- Page 1 TB-FMCH-VFMC-HDMI Hardware User Manual TB-FMCH-VFMC-HDMI Hardware User Manual Rev. 0.1 Rev. 0.1...
- Page 2 TB-FMCH-VFMC-HDMI Hardware User Manual Revision History Version Date Description Publisher Rev.0.01 Draft Usui Rev.0.1 2021/12/14 Table 8-2 Changed slave address of IDT8T49N241 from 0x6C to 0x7C Rev. 0.1...
-
Page 3: Table Of Contents
TB-FMCH-VFMC-HDMI Hardware User Manual Table of Contents Related Documents and Accessories ..................8 Overview ............................8 Feature ............................9 Block Diagram ........................... 10 External View of the Board ......................12 Board Specifications ........................13 Power supply for the board ....................... 14 I2C bus ............................15 8.1. I2C Sub-system ........................15 8.2. I2C Slave addresses ........................ 17 8.3. FMC I2C EEPROM ........................17 Connectors ..........................18 9.1. - Page 4 TB-FMCH-VFMC-HDMI Hardware User Manual List of Figures Figure 4-1 Block diagram for TB-FMCH-VFMC-HDMI ..............10 Figure 4-2 Block diagram for Clock sub-system ................10 Figure 4-3 Block diagram for RX sub-system ................... 11 Figure 4-4 Block diagram for TX sub-system ..................11 Figure 5-1 Top view .......................... 12 Figure 5-2 Bottom view ........................12 Figure 6-1 Board Dimensions ......................13 Figure 7-1 Power Block Diagram ..................... 14 Figure 8-1 I2C sub-system ....................... 15 Figure 8-2 Jumper setting A ......................16 Figure 8-3 Jumper setting B ......................16 Figure 9-1 HDMI connector (a)RX, (b)TX ..................18 Figure 9-2 High Pin Count FMC ....................... 19 List of Tables...
-
Page 5: Safety Precautions
TB-FMCH-VFMC-HDMI Hardware User Manual Introduction Thank you for purchasing the TB-FMCH-VFMC-HDMI board. Before using the product, be sure to carefully read this user manual and fully understand how to correctly use the product. First read through this manual, and always keep it handy. SAFETY PRECAUTIONS Be sure to follow these precautions Observe the precautions listed below to prevent injuries to you or other personnel or damage to property. Before using the product, read these safety precautions carefully to ensure proper use. These precautions contain serious safety instructions that must be followed. After reading through this manual, be sure to always keep it handy. The following conventions are used to indicate the possibility of injury/damage and classify precautions if the product is handled incorrectly. Indicates the high possibility of serious injury or death if the product is handled ... - Page 6 TB-FMCH-VFMC-HDMI Hardware User Manual Warning In the event of a failure, disconnect the power supply. If the product is used as is, a fire or electric shock may occur. Disconnect the power supply immediately and contact our sales personnel for repair. If an unpleasant smell or smoking occurs, disconnect the power supply. If the product is used as is, a fire or electric shock may occur. Disconnect the power supply immediately. After verifying that no smoking is observed, contact our sales personnel for repair. Do not disassemble, repair or modify the product. Otherwise, a fire or electric shock may occur due to a short circuit or heat generation. For inspection, modification or repair, contact our sales personnel. Do not place the product on unstable locations. Otherwise, it may drop or fall, resulting in injury to persons or failure. If the product is dropped or damaged, do not use it as is. Otherwise, a fire or electric shock may occur. Do not touch the product with a metallic object. Otherwise, a fire or electric shock may occur. Do not place the product in dusty or humid locations or where water may ...
- Page 7 TB-FMCH-VFMC-HDMI Hardware User Manual Caution Do not use or place the product in the following locations. Humid, high temperature over 85 degrees Fahrenheit and dusty locations Airless locations such as closet or bookshelf Locations which receive oily smoke or steam Locations exposed to direct sunlight Locations close to heating equipment Closed inside of a car where the temperature becomes high Staticky locations Locations close to water or chemicals Otherwise, a fire, electric shock, accident or deformation may occur due to a short circuit or heat generation. Do not place heavy things on the product. Otherwise, the product may be damaged. ■ Disclaimer This product is an evaluation board intended for development of video interface. Tokyo Electron Device Limited assumes no responsibility for any damages resulting from the use of this product for purposes other than those stated. Even if the product is used properly, Tokyo Electron Device Limited assumes no responsibility for any damages caused by: (1) Earthquake, thunder, natural disaster or fire resulting from the use beyond our responsibility, acts by a third party or other accidents, the customer’s willful or accidental misuse or use under other ...
-
Page 8: Related Documents And Accessories
TB-FMCH-VFMC-HDMI Hardware User Manual 1. Related Documents and Accessories Related documents: The latest version of hardware user manual and other documents can be downloaded from Inrevium website. This board is used with Xilinx’s HDMI2.1 IP core. Documents for the IP core can be downloaded from Xilinx website. Board accessories: M2.5 brass 27mm standoff: BSB-2527E qty. 2 (Installed onto the board) M2.5 brass 25mm standoff: BSB-2525E qty. 2 M2.5 screw: B-2508-S qty. 2 (Installed onto the board) 2mm jumper socket: 2SN-BK-G qty. 3 (Installed onto the board) M2.6 10mm standoff for FMC connector: AS-2610 qty. 2 M2.6 screw for FMC standoff: B-2608-S1N qty. 4 2.52 mm Jumper socket : 90059-0009 qty. 2 (Not used) 2. Overview The TB-FMCH-VFMC-HDMI provides test environment of a system compliant with HDMI 2.1 ... -
Page 9: Feature
TB-FMCH-VFMC-HDMI Hardware User Manual 3. Feature HDMI2.1 Redriver: ON Semiconductor NB7NQ621N PLLIC: IDT IDT8T49N241-999NLGI, TI LMK03318RHST Clock Generator: Silicon Labs Si5344D Clock Multiplexer: IDT ICS854S054IGILF HDMI connector: TE connectivity, 1747981-1 FMC connector: Samtec, ASP-134488-01 (Terminal) Rev. 0.1... -
Page 10: Block Diagram
TB-FMCH-VFMC-HDMI Hardware User Manual 4. Block Diagram Block diagrams for HDMI signal path, clock sub-system, RX/TX sub-systems are shown in Figure 4-1, Figure 4-2, Figure 4-3 and Figure 4-4. HDMI Sink Connector RX[0:3]_P/N RX[0:3]_P/N DP_M2C_P/N CEC,DDC,HPD,EN,GPIO LA_P/N Subsystem IOCLK FMC_GT_CLK GBTCLK_M2C_P/N Clock HDMI Source Connector Subsystem FMC_CC CLK_M2C_P/N TX[0:3]_P/N LA_CC_P/N FMC_CLK_O LA_P/N TX[0:3]_P/N Subsystem DP_C2M_P/N CEC,DDC,HPD,EN,GPIO LA_P/N Figure 4-1 Block diagram for TB-FMCH-VFMC-HDMI OUT0p/n Qp/n OUT4p/n FMC_GT_CLK[0]_P/N FMC_CLKOUT[0]_P/N ICS854S01... -
Page 11: Figure 4-3 Block Diagram For Rx Sub-System
TB-FMCH-VFMC-HDMI Hardware User Manual RX_D0_P/N GT_M2C2_P/N B_TX B_RX TMDS_DATA0 RX_D1_P/N GT_M2C1_P/N C_TX C_RX TMDS_DATA1 RX_D2_P/N D_TX D_RX GT_M2C2_P/N TMDS_DATA2 RX_D3_P/N GT_M2C3_P/N A_TX A_RX TMDS_CLOCK NB7NQ621M IOCLK_P/N DDC_SCL DDC_SDA EEPROM HPD_SNK HPD_SRC HDMI SINK Mezzanine Connector connector HDMI_5V0 DDC_SCL,DDC_SDA Level Shifter Level HOTPLUG Shifter... -
Page 12: External View Of The Board
TB-FMCH-VFMC-HDMI Hardware User Manual 5. External View of the Board The board’s components are shown on the top view and bottom view of Figure 5-1 and Figure 5-2. Figure 5-1 Top view Figure 5-2 Bottom view Rev. 0.1... -
Page 13: Board Specifications
TB-FMCH-VFMC-HDMI Hardware User Manual 6. Board Specifications Figure 6-1 shows the board dimensions. Dimensions : 76.50mm x 69.00mm (excluding the protuberance) Number of layers (Video FMC board) : 6-layer Thickness (Video FMC board) :1.7mm Number of layers (Tx and Rx dongle) : 4-layer Thickness (Tx and Rx dongle) :1.6mm Material :Panasonic R-1755S Figure 6-1 Board Dimensions Rev. 0.1... -
Page 14: Power Supply For The Board
TB-FMCH-VFMC-HDMI Hardware User Manual 7. Power supply for the board 12V, 3.3V and VADJ have to be provided from the carrier board. Figure 7-1 shows the power block of the TB-FMCM-VFMC-HDMI. TX subsystem Vadj VREF HDMI 12V0_1 LT1761 connector 12V0_2 3V3_1 3.3V 3V3_2 3V3_3 LT1763 RX subsystem LTC3621 HDMI Vadj connector V_ADJ Figure 7-1 Power Block Diagram Rev. 0.1... -
Page 15: I2C Bus
TB-FMCH-VFMC-HDMI Hardware User Manual 8. I2C bus 8.1. I2C Sub-system The FMC card contains several I2C programmable devices. These devices can be mastered by either dedicated I2C or IO pins from the FMC connector. J1, J2 and J3 can be used for I2C selection. I2C bus goes through PCA9517 to shift the voltage level from selected voltage to 3.3V. Figure 8-1 shows I2C connection on the board. Vadj 3.3V 3.3V PCA9674BS M24C02 PCA9674BS (ADDR:65h) (ADDR: *) (ADDR:64h) LA32_N PCA9517DP Si5344D LMK03318 IDT8T49N241 LMK61E2 LA32_P (ADDR:68h) (ADDR:51h) (ADDR:6Ch) (ADDR:59h) NB7NQ621M M24C64 (ADDR:*) (ADDR:*) *See Table8-2 ＊See Table 9-3... -
Page 16: Figure 8-2 Jumper Setting A
TB-FMCH-VFMC-HDMI Hardware User Manual Figure 8-2 Jumper setting A Figure 8-3 Jumper setting B Rev. 0.1... -
Page 17: I2C Slave Addresses
I2C Slave addresses 8.2. Slave address for EEPROM on the Video FMC depends on the FMC GA pin level. Table 8-3 shows I2C slave address examples when the carrier board is ZCU106. For more details please contact to Inrevium technical support. Note: Please do not read registers of IO expander (IC21) on the Video FMC. Entire I2C bus will be hanged up due to errata of a PLL chip. -
Page 18: Connectors
TB-FMCH-VFMC-HDMI Hardware User Manual 9. Connectors 9.1. HDMI Connector HDMI Sink and Source connectors are populated on the top side of the board. HDMI5V in RX is supplied from a sourcing device. 5V in TX is generated using the on board LDO. The signals from/to the connectors have ESD protection diodes. (a) RX (b) TX Figure 9-1 HDMI connector (a)RX, (b)TX Rev. 0.1... -
Page 19: Fmc Connector
TB-FMCH-VFMC-HDMI Hardware User Manual 9.2. FMC connector This board has one HPC 400 pin FMC connection board as shown on the block diagram. This FMC connector follows the VITA 57.1 standard with Samtec ASP-134486-01 socket. Presented below is the standard pin assignment on FMC HPC connectors. Not all the pins are connected on the FMC connectors. Please follow this section for more details on all the FMC pinouts. Figure 9-2 High Pin Count FMC Rev. 0.1... -
Page 20: Pin Assignment On Fmc Connector
TB-FMCH-VFMC-HDMI Hardware User Manual 9.3. Pin assignment on FMC connector Table 9-1 shows pin assignment for FMC connector of this board except for the power rails and GND. The pins in a row filled with grey are “not connected” or “GND” on the board, hence they are not functional. Table 9-1 FMC pin assign FMC Pin No Name Schematic Signal Name Description DP1_M2C_P GT_M2Cp(1) HDMI RX1 (Positive) DP1_M2C_N GT_M2Cn(1) HDMI RX1 (Negative) DP2_M2C_P GT_M2Cp(2) HDMI RX2 (Positive) DP2_M2C_N GT_M2Cn(2) HDMI RX2 (Negative) DP3_M2C_P GT_M2Cp(3) HDMI RX3 (Positive) DP3_M2C_N... - Page 21 TB-FMCH-VFMC-HDMI Hardware User Manual FMC Pin No Name Schematic Signal Name Description LA14_N FMC_MZ1_IOn(1) TX LED D2 control LA18_CC_P FMC_CCp(5) Si5344D (IC13) CK_OUT3p LA18_CC_N FMC_CCn(5) Si5344D (IC13) CK_OUT3n LA27_P FMC_LOL Si5344D (IC13) LOL n LA27_N FMC_STATUS(1) LMK03318 (IC12) Status1 ...
- Page 22 TB-FMCH-VFMC-HDMI Hardware User Manual FMC Pin No Name Schematic Signal Name Description LA29_P FMC_MZ0_IOp(4) FRL select signal LA29_N FMC_MZ0_IOn(4) RX HDMI 5V detection LA31_P FMC_MZ0_IOp(5) LA31_N FMC_MZ0_IOn(5) RX Redriver Enable LA33_P LED_0 D1 control LA33_N LED_1 D2 control CLK0_M2C_P...
-
Page 23: Table 9-2 Tested Pins Of The Fmc
TB-FMCH-VFMC-HDMI Hardware User Manual The FMC pins listed in Table 9-2 are tested by using an example design of Xilinx HDMI2.1 IP. Note that the other pins and functions that are related to the other pins (e.g. Audio DAC, ADC, Sync separator and PLLs) are not tested and not guaranteed. Table 9-2 Tested pins of the FMC F M C P i n N o N am e I / O H D M I 2. 1 E xam pl e D esi gn A 30 D P 3̲C 2M ̲P H D M I ̲T X ̲D A T ̲P ̲O U T [ 3]... - Page 24 TB-FMCH-VFMC-HDMI Hardware User Manual URL: http://solutions.inrevium.com/ http://solutions.inrevium.com/jp/ psd-sales@teldevice.co.jp E-mail: HEAD Quarter: Yokohama East Square, 1-4 Kinko-cho, Kanagawa-ku, Yokohama City, Kanagawa, Japan 221-0056 TEL: +81-45-443-4031 FAX: +81-45-443-4063 Rev. 0.1...
