Stainless steel, air-operated paint spray gun.3000 psi (210 bar) maximum working pressure

Advertisement

INSTRUCTIONS-PARTS LIST
This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.
INSTRUCTIONS
Stainless Steel, Air-Operated
Paint Spray Gun
3000 psi (210 bar) Maximum Working Pressure
Model 238–332, Series A
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
COPYRIGHT 1996, GRACO INC.
Graco Inc. is registered to I.S. EN ISO 9001
308–613
Rev. A
05952
