- Page 1 Electric Ceramic Hob Instruction Manual Model number(s): RH77EH6001 For Customer Services & Spare Parts please call 0345 208 8750 or visit us at https://mda.russellhobbs.com IMPORTANT: RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
Contents Safety Instructions ………………………………………. Product Overview ………………………………………. Positioning ………………………………………. Installation ………………………………………. 9-10 Usage ………………………………………. 11-24 Cleaning & Maintenance ………………………………………. 25-26 Trouble shooting ………………………………………. Guarantee ………………………………………. Technical specification ………………………………………. Notes ………………………………………. 30-31... -
Page 3: Safety Instructions
Safety Instructions Important note: Please read this booklet before installing and switching on this appliance. The manufacturer assumes no responsibility for incorrect installation and usage as described in this booklet. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand... - Page 4 Safety Instructions • This appliance can only be installed in a well-ventilated place. • This appliance is intended for domestic use and the household environment only. The appliance is not intended for use outside. • Do not tamper with the appliance's interior. If necessary, call our customer helpline •...
- Page 5 Safety Instructions • Cracks or fractures in the glass ceramic may cause electric shocks. Switch off the circuit breaker in the fuse box. Contact the customer services. • Components inside the appliance may have sharp edges. Wear protective gloves. • Saucepans may suddenly move due to liquid between the pan base and the hotplate.
-
Page 6: Product Overview
Product overview 1. Hob Timer indicator & control 2. Cooking zones Zone indicator controls & 1800W (max) power level indicator 1000W/2200W (max) Controls 1800W (max) 4 x Brackets 1200W (max) 4 x Screws 1200W (max) Unit & Spare Parts If any of the above parts are missing please contact the customer service team on 0345 208 8750 or visit https://mda.russellhobbs.com... -
Page 7: Positioning
Positioning • This appliance is to be installed in a counter top. • Avoid damaging the product during installation. • The appliance can only be used safely if it is correctly installed according to the safety instructions. The installer is responsible for ensuring that the appliance works correct when installed. - Page 8 Positioning • Be sure the thickness of the work surface is at least 30mm • You must have a gap of a minimum gap of 25mm between the underside of the appliance and any surface below it. Note: • Select heat-resistant work surface material to avoid larger deformation caused by the heat radiation from the appliance.
-
Page 9: Installation
Installation Preparation & installation Ensure that there are no electric wires, gas or water pipes in the area where holes are to be made. Components of the appliance may have sharp edges. Wear protective gloves. 1. Ensure that there is an electrical connection within adequate distance of the hob after it has been installed. -
Page 10: Electrical Connection
Installation Electrical connection • WARNING- THIS APPLIANCE MUST BE EARTHED • This appliance is designed to be connected to a 220-240V~50Hz/60Hz AC electricity supply. • Before proceeding with the electrical connection, verify that the current carrying capacity of the system and the isolator / main switch is adequate for the maximum power rating of the hob. -
Page 11: Usage
Usage Controls The appliance has 5 cooking zones and these are controlled by the touch controls at the bottom of the hob. Just above the cooking zone power controls there are the cooking zone selection controls and to the left of the cooking zone controls is the timer indicator: The function of each touch control and the meaning of each icon is explained below:... -
Page 12: Using The Touch Controls
Usage Using the touch controls The controls respond to touch, so you don’t need to apply pressure to them. Below are tips on how to use the controls: • Use the ball of your finger, not its tip. • You will hear a beep each time a touch is registered. •... -
Page 13: Power Levels
Usage Power levels The settings below are guidelines only, the exact setting you will require will depend on several factors, including your cookware and the amount you are cooking. Experiment with the hob to find the settings that best suit you. Heat setting Suitability Delicate warming for small amounts of food... - Page 14 Usage To use a cooking zone Note: • When you touch a symbol, the respective function is activated. • Always keep the controls dry. Moisture reduces their effectiveness. • Do not pull pans close to the displays and sensors. The electronics could overheat.
- Page 15 Usage 5. Use the power level controls to select the required power, this will be shown on the cooking zone indicator of the cooking zone that is being used. 6. You can modify the power setting of a cooking zone at any time during cooking.
- Page 16 Usage Dual ring function The function is only available on cooking zone B The dual ring has two cooking areas that you can use, a central section and an outer section. You can use the central section (A) independently or both sections (B) at once.
-
Page 17: Locking The Controls
Usage 4. Press the dual ring control ‘ ‘ , dual ring function will be de-activate. The power level indicator will return to 6. Locking the controls You can lock the controls to prevent unintended use (for example children accidentally turning the cooking zones on). To lock the controls touch the child lock control, the timer indicator will show ‘Lo’. -
Page 18: Using The Timer
Usage Using the Timer You can use the timer in two different ways: 1. As a minute minder - in this case, the timer will not turn any cooking zone off when the set time is up. 2. To turn one cooking zone off after the set time is up. Note: You can set the timer for up to 99 minutes. - Page 19 Usage 4. Set the time by touching power controls. 5. When the time is set, it will begin to count down immediately. The display will show the remaining time and the timer indicator will flash for 5 seconds. 6. When the time has counted down the hob will beep for 30 seconds and the timer indicator will show ‘- -’.
- Page 20 Usage Setting the timer to turn one cooking zone off Make sure the hob is turned on and that a suitable pan has been placed on the zone you wish to use. Make sure the bottom of the pan and the surface of the pan support are clean and dry.
- Page 21 Usage 6. Set the time by touching power controls. 7. When the time is set, it will begin to count down immediately. The display will show the remaining time and the timer indicator will flash for 5 seconds. 8. When the time has counted down the hob will beep once, the timer indicator will show ‘- -’...
-
Page 22: Residual Heat Warning
Usage Residual heat warning When the hob has been operated there will be some residual heat. The display of controls of which ever cooking zone has been used will show a ‘H’ symbol to warn you of the residual heat and to keep away from it. The ‘H’... - Page 23 Usage Pans & energy saving The following advice is to prevent damage to pans and help you save energy: Zones Suitable pan sizes (diameter) 1000W (max) 140mm 1200W (max) 160mm 1800W (max) 200mm 2200W (max) 240mm Do not use small pans on large Always use pans that are the zones right size for each zone...
-
Page 24: Cooking Recommendations
Usage Cooking recommendations: The following advice is to help you get the best cooking performance/results: Zone Very high, High Medium Boiling, steaming, griddling, Reheating and keeping things hot: toasting, paellas, Asian food cooked and pre-cooked dishes. 1800W (max) - (wok). 2200W (max) Rice, white Escalopes, steaks, omelettes,... -
Page 25: Cleaning & Maintenance
Cleaning and Maintenance: Important notes: • The appliance will become hot during operation, allow the appliance to cool down before cleaning. • Do not use any high-pressure cleaners or steam cleaners. • Wash new sponge cloths thoroughly before use. • Follow all instructions and warnings included with the cleaning agents. How to clean Observe the information in the table below to ensure the surfaces is not damaged by using the wrong type of cleaning agent. -
Page 26: How To Clean
Cleaning and Maintenance: How to clean: • After each use, clean the surface of each zone once they have cooled down. If any residue is left (baked-on food, drops of grease etc.), however little, it will become stuck to the surface and more difficult to remove later. •... -
Page 27: Trouble Shooting
Trouble Shooting: Problem Solution The circuit breaker is defective or turned off check circuit breaker is in working order and that it is not switched off. No power Power cut or faulty fuse Check whether other kitchen appliances are working or check in the fuse box to make sure that the fuse for the appliance is working The child lock/control lock is operational... -
Page 28: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship you must contact Product Care with the original proof of purchase so a replacement or refund can be arranged. Refund or replacement is at the discretion of Product Care. -
Page 29: Technical Specification
Technical Specification Model number RH77EH6001 Rated Voltage 220V – 240V ~ 50Hz/60Hz External Dimensions(HxWxD) 55mm x 770mm x 520mm... -
Page 30: Notes
Notes... - Page 31 Notes...
- Page 32 For Customer Services & Spare Parts please call 0345 208 8750 or visit us at https://mda.russellhobbs.com This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that the product/batteries should not be disposed of with your general household waste. Only discard electrical/electronic/battery items in separate collection schemes, which cater for the recovery and recycling of materials contained within.
