Offices To Go Newland NL6636CEL Assembly Instructions

Assembly Instructions
Thank you for purchasing this product from Global.
Before you begin assembly, check that you have all the
parts and hardware shown on this page.
If there is any item missing, circle the item, indicating
quantity required and return to us by fax or mail:
CANADA
Global Upholstery
560 Supertest Road
Downsview, Ont.
M3J 2M6
TEL. (416)661-3660
FAX. (416)661-4300
Attn.: Customer Service
T
OOLS REQUIRED
Screwdriver size #2
I t is advisable to assemble unit on a carpet to avoid scratches.
CST318
TRANSACTION TOP Leveller 5/16"-18 x 15/16" Base,
FLAT PLATE
x 2
Printed in Canada
Newland
Extended Corner
Narrow Gable on throat side
Full Gable on extended side
US
Global Industries Inc.
17 West Stow ROAD
P.O. 524
Marlton, NJ 08053
TEL. (856)596-3390
FAX. (856)596-5684
Attn.: Customer Service
PHILLIPS
GEN222
Rectangular Grommet
1 1/8" Stem
x 6
d .
b .
a . Top
b . Left gable ( narrow)
c . Right gable ( full )
d . Back ( short )
e . Back ( long )
GEN160 FST028
#8 x3/4 Pan HD.
x 1
NL6636CEL
NL7236CEL
a .
c .
Notice to installers:
Open and assemble only one
product at a time to avoid
a potential mix up of parts
and hardware.
GEN062
Metal pin
5mm Ø x 24mm L
x 8 x 1
NAIN 08 Rev.00
NL6636CER
NL7236CER
e .
Pg 1 of 3
