- Page 1 Induction Electric Hob Instruction Manual Model number(s): RH60IH401B For Customer Services & Spare Parts please call 0345 208 8750 or visit us at https://mda.russellhobbs.com IMPORTANT: RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
Contents Safety Instructions ………………………………………. Product Overview ………………………………………. Positioning ………………………………………. Installation ………………………………………. 9-10 Usage ………………………………………. 11-23 Cleaning & Maintenance ………………………………………. 24-25 Trouble shooting ………………………………………. 26-27 Fault codes ………………………………………. Guarantee ………………………………………. Technical specification ………………………………………. Notes ………………………………………. -
Page 3: Safety Instructions
Safety Instructions Important note: Please read this booklet before installing and switching on this appliance. The manufacturer assumes no responsibility for incorrect installation and usage as described in this booklet. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand... - Page 4 Safety Instructions • This appliance can only be installed in a well-ventilated place. • This appliance is intended for domestic use and the household environment only. The appliance is not intended for use outside. • Do not tamper with the appliance's interior. If necessary, call our customer helpline •...
- Page 5 Safety Instructions • Cracks or fractures in the glass ceramic may cause electric shocks. Switch off the circuit breaker in the fuse box. Contact the customer services. • Components inside the appliance may have sharp edges. Wear protective gloves. • Saucepans may suddenly move due to liquid between the pan base and the hotplate.
-
Page 6: Product Overview
Product overview 1. Hob Cooking zone indicators 2. Cooking zones Controls 2000W (max) 2 x Brackets 1500W (max) 2 x Screws 1500W (max) 2000W (max) Unit & Spare Parts If any of the above parts are missing please contact the customer service team on 0345 208 8750 or visit https://mda.russellhobbs.com... -
Page 7: Positioning
Positioning • This appliance is to be installed in a counter top. • Avoid damaging the product during installation. • The appliance can only be used safely if it is correctly installed according to the safety instructions. The installer is responsible for ensuring that the appliance works correct when installed. - Page 8 Positioning • Be sure the thickness of the work surface is at least 30mm • You must have a gap of a minimum gap of 25mm between the underside of the appliance and any surface below it. Note: • Select heat-resistant work surface material to avoid larger deformation caused by the heat radiation from the appliance.
-
Page 9: Installation
Installation Preparation & installation Ensure that there are no electric wires, gas or water pipes in the area where holes are to be made. Components of the appliance may have sharp edges. Wear protective gloves. 1. Ensure that that there is an electrical plug socket within adequate distance of the hob after it has been installed. - Page 10 Installation Electrical connection • WARNING- THIS APPLIANCE MUST BE EARTHED • This appliance is designed to be connected to a 220-240V ~ 50Hz AC electricity supply. • Before proceeding with the electrical connection, verify that the current carrying capacity of the system and the isolator / main switch is adequate for the maximum power rating of the hob.
- Page 11 Induction introduction Induction hobs only heat the pan rather than the cooking surface heating up like a standard electric hob. They do this by creating a magnetic field between the pan base and an element underneath the glass top; this makes induction hobs safer and cheaper to run as they use only the precise amount of energy you need.
-
Page 12: Usage
Usage Controls The appliance has 4 cooking zones and these are controlled by the touch controls at the bottom of the hob. To use a cooking zone you must press the required cooking zone indicator/on control of the cooking zone before being able to set the power level. - Page 13 Usage Using the touch controls The controls respond to touch, so you don’t need to apply pressure to them. Below are tips on how to use the controls: • Use the ball of your finger, not its tip. • You will hear a beep each time a touch is registered. •...
- Page 14 Usage Power levels The settings below are guidelines only, the exact setting you will require will depend on several factors, including your cookware and the amount you are cooking. Experiment with the induction hob to find the settings that best suit you. Heat setting Suitability Delicate warming for small amounts of food...
- Page 15 Usage To use a cooking zone Note: • When you touch a symbol, the respective function is activated. • Always keep the controls dry. Moisture reduces their effectiveness. • Do not pull pans close to the displays and sensors. The electronics could overheat.
- Page 16 Usage 5. Set the power level of the required cooking zone by touching the controls. The first power level that will be shown on the indicator will be 5. 6. You can modify the power setting of a cooking zone at any time during cooking.
- Page 17 Usage Locking the controls You can lock the controls to prevent unintended use (for example children accidentally turning the cooking zones on). To lock the controls touch the child lock control, the timer indicator will show ‘Lo’. Note: When the controls are locked, all the controls except the Power on/off control are disabled.
- Page 18 Usage 2. Set the time by touching the control of the timer. By touching these controls the timer will increase or decrease by 1 minute but if you touch and hold these controls the timer will increase or decrease by 10 minutes. If the setting time exceeds 99 minutes, the timer will automatically return to 0 minute.
- Page 19 Usage Setting the timer to turn one cooking zone off Make sure the hob is turned on and that a suitable pan has been placed on the zone you wish to use. Make sure the bottom of the pan and the surface of the pan support are clean and dry.
- Page 20 Usage 5. When the time is set, it will begin to count down immediately. The display will show the remaining time and the timer indicator will flash for 5 seconds. 6. Please note that the red dot next to power level indicator will illuminate indicating that zone is selected.
- Page 21 Usage Residual heat warning When the hob has been operated there will be some residual heat. The display of controls of which ever cooking zone has been used will show a ‘H’ symbol to warn you of the residual heat and to keep away from it. The ‘H’...
- Page 22 Usage Pans & energy saving The following advice is to prevent damage to pans and help you save energy: Zones Suitable pan sizes (diameter) 1500W (max) 180mm 2000W (max) 200mm Do not use small pans on large Always use pans that are the zones right size for each zone Do not cook without a lid or...
- Page 23 Usage Cooking recommendations: The following advice is to help you get the best cooking performance/results: Zone Very high, High Medium Boiling, steaming, griddling, Reheating and keeping things hot: toasting, paellas, Asian food cooked and pre-cooked dishes. (wok). 2000W (max) Rice, white Escalopes, steaks, omelettes, Steaming: fish, sauce and...
-
Page 24: Cleaning & Maintenance
Cleaning and Maintenance: Important notes: • The appliance will become hot during operation, allow the appliance to cool down before cleaning. • Do not use any high-pressure cleaners or steam cleaners. • Wash new sponge cloths thoroughly before use. • Follow all instructions and warnings included with the cleaning agents. How to clean Observe the information in the table below to ensure that the surface is not damaged by using the wrong type of cleaning agent. - Page 25 Cleaning and Maintenance: How to clean: • After each use, clean the surface of each zone once they have cooled down. If any residue is left (baked-on food, drops of grease etc.), however little, it will become stuck to the surface and more difficult to remove later. •...
-
Page 26: Trouble Shooting
Trouble Shooting: Problem Solution The plug is not plugged in Connect the appliance to the electricity supply Power cut or faulty fuse No power Check whether other kitchen appliances are working or check in the fuse box to make sure that the fuse for the appliance is working The child lock/control lock is operational Controls aren’t... - Page 27 Trouble Shooting: Problem Solution Sliding or dragging pans may scratch the glass Always lift pans off the hob Rough pot and pan bases scratch the ceramic Scratches, Replace cookware discolouration or Spillages can cause discolouration blistering Remove/clean all spillages immediately Sugar can cause the surface to blister Remove/clean all spillages immediately Cookware can become deformed if boiled dry...
-
Page 28: Fault Codes
Fault codes: The hob is equipped with a self diagnostic function and the table below shows the fault codes and the actions that should be taken. Failure code Problem Solution Auto-Recovery Please inspect whether Supply voltage is above the rated power supply is normal. -
Page 29: Guarantee
Refund or replacement is at the discretion of Russell Hobbs. The following conditions apply: • Russell Hobbs will require a valid proof of purchase at the point of replacement or refund. • The product must be installed and used in accordance with the instructions contained in this instruction guide and any other instructions for use which has been supplied. -
Page 30: Technical Specification
Technical Specification Model number RH60IH401B Rated Voltage 220V – 240V ~ 50Hz External Dimensions(HxWxD) 55mm x 590mm x 520mm... -
Page 31: Notes
Notes... - Page 32 For Customer Services & Spare Parts please call 0345 208 8750 or visit us at https://mda.russellhobbs.com This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that the product/batteries should not be disposed of with your general household waste. Only discard electrical/electronic/battery items in separate collection schemes, which cater for the recovery and recycling of materials contained within.
