Item #1003335301
Model #HD-1870-BZ
USE AND CARE GUIDE
Battery-Operated Motion Sensor Light
Questions, problems, missing parts? Before returning to the store,
call Defiant Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-866-308-3976
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in Defiant through the purchase of this motion security light.
We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products
available for your home improvement needs. Thank you for choosing Defiant!
IQA HD-LB1870-ENG-US-20180608-FINAL.indd 1
08-Jun-18 4:13:11 PM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Defiant HD-1870-BZ
Summary of Contents for Defiant HD-1870-BZ
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Defiant through the purchase of this motion security light. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ........2 Tools That May Be Required ....3 Safety Information ........2 Hardware Included .........4 Precautions Package Contents ........4 Warranty ............3 Installation ..........5 3-Year Warranty ........3 Operation ...........7 Specifications ..........3 Care and Cleaning ........9 Pre-Installation ..........3 Troubleshooting ........10 Planning Installation ......3 Safety Information... -
Page 3: Warranty
Warranty 3-YEAR WARRANTY Contact the Customer Service Team at 1-866-308-3976 or visit www.homedepot.com. Specifications Detection Range Up to 33 ft. Sensing angle Up to 180° LED Lumens 700 lumens Operating temperature -13°F to +113°F Power requirements 4 Alkaline “D” cell batteries - 1.5V (not included) Pre-Installation PLANNING INSTALLATION Before installing the light fixture, ensure that all parts are present (see Hardware Included on page 4). -
Page 4: Hardware Included
Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware shown is not to scale Part Description Quantity Screws Screw pegs Diffuser panels PACKAGE CONTENTS Part Description Quantity Lamp head Main body Mounting plate Motion sensor IQA HD-LB1870-ENG-US-20180608-FINAL.indd 4 08-Jun-18 4:13:12 PM... -
Page 5: Installation
Installation Determining the Mounting Location □ Determine the mounting location - wall or eave mount. Wall mount Eave mount Removing the Mounting Plate NOTE: This fixture comes with a mounting plate (C). It is pre-assembled on the light fixture (B) for shipping. □... - Page 6 Installation (continued) Installing the Mounting Plate A. Wall Mount □ Remove the two rubber gaskets (2) from mounting plate (C). □ Place the mounting plate (C) against the wall with the word “UP” facing you (see illustration). Ensure the mounting plate (C) is level. Mark the hole locations.
-
Page 7: Operation
Installation (continued) Installing the Mounting Plate Mounting the Light Fixture B. Eave or Ceiling Mount □ Place the mounting plate (C) against the ceiling. □ Attach the light fixture (B) to the mounting Mark the hole locations. plate (C). Support the back-plate from behind with one hand and push the light onto the □... - Page 8 Operation (continued) Adjusting the Sensor Head □ The motion sensor gets a full 180° of coverage, so it senses from wall to wall. However, if the sensor is mounted on a corner and you would like additional coverage on one side or the other, the sensor (D) can be rotated left and right.
-
Page 9: Care And Cleaning
Operation (continued) Using the Diffuser Panels If you want to reduce the glare of the lights, attach the diffuser panels to the lamp heads as shown below. This also prevents the LEDs from being seen during daylight hours. Some people may prefer the appearance of the light fixture with the diffuser panels in place. -
Page 10: Troubleshooting
Troubleshooting Problem Possible Cause Solution □ □ The light will not come on. Daylight turn-off (photocell) is in effect. Set the DUSK LEARN at desired lux level. □ Reposition the unit within □ The motion sensor is out of coverage your desired detecting range. - Page 11 Questions, problems, missing parts? Before returning to the store, call Defiant Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-866-308-3976 HOMEDEPOT.COM Retain this manual for future use. IQA HD-LB1870-ENG-US-20180608-FINAL.indd 11 08-Jun-18 4:13:14 PM...
