Installation Guide
5-Port Gigabit Ethernet PoE+ Easy Smart
Managed Switch (63W)
GS105EP
5-Port Gigabit Ethernet Hi-Power PoE+ Easy
Smart Managed Switch (120W)
GS105EPP
Package contents
•
NETGEAR Easy Smart Managed Switch
•
Power adapter (power cable varies by region)
•
Wall installation kit
•
Rubber feet
Advertisement
Related Manuals for NETGEAR GS105EPP
Summary of Contents for NETGEAR GS105EPP
- Page 1 5-Port Gigabit Ethernet PoE+ Easy Smart Managed Switch (63W) GS105EP 5-Port Gigabit Ethernet Hi-Power PoE+ Easy Smart Managed Switch (120W) GS105EPP Package contents • NETGEAR Easy Smart Managed Switch • Power adapter (power cable varies by region) • Wall installation kit • Rubber feet...
- Page 2 From a computer or mobile device that is connected to the Internet, visit my.netgear.com. Log in to your NETGEAR account. If you don’t have a free NETGEAR account, you can create one. The My Products page displays. From the menu on the left, select Register a Product.
- Page 3 Failure to do so can damage the switch. WARNING: Before connecting this switch to outdoor cables or devices, see kb.netgear.com/000057103/ for safety and warranty information. 3. Check the LEDs When you connect the power cord to the switch and plug it into an electrical outlet, the LEDs indicate the status.
- Page 4 You can use your computer’s network settings to discover the switch. Alternatively, you can download the NETGEAR Discovery Tool (NDT). The NETGEAR Discovery Tool lets you discover the switch in your network and access the device user interface (UI) of the switch from a Mac, Windows-based, or Linux-based computer.
- Page 5 The PoE and PoE+ power supplied by the switch is prioritized in ascending port order: Ports 1–4 support PoE and PoE+ with a total power budget of 63W for the GS105EP and 120W for the GS105EPP. If the power requirements for the attached powered devices (PDs) exceed...
- Page 6 PoE troubleshooting Here are some tips for correcting PoE problems that might occur: • If the PoE Max LED is solid yellow, disconnect one or more PoE devices to prevent PoE oversubscription. • For each powered device (PD) that is connected to the switch, the associated PoE LED on the switch lights solid green.
- Page 7 See the regulatory compliance document before connecting the power supply. For NETGEAR’s Privacy Policy, visit https://www.netgear.com/about/privacy-policy. By using this device, you are agreeing to NETGEAR’s Terms and Conditions at https://www.netgear.com/about/terms-and-conditions. If you do not agree, return the device to your place of purchase within your return period.
