Legacy 1310-520 Assembly Instructions

ASSEMBLY INSTRUCTIONS
1310/1313-520 ROUND TABLE
Thank you for purchasing this quality product. Before beginning, please check the packing material carefully for small parts which may have come
loose inside the carton during shipping. Please do not discard any packing material until all parts have been located. If any parts are missing, please
contact your dealer for prompt replacement.
Caution: (1) These parts are cumbersome and heavy. This product can best be assembled with the assistance of one or more persons in order to
prevent personal injury and to ensure parts are not damaged during the assembly process. If dirty, clean finished parts with mild dishwashing liquid
and water solution applied on damp cloth. Cloth should not be excessively wet. Polish finish with soft cloth and an industry recognized furniture
polish.
(2) To prevent damage to your floor or carpet, please check the bottom of each piece of furniture for stain residue and rough surfaces
and also check for staples or nails left after removing the packaging material. The manufacturer will not be held responsible if preventative steps are
not taken prior to installation.
(3) During normal use every day, screws, bolts, nuts and wooden plugs may loosen up. They should be periodically inspected and re-
tightened to prevent damage to the furniture and (or) personal property or cause injury. Always check to be sure all hardware on this list and the
below mentioned components are attached to the furniture properly and kept tightened.
Parts & Hardware List:
NO HARDWARE LIST
A TABLE TOP
B CONNECTING PLATE
C LONG LEG FRAME
D SHORT LEG FRAME
A
QTY. NO.
1 PC #1 ALLEN BOLT
1 PC #3 FLAT WASHER
1 PC
2 PCS
B
Step 2
HARDWARE LIST QTY.
5 PCS
1-1/4"L X 1/4"
5 PCS
1/4" X 23 mm
D
NO. HARDWARE LIST
#2 LOCK WASHER
1/4"
#4 ALLEN WRENCH
4 mm
D
C
Step 3
QTY.
5 PCS
1 PC
