- Page 1 IT3-LEX15 / IT3-LEX17 / IT3-LEX19 Apple Car Play CarPlay / Android Auto + Camera input for Lexus vehicles 929-220-1212 / 877-241-2526 - www.zz-2.com...
- Page 2 Components ANTENNA Screen Cable AV,USB Cable Type GVIF ZZPLAY Interface (IT3) Type GVIF (LEX19 only) (LEX15, LEX17 only) Type Harness LEX17 (only) Type Harness High Type Harness LEX19 (only) LEX15 (only) 11/2023...
-
Page 3: Body Connector Specifications
Body Connector specifications USB / VIDEO POWER/CAN LVDS HDMI IN OLD GVIF TYPE NEW GVIF TYPE NEW TYPE HIGH TYPE OLD TYPE AV CABLE Supports Only 720P POWER / CAN CAN3_LOW CAN3_HIGH AV CABLE CAN2_LOW MIC_IN_P CVBS_GROUND CAN2_HIGH MIC_IN_N CAN1_LOW AUDIO_GND REVERSE_CAM FRONT_CAM... -
Page 4: Car Compatibility Chart
Car Compatibility Chart Production Specific Models Car Models Year Lexus IS(XE30) Lexus CT(A10) 2013 ~ 2016 7 inch IS (XE30) 2017 ~ 10 inch IS (XE30) 2015 ~ 7 inch CT (A10) 2014 ~ 7 inch CT200 (A10) 2015 ~ 2018 7 inch,10inch NX (AZ10) 2018 ~... - Page 5 If the vehicle is equipped with the Joystick, make sure the 15H-KT is connected to the joystick (Please check page 7 for the diagram) 15H-KT HARNESS If the vehicle is equipped with the Small Touch Pad, MAKE SURE THE A# IS PLUGGED INTO C# CONNECTOR (check picture for reference)---------------------...
-
Page 6: Full Installation Diagram
Full Installation Diagram IT3-LEX15 NOTEs: - You must be in BT Audio or AUX mode for audio playback from CarPlay system. - *For Lexus systems, typically MUST ground the Audio Ground Wire if using AUX for sound. - The Screen Correction T-Harness MUST be connected to the screen or flickering will occur! - If vehicle has a Joystick, the KT... -
Page 7: Audio Playback Options
Go to ZZPLAY>SETUP and scroll towards the bottom of the list. If 'BT Channel' does not exist, your system is out of date and needs to be updated. Contact ZZ2 for more information. - Page 8 Vehicles Equipped with the JOYSTICK controls, please Full Installation Diagram make sure the 15-KT harness is attached to the main IT3-LEX15 plug and play and connected to the Joystick module. Main plug and play harness 15-KT Harness 15H-KT HARNESS 11/2023...
- Page 9 Full Installation Diagram IT3-LEX17 NOTEs: - You must be in AUX Audio mode for audio playback from CarPlay system. - *For Lexus systems, typically MUST ground the Audio Ground Wire if using AUX for audio. - The Screen Correction T-Harness MUST be connected to the screen or flickering will occur! ATTENTION: With the...
- Page 10 Full Installation Diagram IT3-LEX19 NOTEs: - You must be in AUX Audio mode for audio playback from CarPlay system. - *For Lexus systems, typically MUST ground the Audio Ground Wire if using AUX for audio. - The Screen Correction T-Harness MUST be connected to the screen or flickering will occur! ATTENTION: With the latest...
- Page 11 • How to connect to Apple CarPlay / How to setup Bluetooth Phone Calls If you would like to use a cable to connect your iPhone, please use a certified Apple cable. If you would to use a wireless connectivity, please follow the next steps. Before pairing the iPhone with the system, please make sure you do a "hard reset"...
-
Page 12: Dip Switch Settings
DIP Switch Settings Knob Type Joystick Controller Touch PAD Type ON : OFF : ON (▼) OFF(▲) Controller Type No.1 No.2 No.5 No.1 No.2 No.5 No.1 No.2 No.5 ON (▼) OFF(▲) ON (▼) ON (▼) ON (▼) ON (▼) ON (▼) ON (▼) OFF(▲) Controller Type For JOYTSTICK, also set... - Page 13 Activation by original ATTENTION: With the latest system software (3.6.13), use OEM Bluetooth streaming (source) buttons for all audio playback from CarPlay/Android Auto. Apple CarPlay 2015 Lexus ES (XV60) Button Function Operation Remarks Press the button 2 seconds Order : OEM → Car Play Changing Modes...
- Page 14 Settings <System> Android Connection settings Menu – Shows information on currently connected phone (does NOT bring you into Android Auto mode) CarPlay Connection settings Menu – Shows information on currently connected iPhone (does N OT bring you into CarPlay mode) For Airplay (Screen-mirroring) iPhone devices.
- Page 15 Settings <System> Selecting ‘Setup’ will bring you to the ZZPLAY The next few pages overview the IT3 interface, navigating settings and explains entering/ exiting all menus. There are (2) menu systems that exist outside of the OE radio system: Interface Setup Menu with all options CARPLAY (or Android Auto) menu and the ZZPLAY Interface Menu.
- Page 16 An array of Microphone settings are used specifically when using trigger (violet) for reverse camera (used for the provided system microphone. ZZ2 recommends using the OEM manual transmissions typically), found on Bluetooth system whenever possible for IT3 hardware (and in that the USB Media Harness.
- Page 17 OEM Bluetooth). Once turned ON, USE THIS FEATURE. use OEM Bluetooth Audio source for all sound from the ZZPLAY unit. This is how ZZ2 always suggests to use these systems (for IT3 hardware). HiCar map confirmation: This setting is never used in N.A.
- Page 18 IT3-LEX Question: I can't hear any audio from the CarPlay/Android Auto system. Answer: Your OE system must be resting on BT Audio (if on latest module sw) or AUX mode in order to hear any sound from the kit. This includes during phone calls. NOTE: Some systems AUX input are not labeled 'AUX', it may be labeled 'Media Interface' or there may be an audio conversion to the vehicle's USB input.
- Page 19 support@zz-2.com 929-220-1212 Toll free: 877-241-2526 Extension 2: Tech Support Agreement: End user agrees to use this product in compliance with all State and Federal laws. ZZDOIS LLC dba ZZ-2 is not to be held liable for misuse of its product. If you do not agree, please discontinue use immediately and return product to retailer.
