Dri-Eaz DrizAir 1400 Quick Start Manual

LEGEND BRANDS, INC. | 15180 Josh Wilson Road, Burlington, WA 98233 | Phone: 800-932-3030 LegendBrands.com
WARNING
ADVERTENCI
WARNING! Do not alter or modify your unit in any way. Use
only replacement parts authorized by Legend Brands.
Modifications or use of unapproved parts could create a hazard
and will void your warranty. Contact your local distributor for
assistance.
WARNING! Explosion or combustion hazard due to
flammable refrigerant.
• Do not use in environments with combustible gases,
electric heaters or open flames.
• Do not drill into or braze the dehumidifier.
• Do not attempt to service the refrigeration system! Only
authorized service personnel should service the
refrigeration system.
• Be aware that refrigerant gases can be odorless.
WARNING! Electric shock hazard, rotating fan, hot surface
hazards. Unplug unit before opening cover for cleaning or
servicing. Unit must be grounded.
• Inspect the power cord before use. If cord is damaged, do
not use. Always grasp the plug (not the cord) to unplug.
• Insert three-prong plug on power cord into a matching
electrically grounded outlet. Do not use adapter. Never cut
off third prong. Do not use an extension cord.
• The unit must be operated on a 120V/60Hz circuit
protected by a Ground Fault Circuit Interrupter (GFCI)
device.
• Keep motor, circuitry and wiring dry. Do not power wash
or expose the unit to rain.
• Do not attempt to repair the unit. For Authorized Service
Centers, contact Legend Brands.
NOTICE: Do not use in environments where corrosive
chemicals are present, such as chlorine.
NOTICE: The unit should not be used by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction. Children should not be allowed
to play with the unit.
For proper disposal, this unit should be taken to a recycler
licensed to process refrigeration equipment.
CONTAINS: FCC ID 2ADHKWINC3400; IC 20266-ATWINC3400;
CAN-ICES-003(B)/MB-003(B)
127758C (#127890/127727 – QSG)
Quick Start Guide
DrizAir 1400 Dehumidifier
Patents:
Item #127890 / #127727 |
http://www.LBpatents.com
OPERATING YOUR DEHUMIDIFIER
Extend Handle
Extend the telescoping handle by pushing the button inward,
then lifting handle up into place. Release the button to secure
handle in operating position.
NOTICE: Do not secure the unit in a vehicle with the
handle extended to avoid causing injury or damaging the
unit, which is not covered by warranty.
Set up drain hose
Unwrap the entire hose and place the unattached end in a
sink, drain, bucket or outdoors – anywhere that water can drain
out safely. If you use a bucket or other container, check it
regularly to prevent overflows.
NOTICE: Uncoil and straighten the entire drain hose. Do not
leave any part of the hose coiled on the unit and do not place
the end of the hose higher than 20 ft. (6 m) above the bottom
of the unit.
Plug in electrical cord
The dehumidifier should be plugged into a GFCI-protected
120 volt outlet rated for at least 15 amps.
OPERATING INDICATOR LIGHTS
When the unit is powered on and operating normally, indicator
lights in the bezel illuminate blue. If the unit needs attention,
indicator lights turn red. The top display bar will turn red and
display an "Alert" indicator as well as the issue encountered.
Press the top display bar to view the message and
troubleshooting steps. When finished, press the "X" in the
upper right corner.
AT THE END OF THE JOB
NOTICE: To ensure all water is removed from the
dehumidifier, the unit will complete the defrost cycle even if the
unit is turned off. Do not unplug the unit during the defrost
cycle and keep it upright on a horizontal surface until all water
has been purged.
1. Do not turn unit off or move it until it has returned to normal
operating mode.
2. Gently rock the machine to ensure any water remaining on
interior surfaces falls into the sump area.
3. Press the PURGE button. When the purge cycle is
complete, turn the unit off.
4. Coil power cord and place it in the cord storage pocket. This
will prevent the cord from catching on the stairs and possibly
damaging the cord.
5. Disconnect and drain the hose completely, then coil and
store it in the hose storage pocket.
1 Legend Brands, Inc.
