Urban Barn Barclay Extension Dining Table Assembly Instructions Manual

Advertisement

Quick Links

Assembly Instructions / Instructions d'assemblage
Please follow instructions closely as deviation from these instructions may present a
possible safety risk and may void your warranty.
It is recommended that assembly is done on a soft surface such as carpet to avoid any
damage during assembly.
Only tighten hardware fully once all hardware is properly in position and tightened
80%. Overtightening bolts will damage the bolt threads.
Use only factory-provided hardware to assemble. Unapproved hardware can damage
product or jeopardize the structural integrity of the product.
Suivre attentivement ces instructions. Le non-respect de ces instructions pourrait poser
un risque pour la sécurité et invalider votre garantie.
Il est recommandé d'assembler le produit sur une surface souple comme un tapis pour
éviter d'endommager le produit pendant l'assemblage.
Visser serré la quincaillerie uniquement après l'avoir toute mise en place et vissée à
80 %. Un serrage excessif des boulons pourrait endommager le filetage.
Utiliser uniquement les outils fournis pour l'assemblage. L'utilisation d'outils non
approuvés pourrait endommager le produit ou compromettre son intégrité structurelle.
Care Instructions / Directives d'entretien
Periodically check and re-tighten hardware.
Vérifier périodiquement la quincaillerie et la resserrer au besoin.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Barclay Extension Dining Table and is the answer not in the manual?

Questions and answers

Summary of Contents for Urban Barn Barclay Extension Dining Table

  • Page 1 Assembly Instructions / Instructions d’assemblage Please follow instructions closely as deviation from these instructions may present a possible safety risk and may void your warranty. It is recommended that assembly is done on a soft surface such as carpet to avoid any damage during assembly.
  • Page 2 List of Parts and Hardware / Liste des pièces et du matériel Ref. / Réf. Parts / Pièces Qty. / Qté Table Top / Dessus de table Extension Leaf / Rallonge Leg C / Patte C Leg D / Patte D Stretcher / Barre transversale...
  • Page 3 List of Parts and Hardware / Liste des pièces et du matériel Ref. / Réf. Parts / Pièces Qty. / Qté Allen Bolt (8 x 50 mm) / Boulon Allen (8 x 50 mm) Hex Bolt (8 x 60 mm) / Boulon à...
  • Page 4 Step 2 / Étape 2 Place the Table Top (A) upside down on top of a soft surface. With Hex Bolt (2), Lock Washer (3), and Flat Washer (4), use the Wrench (6) to attach the assembled table legs to Table Top (A). Placer le dessus de table (A) à...
  • Page 5 Step 4 / Étape 4 Unlock the extension latch and slide open the table extension. Déverrouiller le verrou des rallonges et faire glisser les extrémités du dessus de table pour ouvrir la table. UNLOCK / DÉVERROUILLER Step 5 / Étape 5 Insert Table Leaves (B).
  • Page 6 Step 6 / Étape 6 Slide the table extension back in and lock the extension latch. Faire glisser à nouveau les extrémités du dessus de table pour fermer la table. Verrouiller le verrou des rallonges. LOCK / VERROUILLER Assembled / Table assemblée...
