Legacy 1310-4206 Assembly Instructions

ASSEMBLY INSTRUCTIONS:
1310 / 1313-4206/4216/4901 KING BED 6/0
Thank you for purchasing this quality product. Before beginning, please check the packing material carefully
for small parts which may have come loose inside the carton during shipping. Please do not discard any
packing material until all parts have been located. If any parts are missing, please contact your dealer for
prompt replacement.
Caution: (1) These parts are cumbersome and heavy. This product can best be assembled with the
assistance of one or more persons in order to prevent personal injury and to insure parts are not damaged
during the assembly process. If dirty, clean finished parts with mild dishwashing liquid and water solution
applied on damp cloth. Cloth should not be excessively wet. Polish finish with soft cloth and an industry
recognized furniture polish.
(2) To prevent damage to your floor or carpet, please check the bottom of each piece of furniture
for stain residue and rough surfaces and also check for staples or nails left after removing the packaging
material. The manufacturer will not be held responsible if preventative steps are not taken prior to
installation.
(3) During normal use everyday, screws, bolts, nuts and wooden plugs may loosen up. They
should be periodically inspected and re-tightened to prevent damage to the furniture and (or) personal
property or cause injury. Always check to be sure all hardware on this list and the below mentioned
components are attached to the furniture properly and kept tightened.
Parts & Hardware List:
PARTS LIST
A
HEADBOARD
B
LEG RIGHT
C
LEG LEFT
D
STRETCHER
D
STEP 2
PARTS LIST
Q'TY
E
1 Pc FOOTBOARD
F
1 Pc SIDE RAIL
G
1 Pc
SLAT RAIL
H
1 Pc SLAT SUPPORT
B
D
C
www.legacyclassic.com
Q'TY
1
1 Pc
2
2 Pcs
3
4
3 Pcs
5
6 Pcs 6
7
8
9
4
3
2
1
B
A
LEGACY
classic modern
HARDWARE LIST
Flat Washer (5/16" x Ø19)
Spring Washer (5/16" x Ø12)
Bolt (5/16" x 1-9/16")
Allen Key (4 x 3-1/8")
Full Thread Bolt (5/16" x 3")
Curve washer ( 5/16" )
Hex. Nut ( Ø5/16" x 1/4" )
Open Wrench ( #1/2" )
Screw ( #4 x 1" mm )
B
A
STEP 3
Page 01 of 02
Q'TY
8 Pcs
8 Pcs
8 Pcs
1 Pc
8 Pcs
8 Pcs
8 Pcs
1 Pc
6 Pcs
