Universal AC/DC
Photoelectric Sensors
BX Series
PRODUCT MANUAL
For your safety, read and follow the considerations written in the instruction
manual, other manuals and Autonics website.
The specifications, dimensions, etc. are subject to change without notice for product
improvement. Some models may be discontinued without notice.
Features
• Built-in sensitivity adjuster
• Timer function (built-in timer model)
- ON Delay, OFF Delay, One-shot Delay
• NPN/PNP open collector simultaneous output (DC power Type)
• Self-diagnosis function (green lights up in the stable level)
• Built-in reverse power protection circuit and output short overcurrent protection
circuit
• Wide power supply range: Universal 24-240 VDCᜡ / 24-240 VACᜠ
• IP65 protection rating (IEC standard)
ᜢ ᜽ ᜫ
Safety Considerations
• Observe all 'Safety Considerations' for safe and proper operation to avoid hazards.
• ᜸ symbol indicates caution due to special circumstances in which hazards may occur.
᜸ Warning
Failure to follow instructions may result in serious injury or death.
01. Fail-safe device must be installed when using the unit with machinery that
may cause serious injury or substantial economic loss. (e.g., nuclear power
control, medical equipment, ships, vehicles, railways, aircraft, combustion
apparatus, safety equipment, crime/disaster prevention devices, etc.)
Failure to follow this instruction may result in personal injury, economic loss or fire.
02. Do not use the unit in the place where flammable/explosive/corrosive gas,
high humidity, direct sunlight, radiant heat, vibration, impact or salinity
may be present.
Failure to follow this instruction may result in explosion or fire.
03. Do not disassemble or modify the unit.
Failure to follow this instruction may result in electric shock or fire.
04. Do not connect, repair, or inspect the unit while connected to a power
source.
Failure to follow this instruction may result in electric shock or fire.
05. Check 'Connections' before wiring.
Failure to follow this instruction may result in electric shock or fire.
᜸ Caution
Failure to follow instructions may result in injury or product damage.
01. Use the unit within the rated specifications.
Failure to follow this instruction may result in fire or product damage.
02. Use a dry cloth to clean the unit, and do not use water or organic solvent.
Failure to follow this instruction may result in electric shock or fire.
03. Do not use a load over the range of rated relay specification.
Failure to follow this instruction may result in insulation failure, contact melt,
contact failure, relay broken, or fire
Cautions during Use
• Follow instructions in 'Cautions during Use' . Otherwise, It may cause unexpected
accidents.
• When connecting an inductive load such as DC relay or solenoid valve to the output,
remove surge by using diodes or varistors.
• Use the product after 0.5 sec of the power input.
When using a separate power supply for the sensor and load, supply power to the
sensor first.
• The power supply should be insulated and limited voltage/current or Class 2, SELV
power supply device.
• Wire as short as possible and keep it away from high voltage lines or power lines to
prevent surge and inductive noise.
• When using switching mode power supply (SMPS), ground F.G. terminal and connect
a condenser between 0V and F.G. terminal to remove noise.
• When using a sensor with a noise-generating equipment (e.g., switching regulator,
inverter, and servo motor), ground F.G. terminal of the equipment.
• This unit may be used in the following environments.
- Indoors (in the environment condition rated in 'Specifications')
- Altitude max. 2,000 m
- Pollution degree 2
- Installation category II
Product Components
Through-
Sensing type
beam
Product components
Product, instruction manual
Reflector
-
Adjustment screwdriver
× 1
Bracket / Z bolt
× 2
Washer
× 2
Bolt / nut
× 4
Ø 6 / Ø 10 waterproof rubber
× 2
Polarized
Diffuse
Retroreflective
retroreflective
reflective
MS-2
MS-3
-
× 1
× 1
× 1
× 1
× 1
× 1
× 1
× 1
× 1
× 2
× 2
× 2
× 1
× 1
× 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the BX Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Autonics BX Series
