R-VAN on a Spike
User's Guide
• 17' to 24' (5,2 to 7,3m) radius
• 45° to 270° arc
ARC
ADJUSTMENT
CAP
ROTARY
DEFLECTOR
RADIUS
ADJUSTMENT
DIAL
COLLAR
FILTER
SCREEN
Features
• Adjust arc and radius without tools
• Low precipitation rate reduces run-off and erosion
• Maintains efficient performance at high operating
pressures without misting or fogging
R-VAN on a Spike User's Guide
1
Identify the Left Edge
A grooved white mark located on the collar, just under the
LEFT EDGE
INDICATOR
1. Align the nozzle to the left most edge of desired
coverage area (arc).
ARC
ALIGN LEFT EDGE
INDICATOR WITH ARC
Advertisement
Related Manuals for Rain Bird R-VAN on a Spike
Summary of Contents for Rain Bird R-VAN on a Spike
- Page 1 Features • Adjust arc and radius without tools • Low precipitation rate reduces run-off and erosion • Maintains efficient performance at high operating ALIGN LEFT EDGE pressures without misting or fogging INDICATOR WITH ARC R-VAN on a Spike User's Guide...
- Page 2 A clicking sound will be 2. Push down and turn the Arc Adjustment Cap clockwise heard when range limits are reached. to increase the arc. PUSH DOWN AND TURN THE ARC ADJUSTMENT TURN THE RADIUS ADJUSTMENT DIAL R-VAN on a Spike User's Guide...
- Page 3 1. Unscrew the rotary nozzle from the riser. 2. Remove the clogged screen. 3. Clean and replace the screen. 4. Screw the nozzle back onto the riser. FILTER SCREEN R-VAN on a Spike User's Guide...
