- Page 1 • sophisticated • inspiring For Damp Location E465631 allen + roth is a registered trademark ® ITEM #0760083 of LF, LLC. All Rights Reserved. 1601738 VANITY LIGHT MODEL #WSL11BNK WSL11MBK Français p.10 Español p.19 ATTACH YOUR RECEIPT HERE Purchase Date...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Contents ........................ 2 Hardware Contents ........................... 3 Safety Information ........................ 3 Preparation ........................... 5 Assembly Instructions ......................5 Care and Maintenance ......................8 Troubleshooting........................9 Warranty ..........................9 PACKAGE CONTENTS PART DESCRIPTION QUANTITY Fixture Mounting Plate (preassembled to fixture (A)) Mounting Plate Screw (preassembled to fixture (A)) -
Page 3: Hardware Contents
HARDWARE CONTENTS (shown actual size) Machine Wire Screw Connector Qty. 2 Qty. 3 SAFETY INFORMATION READ AND SAVE THESE INSTRUCTIONS. DANGER • For your protection and safety, carefully read and understand the information provided in this manual completely before attempting to assemble, install or operate this product. Failure to do so could lead to electrical shock, fire or other injuries that could be hazardous or even fatal. - Page 4 SAFETY INFORMATION • DO NOT suspend any fixture by the house wires. A fixture must always be mounted directly to an outlet box or to a mounting strap that is first attached to the outlet box. Wire connectors will not support the weight of a fixture.
-
Page 5: Preparation
PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Time: 30 minutes Tools Required for Assembly (not included): Flathead Screwdriver, Phillips Screwdriver, Wire Strippers, Pliers, Wire Cutters, Safety Glasses, Stepladder, Electrical Tape Helpful Tools (not included): A/C Tester Light, Do-It-Yourself Guide, Soft Cloth, Level... - Page 6 ASSEMBLY INSTRUCTIONS Remove mounting plate (B) from fixture (A) by removing mounting plate screws (C) from the edges of the fixture (A). Save mounting plate screws (C) for later use. Attach mounting plate (B) to outlet box (not included) using existing washers and outlet box screws or the machine screws (BB).
- Page 7 ASSEMBLY INSTRUCTIONS Unwrap BARE fixture wire from BLACK and WHITE BLACK fixture wires. Prepare wires by stripping 3/4 in. of WHITE insulation from wire ends using wire strippers (not included). Connect WHITE wire from fixture (A) to WHITE wire from outlet box using existing wire connector or wire connector (AA).
-
Page 8: Care And Maintenance
ASSEMBLY INSTRUCTIONS Attach fixture (A) to mounting plate (B) using the mounting plate screws (C) previously removed (Step 3, Page 6). NOTE: Before tightening mounting plate screws (C) completely, use level (not included) to check fixture (A) -- adjust if necessary. Restore power and test fixture (A). -
Page 9: Troubleshooting
TROUBLESHOOTING WARNING: Before beginning work, shut off the power supply to avoid electrical shock. PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION 1. Power is OFF. 1. Make sure power supply is ON. Light does not come on 2. Faulty connection. 2. Check wiring and all connections. initially or no longer 3.
