Clas Ohlson BZ083-PIR Manual

Rechargeable wardrobe light
with motion sensor (PIR)
Art. no. 36-9966 Model BZ083-PIR
Please read the entire instruction manual before using the product
and then keep it for future reference. We accept no liability for
any errors in the text or images and we reserve the right to make
any necessary changes to technical data. If you have technical
problems or other questions, please contact our customer service
team.
Safety
• Do not let children play with the product.
• The product must not be changed or modified in any way.
• Never charge the product in a flammable environment or on a
flammable surface.
• Never use a faulty or damaged charging cable.
• Never expose the product to high temperatures or naked
flames.
Care and maintenance
Switch the light off and clean it using a soft, dry cloth.
Responsible disposal
This symbol indicates that the product should not
be disposed of with general household waste. This
applies throughout the entire EU. In order to pre-
vent any harm to the environment or health hazards
caused by incorrect waste disposal, the product
must be handed in for recycling so that the materials
can be disposed of in a responsible way. To recycle the product,
take it to your local recycling facility or contact the retailer. They
will ensure that the product is disposed of in a way that does not
harm the environment.
Product description
5
1 2 3 4
7
1. Charging indicator light 5. Magnetic attachment
2. [ ] Dimmer switch 6. USB-C port
3. Motion sensor 7. USB-A to USB-C cable
4. [ ON/OFF ] switch 8. Self-adhesive wall bracket
Mounting the light
Note: The light is designed to be installed in a dark place.
The motion sensor will not work in a light area.
1. Clean the surface where you want to attach the wall mount to
remove any dust or grease.
2. Remove the backing film from the wall mount and press it
against the wall.
3. Fit the magnetic attachment (4) of the light to the wall mount
until you hear a click.
Using the light
Set the power switch to ON to activate the light, it will be on for
15 seconds. Hold [ ] to adjust the brightness. The light will go
out after 15 seconds if no further movement is detected.
The motion sensor will switch the light on again when it registers
movement.
Set the power switch to OFF to completely switch the light off.
6 Charging
Note: Charge the light fully before using it for the first time.
Connect the charging cable (6) to the port (5) and to any USB
charger. The charge indicator light (1) shows the status of the
battery in two different modes:
• Red light: The battery is being charged
8
• Green light: The battery is fully charged
Specifications
Charging voltage
Battery
Cable
Charging time
Operating time
Type of light source
Luminous flux
Light temperature
CRI
Dimensions
Detection zone
2-3 m
English
5 V DC 1 A adapter (sold separately)
Li-ion 2200 mAh, 3.7 V (non-replaceable)
USB-A to USB-C, 30 cm (included)
up to 4 hours
approx. 7 hours
LED (non-replaceable)
100 lm
3000 K
80
76 x 73 x 39 mm
2-3 m
4-5 m
120°
