NI SMB-2163 User Manual

Single-ended digital i/o accessory

Advertisement

Quick Links

USER GUIDE
SMB-2163
Single-Ended Digital I/O Accessory
The SMB-2163 is a breakout box for National Instruments single-ended digital waveform generator/analyzer
modules. The SMB-2163 provides an easy way to connect to other devices for testing and debugging.
This guide explains how to set up and use the SMB-2163 single-ended digital I/O (DIO) accessory with NI
single-ended digital waveform generator/analyzer modules.
Contents
Conventions ............................................................................................ 2
What You Need to Get Started ............................................................... 2
Related Documentation........................................................................... 3
Parts Locator ........................................................................................... 3
Installing Cables...................................................................................... 3
Connecting Signals ................................................................................. 6
Cleaning the Accessory........................................................................... 8
Specifications .......................................................................................... 9
Digital I/O ........................................................................................ 9
Power ............................................................................................... 9
Physical ............................................................................................ 9
CE Compliance ................................................................................ 9
Environmental Management............................................................ 9
NI Services.............................................................................................. 10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMB-2163 and is the answer not in the manual?

Questions and answers

Summary of Contents for NI SMB-2163

  • Page 1: Table Of Contents

    The SMB-2163 is a breakout box for National Instruments single-ended digital waveform generator/analyzer modules. The SMB-2163 provides an easy way to connect to other devices for testing and debugging. This guide explains how to set up and use the SMB-2163 single-ended digital I/O (DIO) accessory with NI single-ended digital waveform generator/analyzer modules.
  • Page 2: Conventions

    What You Need to Get Started To set up and use the SMB-2163, you need the following items: SHC68-C68-D4 (shielded) or C68-C68-D4 (unshielded) cable assembly NI digital waveform generator/analyzer, installed in a PXI or CompactPCI chassis 50 Ω...
  • Page 3: Related Documentation

    Related Documentation The NI digital waveform generator/analyzer ships with several documents designed to familiarize you with different aspects of the module. The documentation set includes the following pieces: • NI Digital Waveform Generator/Analyzer Getting Started Guide—Read this printed document to set up the digital waveform generator/analyzer and configure it to complete your first acquisition or generation.
  • Page 4 PXI-5421 signal generator. The SMB-2163 is not compatible with the NI 6533/6534 products. Attach and secure the other end of the cable assembly to the DDC connector of the SMB-2163 and secure them together with the captive screws on the cable connector.
  • Page 5 Figure 2 shows how the cable assembly connects the SMB-2163 and the NI digital waveform generator/analyzer. NI PXI-1042 NI PXI-6551 50 MHz Digital I/O ACCESS ACTIVE PFI 0 PXI Chassis with NI Digital Waveform Generator/Analyzer SMB-2163 SHC68-C68-D4 Cable Assembly Figure 2. Connecting a Single-Ended Digital Waveform Generator/Analyzer to the SMB-2163 Make signal connections by connecting SMB cables to SMB-2163 signal terminals.
  • Page 6: Connecting Signals

    The SMB-2163 provides connectivity to up to 32 single-ended DIO channels, three programmable function interface (PFI) channels, and two clock channels of an NI digital waveform generator/analyzer. You can connect to these signals from the labeled SMB connectors on the SMB-2163.
  • Page 7 DDC CLK OUT STROBE Figure 3. DDC Connector Pinout Refer to the NI Digital Waveform Generator/Analyzer Help at Program Files»National Note Instruments»NI-HSDIO»Documentation»NI Digital Waveform Generator/Analyzer Help for information about the number of available DIO channels on your device. DIO <20..31> may not apply to your device.
  • Page 8: Cleaning The Accessory

    Figure 1. Cleaning the Accessory Disconnect all cables to the SMB-2163 before cleaning. To remove light dust, use a soft, nonmetallic brush. To remove other contaminants, use alcohol wipes. The unit must be completely dry and free from contaminants before returning to service.
  • Page 9: Specifications

    Environmental Management National Instruments is committed to designing and manufacturing products in an environmentally responsible manner. NI recognizes that eliminating certain hazardous substances from our products is beneficial not only to the environment but also to NI customers. For additional environmental information, refer to the NI and the Environment Web page at .
  • Page 10: Waste Electrical And Electronic Equipment (Weee)

    Visit to register your NI product. Product registration facilitates technical support and ni.com/register ensures that you receive important information updates from NI. NI corporate headquarters is located at 11500 North Mopac Expressway, Austin, Texas, 78759-3504, USA. 10 | ni.com |...
  • Page 11 | © National Instruments Corporation | 11...
  • Page 12 Help»Patents in your software, the patents.txt file on your media, or the National Instruments Patents Notice at ni.com/patents. You can find information about end-user license agreements (EULAs) and third-party legal notices in the readme file for your NI product. Refer to the Export Compliance Information at ni.com/legal/export-compliance for the NI global trade compliance policy and how to obtain relevant HTS codes, ECCNs, and other...
