allen + roth
®
is a registered trademark
of LF, LLC. All Rights Reserved.
ATTACH YOUR RECEIPT HERE
Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at
8 a.m. - 5 p.m., EST, Friday.
AB171084
welcoming • sophisticated • inspiring
Model VBL4-18CH
Model VBL4-24BZ
1-866-439-9800, 8 a.m. - 6 p.m., EST, Monday - Thursday,
VBL4-24BNK
1
800192
APPROVED FOR USE
IN DAMP LOCATIONS
ITEM
#0970848
VANITY LIGHT
MODEL
#VBL4-18CH
VBL4-24BZ
VBL4-24BNK
Français p. 9
Español p. 17
0970849
1010727
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Allen + Roth VBL4-18CH
Summary of Contents for Allen + Roth VBL4-18CH
- Page 1 • sophisticated • inspiring Model VBL4-18CH Model VBL4-24BZ VBL4-24BNK 800192 APPROVED FOR USE IN DAMP LOCATIONS allen + roth ® is a registered trademark ITEM #0970848 of LF, LLC. All Rights Reserved. 0970849 1010727 VANITY LIGHT MODEL #VBL4-18CH VBL4-24BZ VBL4-24BNK Français p.
-
Page 2: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Fixture Mounting Plate (preassembled to fixture (A)) Mounting Plate Screw (preassembled to fixture (A)) HARDWARE CONTENTS (shown actual size) Plastic Wire Anchor Fixture Machine Connector Screw Screw Qty. 2 Qty. 3 Qty. 2 Qty. 2 SAFETY INFORMATION READ AND SAVE THESE INSTRUCTIONS. - Page 3 SAFETY INFORMATION • DO NOT connect the bare or green insulation fixture ground wire to the black (HOT) current-carrying wire or the white (NEUTRAL) house wire. Connection of the bare or green fixture ground wire to the black or white house wires may cause metal parts of the fixture to carry electrical currents. Under this condition anyone coming in contact with the fixture will receive electrical shock, which could cause serious injury or death.
- Page 4 PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Time: 30 minutes Tools Required for Assembly (not included): Flathead Screwdriver, Phillips Screwdriver, Wire Strippers, Drill, 1/8 in.
- Page 5 ASSEMBLY INSTRUCTIONS 3. Remove mounting plate (B) from fixture (A) by removing mounting plate screws (C) from the edges of the fixture (A). Save mounting plate screws (C) for later use. Determine the approximate location for the fixture (A). Place mounting plate (B) against the wall and mark the location of the hole using a pencil or a marker (not included).
- Page 6 ASSEMBLY INSTRUCTIONS Prepare wires by stripping 3/4 in. of insulation from BLACK wire ends using wire strippers (not included). Connect WHITE wire from fixture (A) to WHITE wire from outlet box using existing wire connector or wire connector (AA). Connect BLACK wire from fixture (A) to BLACK wire from outlet box using existing wire connector or wire connector (AA).
-
Page 7: Troubleshooting
ASSEMBLY INSTRUCTIONS Attach fixture (A) to mounting plate (B) using the mounting plate screws (C) previously removed (Step 3, Page 5). NOTE: Before tightening mounting plate screws (C) completely, use level (not included) to check fixture (A) -- adjust if necessary. Restore power and test fixture (A). -
Page 8: Warranty
TROUBLESHOOTING WARNING: Before beginning work, shut off the power supply to avoid electrical shock. PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION 1. Power is OFF. 1. Make sure power supply is ON. Light does not come on 2. Faulty connection. 2. Check wiring and all connections. initially or no longer 3.
