New Classic Furniture B6428-110 Assembly Instructions

Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts,
which may have come loose inside the carton during shipment. Identify and count all items and compare with the
PARTS LIST and/or HARDWARE LIST shown below.
Caution: Please read the instructions thoroughly before assembly.
1. We recommend that you assemble this product with the assistance of another person: this will make the
assembly easier, and will help eliminate damage to the product or injury to persons during assembly.
2. Please do not over tighten screws or bolts until the assembly is completed.
3. Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps to assemble your
newly purchased product correctly and efficiently
PARTS LIST
NO: COMPONENT
A
Headboard
B
Footboard
C
Side Rail
D
Headboard Crossbar
Left Side Facing
E
(LSF) HB Leg
Right Side Facing
F
(RSF) HB Leg
G
Slats
H
Support Legs
Assembly Instructions
B6428-110
B6428-120
B6428-230
SKETCH Q'TY
1PC
1PC
2PCS
1PC
1PC
1PC
4PCS
8PCS
MADE IN VIETNAM
TYBEE 6"6"/6"0" EK/WK HEADBOARD
TYBEE 6"6"/6"0" EK/WK PANEL FOOTBOARD AND SLATS
TYBEE 6"0" WK RAILS
HARDWARE LIST
NO: COMPONENT
1
Bolt 5/16" x 1-3/4"
2
Bolt 5/16" x 3-1/2"
3
Flat Washer 5/16"*3/4"
4
Lock Washer 5/16"
5
Half Moon Washer 5/16"
6
Nut (5/16")
7
Screw: #8*1-1/4"
8 Allen key
9
Open Wrench 5/16"
SKETCH Q'TY
8pcs
8pcs
8pcs
16pcs
8pcs
8pcs
8pcs
1pc
1pc
PAGE: 1 of 4
