Paramount Power Recliner

Assembly Instructions

Power components

X1 Battery pack

How to install battery pack:

Step 1

Please protect your floor and recliner by placing a blanket on the floor before turning

the chair base upside down to gain access to the mechanism. You will notice a pre-

installed plastic mounting bracket on the lower part of the back chair frame.

Step 2

Attach the enclosed Rechargeable Battery Pack using its 'Snap-On' system with the

pre-installed mounting plastic bracket.

X1 Power cord

X1 battery charger

X1 Power supply

transformer

(alternative power

option)

Need help?

Do you have a question about the Paramount Power Recliner and is the answer not in the manual?

Page 1 Paramount Power Recliner Assembly Instructions Power components X1 Power cord X1 Battery pack X1 Power supply X1 battery charger transformer (alternative power option) How to install battery pack: Step 1 Please protect your floor and recliner by placing a blanket on the floor before turning the chair base upside down to gain access to the mechanism.
Page 2 Step 3 Connect the Rechargeable Battery Pack to the reclining motor's extension cable, which is securely attached to the rear seat mechanism. Secure the cable leading to the battery by using a cable tie. Please maintain a distance of approx. 7 cm (2.75 inch) from the frame corner.
Page 3 Your Paramount Power Recliner includes a transformer power supply, giving you the option to connect it directly to a power outlet. Step 1 Connect the cable from the reclining motor to the power supply transformer. The extension cable is already connected to the motor and securely attached to the rear seat mechanism.
