Installation
1
Determining the mounting
location
NOTE:
mounted higher than recommended, aiming the sensor
down will reduce the coverage area.
□
Determine the mounting location – wall mount.
□
Position the lamp heads in the general
direction of the desired light coverage.
2
Mounting the light fixture
Step 1. Determine the mounting location and mark two pilot holes 3.07 in apart. Use a drill bit to create the pilot
holes (if mounting to drywall, use the drywall anchors included with the screws). Use a hammer to tap the
anchors(AA) into the pilot holes.
B)Drill the screws(BB) into the anchors(AA) but leave a 0.12 in gap.
Step 2. Turn on the light switch on the back of the xture.
Step 3. Align the groove on the back with the screw, stick it to the wall and slide it down to lock the xture.
0.12in
Quick Start Guide
Motion Activated Security Light
3.07 in
Step1
Step3
MODEL: IS15a5008WDF-BK
Wall Mount
Step2
Please contact 1-866-308-3976 for further assistance.
SKU: 1001 857 558
HOMEDEPOT.CA
Advertisement
Related Manuals for Defiant IS15a5008WDF-BK
Summary of Contents for Defiant IS15a5008WDF-BK
- Page 1 Quick Start Guide SKU: 1001 857 558 Motion Activated Security Light MODEL: IS15a5008WDF-BK Installation Determining the mounting location NOTE: mounted higher than recommended, aiming the sensor down will reduce the coverage area. Wall Mount □ Determine the mounting location – wall mount.
- Page 2 Care and Cleaning □ □ □ Troubleshooting Problem Possible Cause Solution The light will not come on. □ □ Daylight turn-off (photocell) is in effect. Recheck after dark. □ □ The motion sensor is aimed in the Re-aim the motion sensor wrong direction.
- Page 3 Guide de démarrage rapide Lumière SKU: 1001 857 558 SKU # 1001 857 557 de sécurité activée par le mouvement Modèle: IS15a5008WDF-BK 1001 857 552 Installation Détermination du lieu de l’installation REMARQUE: Le luminaire doit être monté à environ 2,4 m au-dessus de la hauteur recommandée, car si le capteur est...
- Page 4 Entretien et nettoyage □ Pour prolonger l’apparence originale, nettoyez uniquement au moyen d’un chiffon doux trempé dans de l’eau. □ N’appliquez aucune peinture, solvant ou produit chimique sur ce luminaire. Cela pourrait causer une détérioration prématurée du ni. Cela ne constitue pas un défaut du ni, de sorte que ce n’est pas couvert par la garantie.
