- Page 1 Dreame Robot Vacuum-Mop F9 User Manual Read this manual carefully before use, and retain it for future reference.
-
Page 2: Safety Information
Safety Information Only for navigation and positioning purposes, the camera of the vacuum-mop will collect individuals in the surroundings within the range of the viewing angles when it is cleaning. Please be assured that all your personal information will be protected by the data encryption technology. Usage This product is for floor cleaning in a home environment only. - Page 3 This product contains batteries that can only be replaced by qualified technicians or after-sales service. Hereby, Dreame Technology (Tianjin) Limited declares that the radio equipment type RVS5-WH0 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.dreame.tech...
-
Page 4: Product Overview
Product Overview Accessories Power Cord Charging Dock Cleaning Tool Water Tank Mop Pad Side Brush Note: The illustrations in this manual are for reference only, please refer to the actual product for the actual appearance. - Page 5 Product Overview Vacuum-Mop Power/Clean Button Press and hold for 3 seconds Press to start cleaning after the vacuum-mop is powered on Status Indicator White: Cleaning, or cleanup is completed Blinking white: Cleaning paused Blinking blue: Connecting to network Blinking orange: Error Spot/Dock Button Press to send vacuum-mop back to charging dock Press and hold for 3 seconds to start Spot Clean mode...
- Page 6 Product Overview Vacuum-Mop Cliff Sensor Omnidirectional Wheel Reset button Charging Contacts Press and hold to restore factory settings Optical Sensor Wi-Fi Indicator Side Brush Blinking slowly: To be connected Blinking quickly: Connecting Main Wheels On: Wi-Fi connected Main Brush Cleaning Tool Brush Guard Clips Air Outlet/Speaker Vacuum-mop and Sensors...
- Page 7 Product Overview Dust Bin Mopping module Bin Clip Bin Cover Water Tank Filter Water Tank Stopper Charging Dock Mop Pad Attaching Area Signaling Area Charging Contacts Power Port...
- Page 8 Preparation 1. Remove the protective film 3. Place the charging dock on the level ground against wall and connect to a power outlet >0.5m >0.5m >1.5m Note： • Make sure there is a distance of 0.5 meters or more on either side of the charging dock, and more than 1.5 meters in front of it.
- Page 9 Connecting with Mi Home/Xiaomi Home App Reset Wi-Fi This product works with Mi Home/Xiaomi Home app *. Scan the QR code to download and install the app. Simultaneously press and hold the buttons until you hear a You will be directed to the connection setup page if the app is installed voice saying "Waiting for the network configuration".
-
Page 10: How To Use
How to Use 1. Turn On/Off 3. Cleaning Mode Four cleaning modes are available in the app: Press and hold the button to turn on the vacuum-mop. Once the power indicator turns solid white, the vacuum-mop is in standby mode. To turn off Quiet, Standard, Strong and Turbo. - Page 11 How to Use 6. Do Not Disturb Mode Select Room Forbidden Area / Virtual Wall Do Not Disturb mode prevents the vacuum-mop from automatically starting cleaning tasks, and the power indicator remains off. You can enable Do Not Disturb or modify its hours in the app. Note: •...
- Page 12 How to Use 9. Use the mopping function ③ Install the mopping module: Align the mopping module as indicated by the arrow, then slide it into the back of the vacuum until it clicks into place. It is recommended that all floors are vacuumed at least three times before the first mopping session to achieve better cleaning effect.
- Page 13 Problem Type Solution Battery level is low. Recharge the vacuum-mop at the charging dock, then try again. Vacuum-mop does not turn on The ambient temperature is too low (below 0°C) or too high (above 50°C). The operating temperature of the vacuum-mop is 0°C to 40°C. The charging dock is not receiving power.
- Page 14 Problem Type Solution Vacuum-mop has low battery. Scheduled cleaning will not start unless the vacuum-mop has at least Vacuum-mop does not perform scheduled 15% battery left . cleaning. Does leaving the vacuum-mop on the Leaving the vacuum-mop on the charging dock after it's fully charged consumes very little charging dock consume power if it's already electricity and helps maintain optimal battery performance.
-
Page 15: Specifications
Specifications Vacuum-Mop Charging Dock Model RVS5-WH0 Model RCS0 Battery 14.4 V 5200 mAh(Rated Capacity) Rated Input 100-240 V ~ 50/60 Hz 0.5 A Wireless Connectivity Wi-Fi IEEE 802.11b/g/n 2.4 GHz Rated Output 19.8 V Rated Voltage 14.4V Rated Power Operation Frequency 2400-2483.5 MHz Maximum Output ＜20 dBm... - Page 16 For further information, please go to www.dreame.tech Manufactured by: Dreame Technology )Tianjin( Limited Made in China...
