New Classic Furniture PARADOX QUEEN B69-310 Assembly Instructions

Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have
come loose inside the carton during shipment. Iden�fy and count all items and compare with the parts list and/or hardware
list
shown below.
PARTS LIST
ITEM
DESCRIPTION
1 HEADBOARD
2 HEADBOARD LEG (RSF)
3
HEADBOARD LEG (LSF)
4 FOOTBOARD
5 TOP SIDE RAIL (L/R)
LOWER INNER
6
SIDE RAIL (L/R)
BED SLAT WITH MARKING
7
8
BED SLAT
9 SLAT BOTTOM
SLAT SUPPORT LEG
10
W/ADJUSTABLE FFET
11 CONCEALED PANEL
BACK VIEW
1
IMPORTANT NOTE :
ASSEMBLY INSTRUCTIONS
B69-310 PARADOX 5/0 Q HEADBOARD
B69-320 PARADOX 5/0 Q PANEL FOOTBOARD
B69-330 PARADOX 5/0 Q PANEL RAILS & SLATS
PARADOX QUEEN
SKETCH
QTY
1PC
1PC
1PC
1PC
2PCS
2PCS
2PCS
3PCS
2PCS
5PCS
5PCS
HARDWARE LIST
ITEM
DESCRIPTION
JCBC SCREW -
A
M6 x 1-9/16''
SPRING WASHER -
B
M6 x 1/2"
FLAT WASHER -
C
M6 x 1/2"
M4 ALLEN KEY (60)
D
E
M5 ALLEN KEY (2 9/16")
F
CSK M4 x 32mm
PAN HEAD SCREW -
G
M3.5 x 20mm
3
2
SKETCH
D
A
B
C
F
STEP 1
PAGE 1 OF 5
QTY
4PCS
4PCS
4PCS
1PC
1PC
18PCS
25PCS
