterprise is committed to providing documentation that meets your needs. To help us improve the documentation, send any errors, suggestions, or comments to Documentation Feedback (docsfeedback@hpe.com). When submitting your feedback, include the document title, part number, edition, and publication date located on the front cover of the document. For online help content, include the product name, product version, help edition, and publication date located on the legal notices page.

  • Page 65: Index

    Index Numerics rail, views, 1/10GBase-T autosensing Ethernet cleanliness port, installation site, port LED, compatibility matrixes, 10/100/1000 Base-T autosensing Ethernet configuring port, accessing IRF fabric to verify the configuration, port LED, IRF basic settings, 19-inch rack switch, switch installation, troubleshooting configuration terminal problems, connecting AC power supply...
  • Page 66 grounding switch through AC power supply 1/10GBase-T autosensing Ethernet port technical PE wire, specifications, grounding switch with grounding strip, 10/100/1000 Base-T autosensing Ethernet port LED technical specifications, grounding the switch, 10/100/1000 Base-T autosensing Ethernet port power supply installation, 19, technical specifications, power supply removal, 19, connecting AC power supply, powering on switch,...
  • Page 67 rack chassis rails, member rack mounting bracket, configuring IRF member switch basic settings, rack mounting grounding cable, connecting IRF physical ports, rack requirement, identifying IRF member switch physical ports, safety recommendations, IRF member ID, site cleanliness, site humidity, troubleshooting fan failure, site temperature, switch, network management...
  • Page 68 preparing for installation, mounting the switch, preventing rack mounting rail kit, EMI prevention, requirement, procedure switch installation on 19-inch rack, configuring IRF basic settings, verifying switch installation (19-inch rack), connecting AC power supply, removing connecting DC power supply, fan tray, 17, connecting IRF physical ports, power supply, 19, connecting power cable,...
  • Page 69 grounding with grounding strip, troubleshooting garbled display on the configuration terminal, identifying IRF master switch, troubleshooting no display on the configuration identifying IRF member switch physical terminal, ports, tools needed for installation, installation, topology LEDs, planning IRF cabling scheme, 29, maintaining, topology (IRF fabric), maintaining the switch,...
