Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at
8 a.m. - 5 p.m., EST, Friday.
BM19164
welcoming • sophisticated • inspiring
1-866-439-9800, 8 a.m. - 6 p.m., EST, Monday - Thursday,
3-Light Vanity Bar
1
800413
APPROVED FOR USE
IN DAMP LOCATIONS
ITEM #1362612
MODEL
#VBL18-3BNK
Français p. 10
Español p. 19
ATTACH YOUR RECEIPT HERE
1362621
VBL18-3OSB
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Allen + Roth VBL18-3BNK
Summary of Contents for Allen + Roth VBL18-3BNK
- Page 1 • sophisticated • inspiring 800413 APPROVED FOR USE IN DAMP LOCATIONS ® allen + roth is a registered trademark ITEM #1362612 of LF, LLC. All Rights Reserved. 1362621 3-Light Vanity Bar MODEL #VBL18-3BNK VBL18-3OSB Français p. 10 Español p. 19...
- Page 2 TABLE OF CONTENTS Package Contents ........................2 Hardware Contents .......................3 Safety Information ........................3 Preparation ..........................4 Assembly Instructions ......................5 Care and Maintenance ......................9 Troubleshooting ........................9 Warranty ..........................9 PACKAGE CONTENTS PART DESCRIPTION QUANTITY Fixture Mounting Plate (preassembled to fixture (A)) Mounting Plate Screw (preassembled to fixture (A))
- Page 3 HARDWARE CONTENTS (shown actual size) Plastic Wire Machine Fixture Anchor Connector Screw Screw Qty. 2 Qty. 3 Qty. 2 Qty. 2 SAFETY INFORMATION READ AND SAVE THESE INSTRUCTIONS. DANGER • For your protection and safety, carefully read and understand the information provided in this manual completely before attempting to assemble, install or operate this product.
- Page 4 SAFETY INFORMATION WARNING • To reduce the risk of fire, electrical shock or personal injury, wire connectors provided with this light fixture are designed to accept only one 12-gauge house wire and two lead wires from the light fixture. If your house wire is larger than 12-gauge or there is more than one house wire to connect to the corresponding fixture lead wires, consult an electrician for the proper size wire connectors to use.
- Page 5 ASSEMBLY INSTRUCTIONS Turn off circuit breakers and wall switch to the fixture supply line leads. DANGER: Failure to disconnect power supply prior to installation may result in serious injury or death. Remove existing fixture and disconnect all electrical wiring. Remove mounting plate (B) from fixture (A) by removing mounting plate screws (C) from the edges of the fixture (A).
- Page 6 ASSEMBLY INSTRUCTIONS To mount the item directly to an outlet box (not included), attach mounting plate (B) to outlet box using the existing washers and outlet box screws or Washer the machine screws (BB). Note: If the outlet box screws required for your outlet box are of a different size than the machine screws (BB), consult with a licensed electrician before proceeding.
- Page 7 ASSEMBLY INSTRUCTIONS 5. Prepare wires by stripping 1/2 in. of insulation from BLACK wire ends using wire strippers (not included). WHITE Connect BARE/GREEN ground wire from outlet box to BARE ground wire from fixture (A) with wire connector (AA). Connect WHITE wire from fixture (A) to WHITE wire from outlet box using existing wire connector or wire connector (AA).
- Page 8 ASSEMBLY INSTRUCTIONS 6. Wrap electrical tape (not included) around each individual wire connector (AA) down to the wire. WARNING: Make sure no bare wire or wire strands are visible after making connections. Carefully push excess wiring and wire connectors (AA) gently back into outlet box. Outlet 7.
- Page 9 CARE AND MAINTENANCE • Shut off main power supply. Wipe fixture with soft, damp cloth. Use window cleaner to clean glass. Do not use an abrasive cleaner on glass or fixture. • Total wattage for this fixture is 24 watts; do not attempt to replace the LEDs. TROUBLESHOOTING WARNING: Before beginning work, shut off the power supply to avoid electrical shock.
