Summary of Contents for Hisense AN09CBG
- Page 1 Hisense R32 Air Conditioner User Guide...
- Page 2 Introduction The iRobot Roomba j6 is a cutting-edge robot vacuum cleaner designed and manufactured by iRobot, a renowned company known for its innovative home robotics solutions. Released as part of the Roomba series, the j6 model represents a significant advancement in autonomous cleaning technology, making it easier and more efficient to maintain a clean and tidy home.
- Page 3 Additionally, the Roomba j6 is part of iRobot's broader ecosystem, enabling seamless integration with other iRobot home robots and smart devices. This ecosystem approach allows for enhanced automation and coordination within your smart home. In summary, the iRobot Roomba j6 is an advanced and feature-rich robot vacuum cleaner that combines intelligent mapping, powerful cleaning capabilities, and smart home integration to take the hassle out of maintaining a clean and tidy living space.
- Page 5 About this item ● Split AC with inverter compressor: Variable speed compressor which adjusts power depending on heat load. It is most energy efficient and has lowest-noise operation. ● Capacity: 1.5 Ton suitable for small sized rooms (151 to 200 square feet). ●...
-
Page 7: Installation Diagram
Installation diagram The above figure is only a simple presentation of the unit, it may not match the external appearance of the unit you purchased. Installation must be performed in accordance with the national wiring standards by authorized personnel only. Select the installation locations... - Page 8 Location for Installing Outdoor Unit ● Where it is convenient to install and well ventilated. ● Avoid installing it where flammable gas could leak. ● Keep the required distance apart from the wall. ● The pipe length between indoor and outdoor units should be no more than 5 meters in factory default status, but it can go up to maximum 20 meters with an additional refrigerant charge.
- Page 9 If the height or pipe length is out of the scope of the table, please consult the merchant.
- Page 11 Connecting of the Cable Note: For some models, it is necessary to remove the cabinet to connect to the indoor unit terminal. Outdoor Unit Remove the access door from the unit by loosening the screw. Connect the wires to the terminals on the control board individually as follows.
- Page 12 Caution: ● Never fail to have an individual power circuit specifically for the air conditioner. As for the method of wiring, refer to the circuit diagram posted on the inside of the access door. ● Confirm that the cable thickness is as specified in the power source specification ●...
-
Page 14: Cable Specifications
Cable Specifications Attention: The plug must be accessible even after the installation of the appliance in case there is a need to disconnect it. If not possible, connect the appliance to a double-pole switching device with a contact separation of at least 3 mm placed in an accessible position even after installation. -
Page 15: Wiring Diagram
Wiring diagram Make sure that the color of the wires in the outdoor unit and terminal No. are the same as those of the indoor unit. 7K~24K Model Warning: Before obtaining access to terminals,all supply circuits must be disconnected. -
Page 17: Outdoor Unit Installation
Outdoor unit installation Install Drain Port and Drain Hose (for heat-pump model only) The condensate drains from the outdoor unit when the unit operates in heating mode. In order not to disturb your neighbor and protect the environment, install a drain port and a drain hose to direct the condensate water. Just install the drain port and rubber washer to the chassis of the outdoor unit, then connect a drain hose to the port as the right figure demonstrates. -
Page 20: Air Purging
Air purging The air which contains moisture remaining in the refrigeration cycle may cause a malfunction on the compressor. After connecting the indoor and outdoor units, release air and moisture from the refrigerant cycle using a vacuum pump, as shown below. Note: To protect the environment, be sure not to discharge the refrigerant to the air directly. - Page 23 DIMENSION Indoor Outdoor...
- Page 25 Manuals.plus ● What safety precautions should I take when installing the air conditioner? Please read the manual carefully before installation and follow the instructions. Make sure to properly ground the air conditioner, check the connecting cables and pipes, and install an air-break switch. The appliance must be installed by a professional or qualified person.
- Page 26 Manuals.plus ● Can children use the air conditioner? This appliance can be used by children aged 8 years and above if they have been given supervision or instruction concerning the safe use of the appliance. Children should not play with the appliance and cleaning and user maintenance should not be done by children without supervision.
- Page 27 Manuals.plus Like And Subscribe us for more Videos Manuals.plus...
