Summary of Contents for ZZ2 IC-EVO2
- Page 1 User Manual IC-EVO2 OEM RADIO:Camera Interface for BMW EVO system with 6.5”/8.8”/10.25” screen...
- Page 2 Camera Interface for BMW EVO system with 6.5”/8.8”/10.25” screen 1. Car Compatibility Chart Car Models Production Year 1 Series 2017- 2 Series 2017- 3 Series 2017- 4 Series 2017- 5 Series 2017- 6 Series 2017- 7 Series 2017- 2017- 2017- 2017- 2017- www.zz-2.com...
- Page 3 Camera Interface for BMW EVO system with 6.5”/8.8”/10.25” screen Contents 1.Features....................................4 2.Specifications..................................5 3.Packing Lists................................... 6 4.Wiring Diagram..................................7 5.DIP Switch Settings................................8 6.Operation Instructions............................... 10 7.Safety Considerations................................ 16 www.zz-2.com...
- Page 4 Camera Interface for BMW EVO system with 6.5”/8.8”/10.25” screen 1. Features: A. Support Intelligent Parking Assist System including PDC (Parking Distance Control) and FPG (Flexible Parking Guidelines) B. Support further software update by TF Card C. Support adjust FPG position for 8.8" 10.25" screen D.
- Page 5 Camera Interface for BMW EVO system with 6.5”/8.8”/10.25” screen 2. Specifications A. Interface I/O Spec: Input: CVBS *4 (Front/Rear View Camera, 360, Video), VGA *1 (Specific 360 Panoramic System) Output: LVDS Output B. Power Spec: Input Power: 9V-16V Consumption: 6W C.
- Page 6 Camera Interface for BMW EVO system with 6.5”/8.8”/10.25” screen 3. Packing Lists Camera Interface LVDS Cables Power Harness Optional Parts(Sold separately at the Cartizan) AV Input Cable AUX IN USB adapter www.zz-2.com...
- Page 7 Camera Interface for BMW EVO system with 6.5”/8.8”/10.25” screen 4. Wiring Diagram www.zz-2.com...
- Page 8 Camera Interface for BMW EVO system with 6.5”/8.8”/10.25” screen 5. DIP Switch Settings ON ( OFF( ▼ ▲ Car Model No.1 No.2 No.3 1-4 series/X3/X4, 8.8 inch with OEM rear camera OFF(▲) OFF(▲) OFF(▲) 1-4 series/X3/X4, 8.8 inch without OEM rear camera ON (▼) OFF(▲) OFF(▲)
- Page 9 Camera Interface for BMW EVO system with 6.5”/8.8”/10.25” screen ON ( OFF( ▼ ▲ Turn off PDC Turn on PDC Turn off dynamic guideline Turn on dynamic guideline Turn on front view Turn off front view *Please note that DIP Switch 5 and DIP Switch 8 put ON ( with OEM rear view.
- Page 10 Camera Interface for BMW EVO system with 6.5”/8.8”/10.25” screen 6. Operation Instructions 5.1 Installation Process * Please note that there need to power off and take protection measures to avoid damaging in the installation process. 1. Please prize up the air conditioner panel according to the designated position. *Please note that there are screws on the side panel of copilot, and remove the screws of side panel first if there is any, then prize up the air conditioner panel.
- Page 11 Camera Interface for BMW EVO system with 6.5”/8.8”/10.25” screen 2. After prize up the air conditioner panel, pull out the panel cables, then prize up the up plastic panel, remove the six screws in the red circle, and take down the CD panel. www.zz-2.com...
- Page 12 Camera Interface for BMW EVO system with 6.5”/8.8”/10.25” screen 3. Remove the screw in the red circle, take out the head unit. Please note that original car plug has optical fibers, and switch the optical fibers of the original car to the plug according to the pictures. www.zz-2.com...
- Page 13 Camera Interface for BMW EVO system with 6.5”/8.8”/10.25” screen 4. Pull out the LVDS cables of the OEM screen and connect to the LVDS-IN interface. Another cable connect to the LVDS-OUT interface, plug connect to the OEM screen on the other side. Then connect to the rear view cables and all of cables, check it and confirm the dip switcher, power on at the end.
- Page 14 Camera Interface for BMW EVO system with 6.5”/8.8”/10.25” screen 5.2 DVR Switching Long time press MENU for 2 seconds to enter DVR if DVR available. www.zz-2.com...
- Page 15 Camera Interface for BMW EVO system with 6.5”/8.8”/10.25” screen 5.3 Switch Position FPG (Flexible Parking Guidelines) Please press the screen for 20 seconds. The dynamic guidelines will come out from the up, below, left, right four directions. The dynamic guidelines will be adjusted by press four buttons. (Please note that it can be adjusted by multimedia button if there does not touch screen.) www.zz-2.com...
- Page 16 Camera Interface for BMW EVO system with 6.5”/8.8”/10.25” screen 7. Safety Considerations 1. In order to protect driving safety and avoid breaking the traffic law, please do not watch the program or use this product when you’re driving. 2. Please do not put the product in the damp environment or water, in order to avoid electric shock, damaged and fire accident caused by short circuit.
- Page 17 Camera Interface for BMW EVO system with 6.5”/8.8”/10.25” screen 7. The cables should be connected in a good way, the vehicle installation space is small, so reduce space usage as far as possible, and it will easy installation for monitor. There should be a good plan about connect cables, avoid affecting the active component of connecting, such as control components of turning steering wheel, throttle and brake pedal.
