- Page 1 KKG 6401-90 INSTRUCTION MANUAL GAS HOB IO-HOB-1556/ 8513920 (05.2024 / v4)
- Page 2 Congratulations on the new GRAM hob Your hob is exceptionally easy to use and extremely efficient. After reading these Operating Instructions, operating the appliance will be easy. Before being packaged and leaving the manufacturer, the appliance was thoroughly checked with regard to safety and functionality.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Basic Information....................2 Safety instructions....................4 Description of the appliance................10 Specification......................10 Installing (instructions for the installer)...............11 Operation.........................19 Cleaning and maintenance..................23 Troubleshooting.....................24... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS FOR USE Note.The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concern-... - Page 5 SAFETY INSTRUCTIONS FOR USE well ventilated especially when the appliance is in use. Prolonged intensive use of the appliance may require addi- tional ventilation, for example the increasing of mechanical ventilation where present, additional ventilation to safely remove the products of combustion to outside (external) air whilst also providing room air changes with additional ventilation.
- Page 6 SAFETY INSTRUCTIONS FOR USE ● Do not allow liquids to boil over onto the burners and avoid burner contamination. Soiled burners must be cleaned and dried immediately after cooling. ● Do not place pots directly on the burners. ● Do not place pots weighing more than 5 kg on the grid over one burner or more than 25 kg on the entire grid.
-
Page 7: How To Save Energy
HOW TO SAVE ENERGY Using energy responsibly not only saves money but also helps the environment. So let’s save energy! And this is how you can do it: ● Use proper pans for cooking. Pans with thick, flat bases can save up to 1/3 on electric energy. -
Page 8: Disposal Of The Appliance
UNPACKING DISPOSAL OF THE APPLIANCE The appliance was packed In accordance with European to protected it from damage Directive 2012/19/UE and Pol- during of transport. After ish legislation regarding used unpacking, please dispose electrical and electronic goods, of all elements of packaging this appliance is marked with in a way that will not cause the symbol of the crossed-out... -
Page 9: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE Gas hob 1,2,3,4 - top burners 5 - burner knobs with igniter switch 6 - grids SPECIFICATION height 99,8 mm depth 520 mm width 600 mm weight of the appliance 11,8 kg The appliance is equipped with burners: 1 - large burner, heat load - 3.0 kW 2 - medium large burners, heat load... -
Page 10: Installing (Instructions For The Installer)
INSTALLING The following instructions are intended for a qualified professional installer. These instructions are intended to provide the most professional installation and maintenance of the appliance. l Before you install the appliance, make sure that the local distribution conditions (gas type and pressure) and the appliance configuration is appropriate. l Configuration details are given on the appliance nameplate. -
Page 11: Installation Instructions
INSTALLATION INSTRUCTIONS Install gas hob B/B* 500x20 mm 500x10 mm 500x10 mm min 30 mm *optional... - Page 12 INSTALLING ● prepare an opening in the worktop of a kitchen cabinet, as per the installation drawing ● connect the hob to a gas and electrical system in accordance with the instructions supplied, ● loosely attach fixing brackets to the bottom of the hob*, ●...
- Page 13 INSTALLING Tips for the installer The appliance has an G 1/2" threaded pipe connector to connect it to the gas system. The installer must: The LPG (propane-butane) hob version has Have appropriate qualification ● the connector terminated with a hose tip ∅...
- Page 14 INSTALLING Adapt the hob to a particular type of gas This may be performed by an installer with the appropriate qualifications only. If the gas, which the hob will be supplied with is different from the gas type specified by the manufacturer, i.e.
- Page 15 INSTALLING SOMIPRESS burner. (indicated "SOMIPRESS." on the burner body) Somipress burner(marked „SOMI- Gas type press” on the burner body) G20 2E G30 3B/P G110 1a 8 20 mbar 30 mbar mbar Nozzle diameter 0.72 0.52 1.41 Auxiliary Heat load Gas consumption Nozzle diameter 0.98 0.67...
-
Page 16: Adjust The Valves
INSTALLING Adjust the valves for a reduced flow. Convert the appliance from Convert the appliance from Burners Flame LPG to natural gas natural gas to LPG Replace burner nozzle with the Replace burner nozzle with the Full flame appropriate nozzle according appropriate nozzle according to the table. -
Page 17: Operation
OPERATION Cookware lid: Burner operation Lid prevents heat from escaping and thus reduces heating time. To achieve significant energy savings, use the appliance as instructed in these operating instructions, make the appropriate adjustments and use suitable pots. Do not use cookware that protrude Potential energy savings: over the edges of the hob. - Page 18 OPERATION Using the hob equipped with igniter knobs Repeat the above step if flame does ("Zp" model) not ignite. If flame is extinguished, the flame- ● push down the knob of a selected burner failure device will cut off gas supply until you feel resistance and turn left to within about 60 seconds.
- Page 19 OPERATION Adjust flame “Zt” Adjust flame “Zs” Flame from a properly adjusted burner is Flame from a properly adjusted burner is pale blue with a clearly outlined inner cone. pale blue with a clearly outlined inner cone. You can adjust flame by setting the knob to You can adjust flame by setting the knob to different positions.
- Page 20 OPERATION In the event a gas leak risk 1 gas system 2 gas system shut-off valve A valve "open" B valve "closed" In the event of a fault ● turn off the burners ● close the gas system shut-off valve ●...
-
Page 21: Cleaning And Maintenance
CLEANING AND MAINTENANCE Make sure that burner is correctly re- Proper routine maintenance and cleaning assembled after cleaning. of the appliance can significantly extend its trouble-free operation. CORRECT B e f o r e c l e a n i n g o r o t h e r maintenance work, always unplug the appliance or use the main electrical system circuit breaker... -
Page 22: Troubleshooting
● have the appliance repaired ● based on the instructions given in the table below, some minor issues can be corrected by the user. Please check the consecutive points in the table before you refer the repair to customer GRAM service. PROBLEM POSSIBLE CAUSE REMEDY 1.The appliance does not... - Page 24 Gram A/S Gram A/S Gram A/S Tel.: 22 07 26 30 Tel.: 040 38 08 40 Tel.: 020 7756 350 www.gram.no www.gram.se www.gram.fi Gram A/S Gejlhavegård 2B DK-6000 Kolding +45 73 20 10 00 www.gram.dk...
